Less Than 300mm Feeding Size Environmental Stationary Wood Sawdust Screening Machine

Less Than 300mm Feeding Size Environmental Stationary Wood Sawdust Screening Machine

Product Details:

Place of Origin: Henan, China
Brand Name: Sinolion

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: $13,100.00/sets
Get Best Price Contact Now

Detail Information

Applicable Industries: Energy & Mining Showroom Location: United States, Mexico
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Marketing Type: New Product 2020 Warranty Of Core Components: 1 Year
Core Components: Motor Condition: New
Type: Compost Trommel Screener Application: Topsoil, Compost, Solid, Municipal Soild Waste, Glass, Mulch, Organics, Bark, MSW, Municipal Solid Waste
Voltage: 380V/415V/440V( As Client Request) Dimension(L*W*H): As Per Different Model
Weight: 2200 KG Warranty: 18 Month Excluding Spare Parts
Product Name: High Quality Rotary Compost Sifter /drum Screen Filter For Compost Screen Material: Steel Bar, Steel Plate, Manganese Steel Wire Woven, Stainless Steel
Power: 3-45KW Dimension: 5600x2015x2010mm
Installation: Supply Manual To Guide User Capacity: 1-200 Tons Per Hour
Feeding Size: Less Than 300mm Discharge Size: Less Than 6mm Or As Request
Color: Yellow, White, Red, Blue, Gray( Or As Client Request)

Product Description

Environmental Stationary Wood Sawdust Firewood Screening Machine

Product Description



Due to the turning and rolling of the material in the screen drum, the material stuck in the screen hole can be ejected to prevent the screen hole from being clogged. GTS series shaftless trommel screen machine mainly consists of motor, gearbox, screen drum, frame, sealing cover, inlet and outlet. The screen drum is mounted obliquely on the frame. The motor is coupled to the drum unit via a coupling through a reducer to drive the screen drum unit to rotate about its axis. After the material enters the screen drum, due to the tilting and rotation of drum screen, the material on the screen surface is turned over and rolled, so that the qualified material (the product under the sieve) is discharged through the screen, and the unqualified material (the product on the sieve) ) is discharged through the end of the screen drum.

Less Than 300mm Feeding Size Environmental Stationary Wood Sawdust Screening Machine 0

Less Than 300mm Feeding Size Environmental Stationary Wood Sawdust Screening Machine 1

Less Than 300mm Feeding Size Environmental Stationary Wood Sawdust Screening Machine 2



Less Than 300mm Feeding Size Environmental Stationary Wood Sawdust Screening Machine 3



Application:munlcpal solid waste,construction waste,stone,compost,wood chips,sawdust,soil,coal,river sand,refractory materials,chemiacal,etc



Technical parameter of shaftless trommel screen



Model
Capacity
(t/h)
Power
(kw)
Diameter
(mm)
Length
(mm)
Discharge
(mm)
Input
(mm)
Dimension
(mm)
FTS1230
60
3.0
1200
3000
0-100
≤30
5613*1940*2390


Less Than 300mm Feeding Size Environmental Stationary Wood Sawdust Screening Machine 4

Packaging & Shipping

 Less Than 300mm Feeding Size Environmental Stationary Wood Sawdust Screening Machine 5

Less Than 300mm Feeding Size Environmental Stationary Wood Sawdust Screening Machine 6Less Than 300mm Feeding Size Environmental Stationary Wood Sawdust Screening Machine 7Less Than 300mm Feeding Size Environmental Stationary Wood Sawdust Screening Machine 8

Less Than 300mm Feeding Size Environmental Stationary Wood Sawdust Screening Machine 9Less Than 300mm Feeding Size Environmental Stationary Wood Sawdust Screening Machine 10Less Than 300mm Feeding Size Environmental Stationary Wood Sawdust Screening Machine 11 Less Than 300mm Feeding Size Environmental Stationary Wood Sawdust Screening Machine 12
