Product Details:

Place of Origin: Henan, China
Brand Name: Sinoline, Sinolion

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: $1,500.00/sets >=1 sets
Get Best Price Contact Now

Detail Information

Applicable Industries: Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Construction Works , Energy & Mining Showroom Location: None
Condition: New Type: Jaw Crusher
Application: Chemical Industry, Stone, Ore, Glass, Coal Motor Type: AC Motor
Capacity(t/h): 1-500t/h Dimension(L*W*H): Depends On Models
Weight: 600 KG Warranty: 1 Year
Marketing Type: New Product 2021 Machinery Test Report: Provided
Video Outgoing-inspection: Provided Warranty Of Core Components: 1.5 Years
Core Components: PLC, Motor, Engine, Pump Key Selling Points: Competitive Price
Keyword: Limestone Jaw Crusher Of Mining Machine Feeding Size: 0-1020mm
Discharge Size: 0-300 Jaw Plate Material: High Manganese
Driving Type: Diesel Engine Or Motor Wearing Parts: Jaw Plates
Installation: Supply Manual And Send Engineer To Guide User Product Name: Primary Crushing Line Limestone Jaw Crusher Of Mining Machine

Product Description

Primary Crushing Line Limestone Jaw Crusher of Mining Machine

Product Description

50t/h Stone Crushing Line Jaw Crusher with 600 KG Weight and Discharge Size of 0-300 0



Crasher stone crusher machine

The jaw crusher has been a staple of the hard rock mining industry since its invention. It is used as a primary crusher for all types of ores. The jaw typically takes the larger run of mine product and produces a sized discharge for feed to a secondary crusher such as a cone crusher, ball mill, or hammer mill. We have sold our jaw crushers to many different industries over the years, but the hard rock mining industry is still the #1 purchaser of our jaw crushers and other equipment such as turn-key ore processors.



Crasher stone crusher machine working principle:

Motor drives belt and belt pulley, makes moving jaw up and down through eccentric shaft. When the moving jaw is up, the angle between lining plate and moving jaw becomes large, and this will push moving jaw plate close to the fixed jaw plate. During this process, the material is crushed and ground, thus the crushing will be done.



When the moving jaw is down, the angle between lining plate and moving jaw becomes small, the moving jaw plate will leave the fixed jaw plate on account of the effect of pulling bar and spring, and then the crushed material will be discharged from the lower opening of the crushing room.



With the motor continuously rotating and the material periodically crushed and discharged by the crusher, the mass production can be realized.



50t/h Stone Crushing Line Jaw Crusher with 600 KG Weight and Discharge Size of 0-300 1



Our diesel engine jaw crusher model: 150*250, 200*300, 250*400, 400*600.



Diesel engine jaw crusher for sale technical parameters:



Model

max feed size

(mm)

Discharge size

(mm)

Capacity

(t/h)

Power

(kw)

Weight

(T)

PE-150×250 125 10-40 1-3 5.5 0.8
PE-200×300 180 20-70 2-8 11 1.4
PE-250×400 210 20-80 5-20 15 3
PE-400×600 350 40-100 15-60 30 6.5
PE-500×750 425 50-100 40-110 55 11.3
PE-600×900 480 65-160 90-150 75 17.625
PE-750×1060 630 80-160 100-250 90-110 27.5
PE-900×1200 750 95-165 120-300 110-160 52
PE-1000×1200 850 110-260 180-350 110-160 57
PE-1200x1500 1020 150-300 300-500 180-220 100



Secondary diesel engine jaw crusher technical parameters:



Model

max feed size

(mm)

Discharge size

(mm)

Capacity

(t/h)

Power

(kw)

Weight

(T)

PEX-150×750 120 8-25 10-40 15 3.5
PEX-250×750 210 12-25 15-50 30 5.5
PEX-250×1000 210 12-50 30-95 37 6.37
PE-350×750 300 15-50 20-50 30 6.5
PE-300×1300 250 20-90 45-130 75 11
PE-600×900 480 65-160 90-150 75 17.625



Diesel engine jaw crusher for sale structure:

50t/h Stone Crushing Line Jaw Crusher with 600 KG Weight and Discharge Size of 0-300 2



Portable diesel engine jaw crusher:

50t/h Stone Crushing Line Jaw Crusher with 600 KG Weight and Discharge Size of 0-300 350t/h Stone Crushing Line Jaw Crusher with 600 KG Weight and Discharge Size of 0-300 4

50t/h Stone Crushing Line Jaw Crusher with 600 KG Weight and Discharge Size of 0-300 5

50t/h Stone Crushing Line Jaw Crusher with 600 KG Weight and Discharge Size of 0-300 6

Finished jaw crushers:

50t/h Stone Crushing Line Jaw Crusher with 600 KG Weight and Discharge Size of 0-300 7

50t/h Stone Crushing Line Jaw Crusher with 600 KG Weight and Discharge Size of 0-300 8



Jaw crusher spare parts: jaw plates, spring, fly wheels, etc.

50t/h Stone Crushing Line Jaw Crusher with 600 KG Weight and Discharge Size of 0-300 9



Packaging & Shipping

 50t/h Stone Crushing Line Jaw Crusher with 600 KG Weight and Discharge Size of 0-300 1050t/h Stone Crushing Line Jaw Crusher with 600 KG Weight and Discharge Size of 0-300 1150t/h Stone Crushing Line Jaw Crusher with 600 KG Weight and Discharge Size of 0-300 12

Working site

 50t/h Stone Crushing Line Jaw Crusher with 600 KG Weight and Discharge Size of 0-300 13

50t/h Stone Crushing Line Jaw Crusher with 600 KG Weight and Discharge Size of 0-300 14

Our Services

 1. Pre-sale service:

1) Sinolion will provide production line design, quotation sheet, working sites video, machinery photos, sample testing(gold ore, tin ore , iron ore, tungsten processing in laboratory).

2) Welcome to visit us at any time, we will pick you up.



2. Sale service:

1) Keep clients updated when our company gets advance payment.

2) Confirm production details with clients.

3) Take photos and send all pictures to customers during production.

4) Inspection and testing the product before delivery;

5) Clients are welcome to inspect the equipment when the equipment are ready to delivery.

6) logistics service if needed.



3. After Sale service:

1) Provide foundation drawing to the clients for installation.

2) Besides, our engineers are available to help with installation and workers training.

3) Repairing and maintenance if any problem during the warranty.

4) Spare parts and wearing parts will be offered with production cost in 10 years.



50t/h Stone Crushing Line Jaw Crusher with 600 KG Weight and Discharge Size of 0-300 15



Company Information

50t/h Stone Crushing Line Jaw Crusher with 600 KG Weight and Discharge Size of 0-300 1650t/h Stone Crushing Line Jaw Crusher with 600 KG Weight and Discharge Size of 0-300 1750t/h Stone Crushing Line Jaw Crusher with 600 KG Weight and Discharge Size of 0-300 1850t/h Stone Crushing Line Jaw Crusher with 600 KG Weight and Discharge Size of 0-300 1950t/h Stone Crushing Line Jaw Crusher with 600 KG Weight and Discharge Size of 0-300 2050t/h Stone Crushing Line Jaw Crusher with 600 KG Weight and Discharge Size of 0-300 21



FAQ

Question 1: What’s the delivery time after I pay the deposit ?

Answer: We will delivery the goods within 10-15 working days after receipt of the prepayment.



Question 2: Is mineral samples analysis available?

Answer: Sure, we supply samples analysis service for free. After the testing, we will give you the reasonable flow chart, suitable solution and equipment selection.



Question 3: Do you have client in my country?

Answer: Our products have exported to Malaysia, Indonesia, the Philippines, Vietnam, Myanmar, Korea, Singapore, Thailand, Mongolia, Ghana, Sudan, Serbia, Kazakhstan,  Canada, Nigeria, Australia, Chile, Brazil, Columbia, Ecuador, Peru, Bolivia, etc



Question 4: How long of your machine quality guarantee terms ?

Answer: Quality guarantee time is one year(wearing parts excluded).
