• Energy Mining Yellow 2 Ton Ball Mill Machine for Gold Copper Iron Ore Production Line
Energy Mining Yellow 2 Ton Ball Mill Machine for Gold Copper Iron Ore Production Line

Energy Mining Yellow 2 Ton Ball Mill Machine for Gold Copper Iron Ore Production Line

Product Details:

Place of Origin: Henan, China
Brand Name: Sinolion

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: $2,686.00/sets >=1 sets
Get Best Price Contact Now

Detail Information

Applicable Industries: Energy & Mining Showroom Location: None
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Marketing Type: Hot Product 2023 Warranty Of Core Components: 1 Year
Core Components: Motor Condition: New
Type: Ball Mill Motor Type: AC Motor
Capacity(t/h): 0.5-83t/h Dimension(L*W*H): Depends On Different Models
Weight: 3.6 KG Warranty: One Year (excluding Wearing Parts)
After-sales Service Provided: Engineers Available To Service Machinery Overseas Application: Gold Ore, Iron Ore, Copper, Quartz, Limestone, Building Material, Etc
Liner: High Manganese, Rubber, Ceramic(as Client Request) Spare Parts: Liner, Grinding Balls
Flow Chart And Foundation: Supply By Seller Operation: Automatically
After Sale Service: The Whole Using Life Grinding Way: Wet Or Dry
Test & Installation: Professional Engineer Supplies Any Help Color: Yellow, White, Red, Blue, Gray( Or As Client Request)

Product Description

Product Description





Small Mini Ball Mill Introduction:



Ball mill is the key equipment for grinding after the crushing process, which is widely used in the manufacture industries, such as cement, silicate, new building material, refractory material, fertilizer, ferrous metal, nonferrous metal and glass ceramics and can be used for the dry and wet grinding for all kinds of ores and other grind-able materials.



Ball Mill grinds material by rotating a cylinder with steel grinding balls, causing the balls to fall back into the cylinder and onto the material to be ground. The rotation is usually between 4 to 20 revolutions per minute, depending upon the diameter of the mill. The larger the diameter is, the slower the rotation speed will be. If the peripheral speed of the mill is too great, it begins to act like a centrifuge and the balls do not fall back, but stay on the perimeter of the mill. The point where the mill becomes a centrifuge is called the "Critical Speed", and ball mills usually operate at 65% to 75% of the critical speed.



Ball mill Working Principle:

The ball mill is a horizontal rotating device transmitted by the outer gear. The materials are transferred to the grinding chamber through the quill shaft uniformly. There are ladder liner and ripple liner and different specifications of steel balls in the chamber. The centrifugal force caused by rotation of barrel brings the steel balls to a certain height and impact and grind the materials. The ground materials are discharged through the discharging board thus the grinding process is finished.



Ball mill Structure:

The machine is composed by feeding part, discharging part, rotation part and driving part (reducer, small driving gear, electric motor and electric control). The quill shaft adopts cast steel part and the liner is detachable. The rotation big gearwheel is made by cast hobbling processing and the drum is equipped with wear-resistant liner, which has good wear-resistance.



Ball Mill Features:



1) Ball mill is an efficient tool for grinding many materials into fine powder.



2) Ball mill is widely used in ore upgrading production line, building material, chemical industry, etc.



3) There are two ways of grinding: the dry way and the wet way.



4) Ball mill can be divided into tabular type and flowing type according to different expelling mine



5) To use the ball mill, the material to be ground is loaded into the neoprene barrel that contains grinding media.



6) As the barrel rotates, the material is crushed between the individual pieces of grinding media that mix and crush the product into fine powder over a period of several hours.



7) The longer the ball mill runs, the finer the powder will be.



8) Ultimate particle size depends entirely on how hard the material you're grinding is, and the time ball mill runs.





9) Our ball mills have been used to grind glass, powder food products, create custom varnishes, make ceramic glaze, and powder various chemicals.





Ball mill technicial parameters:





Model

Rotation speed

(r/min)

Weight of

grinding media

(ton)

Size of feed opening

(mm)

Discharge size

(mm)

Capacity

(t/h)

Power

(kw)

Weight

(T)

Φ 900x1800 38 1.5 ≤ 20 0.075-0.89 0.65-2 18.5 3.6
Φ 900x3000 38 2.51 ≤ 20 0.075-0.89 1.1-3.5 22 4.6
Φ 1200x2400 32 3.8 ≤ 25 0.075-0.6 1.5-4.8 30-45 12.5
Φ 1200x3000 32 5 ≤ 25 0.074-0.4 1.6-5 30-45 12.8
Φ 1200x4500 32 7 ≤ 25 0.074-0.4 1.6-5.5 55 13.8
Φ 1500x3000 27 8 ≤ 25 0.074-0.4 2-5.8 75-90 17
Φ 1500x4500 27 14 ≤ 25 0.074-0.4 3-6.5 110 21
Φ 1500x5700 27 15 ≤ 25 0.074-0.4 3.5-8 132 24.7
Φ 1830x3000 24 11 ≤ 25 0.074-0.4 4-10 180 28
Φ 1830x6400 24 23 ≤ 25 0.074-0.4 6.5-15 210 34
Φ 1830x7000 24 25 ≤ 25 0.074-0.4 7.5-17 245 36
Φ 2200x5500 21 30 ≤ 25 0.074-0.4 10-22 370 48.5
Φ 2200x6500 21 31 ≤ 25 0.074-0.4 14-26 280 52.8
Φ 2200x7500 21 33 ≤ 25 0.074-0.4 15-29 475 56

Energy Mining Yellow 2 Ton Ball Mill Machine for Gold Copper Iron Ore Production Line 0

 Energy Mining Yellow 2 Ton Ball Mill Machine for Gold Copper Iron Ore Production Line 1



Packaging & Shipping

 Energy Mining Yellow 2 Ton Ball Mill Machine for Gold Copper Iron Ore Production Line 2Energy Mining Yellow 2 Ton Ball Mill Machine for Gold Copper Iron Ore Production Line 3





Working site

 Energy Mining Yellow 2 Ton Ball Mill Machine for Gold Copper Iron Ore Production Line 4

Our Services


1. Pre-sale service:

1) Sinolion will provide production line designquotation sheet, working sites video, machinery photos, sample testing(gold ore, tin ore , iron ore, tungsten processing in laboratory).

2) Welcome to visit us at any time, we will pick you up.



2. Sale service:

1) Keep clients updated when our company gets advance payment.

2) Confirm production details with clients.

3) Take photos and send all pictures to customers during production.

4) Inspection and testing the product before delivery

5) Clients are welcome to inspect the equipment when the equipment are ready to delivery.

6) logistics service if needed.



3. After Sale service:

1) Provide foundation drawing to the clients for installation.

2) Besides, our engineers are available to help with installation and workers training.

3) Repairing and maintenance if any problem during the warranty.

4) Spare parts and wearing parts will be offered with production cost in 10 years.

Company Information

 Energy Mining Yellow 2 Ton Ball Mill Machine for Gold Copper Iron Ore Production Line 5

Energy Mining Yellow 2 Ton Ball Mill Machine for Gold Copper Iron Ore Production Line 6





FAQ

Question 1: What’s the delivery time after I pay the deposit ?

Answer: We will delivery the goods within 10-15 working days after receipt of the prepayment.



Question 2: Is mineral samples analysis available?

Answer: Sure, we supply samples analysis service for free. After the testing, we will give you the reasonable flow chart, suitable solution and equipment selection.



Question 3: Do you have client in my country?

Answer: Our products have exported to Malaysia, Indonesia, the Philippines, Vietnam, Myanmar, Korea, Singapore, Thailand, Mongolia, Ghana, Sudan, Serbia, Kazakhstan,  Canada, Nigeria, Australia, Chile, Brazil, Columbia, Ecuador, Peru, Bolivia, etc



Question 4: How long of your machine quality guarantee terms ?

Answer: Quality guarantee time is one year(wearing parts excluded).
