50-500t/h Capacity Counter Flow Firewood Chip/Compost Fertilizer Rotary Drum Screen

50-500t/h Capacity Counter Flow Firewood Chip/Compost Fertilizer Rotary Drum Screen

Product Details:

Place of Origin: Henan, China
Brand Name: Sprial Separator

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: $13,100.00/sets >=1 sets
Packaging Details: Standard export packing, Spare parts in wooden case, big machines loaded in container,<br>large machines use nude packing, cover with plastic cloth. We export through Qingdao<br>Port, also can be nominated by customer. We have superior cargo agent to arran
Supply Ability: 25 Set/Sets per Month
Get Best Price Contact Now

Detail Information

Applicable Industries: Building Material Shops, Manufacturing Plant, Construction Works , Energy & Mining Showroom Location: Mexico
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Marketing Type: New Product 2023 Warranty Of Core Components: 1 Year
Core Components: PLC, Engine, Bearing, Gearbox, Motor, Pressure Vessel, Gear, Pump Condition: New
Type: Sprial Separator Voltage: 380v/410v/440v
Dimension(L*W*H): Depend On Firewood Chip Trommel Screen Weight: 2200 KG
Warranty: 1 Year After-sales Service Provided: Engineers Available To Service Machinery Overseas
Power: 3-45kw Screen Material: Steel Bar, Steel Plate Punch Hole, Steel Wire Woven, Stainless Steel
Application: Coal, Coke, Mulch, Organics, Bark, MSW, Building Waste Installation: Supply Manual To Guide User
Capacity: 50-500t/h Feeding Size: Less Than 300mm
Discharge Size: As Request Color: Yellow, White, Red, Blue, Gray( Or As Client Request)
Port: Qingdao, Ningbo, Lianyungang

Product Description

Counter flow firewood chip /compost fertilizer rotary drum screen machine

Product Description



Compost Sifter provides a simple, efficient and economical solution to upgrade a wide range of materials and optimize the subsequent process steps of recovery. This method of screening helps to reduce operating and investment costs and to increase product quality, while allowing rapid and large volume processing. This material is then passed onto the downstream process equipment which can be in various forms, such as centrifugal concentrate, spiral chute, jig, etc. Our compost sifter is constructed of high quality material, designed for high performance, high production rates, lower operating costs and lower maintenance.



Removable side panels expose the full length of the drum screen, providing for easy maintenance and cleaning.
Put the finished product where you need it – loading directly into a truck or stockpiling using the optional radial stacking conveyor on select models that swings a full 200 degrees.
Avoid jams with both the drum and feed conveyor being reversible.
With the ability to tension the screen around the drum, operators can add rigidity to the screens. This design allows the use of smaller gauge wire, ultimately increasing the open area of the screen to help improve productivity .



Screening is a unit operation which involves the segregation of a mixture of materials with different particle size distributions into two or more fractions (each fraction having relatively similar particle size distribution) by means of one or more sets of screen mesh openings (or screening surfaces). The material that remains on the screening surface generally is known as the oversize (or plus) material. The material that passes through the screen apertures commonly is referred to as the undersize (or minus) material. The screening surface may consist of plastic, cloth, wire mesh, perforated plate or bars.



technical parameters



Model

Capacity

Power

 Screen

Discharge Size

Input Size

(t/h)

(kw)

Diameter (mm)

Length (mm)

(mm)

(mm)

GTS1020

1-2

3.0

1000

2000

0~100

≤300

GTS1030

2-3

4.0

1000

3000

0~100

≤300

GTS1240

3-5

5.5

1200

4000

0~100

≤300

GTS1540

5-8

7.5

1500

4000

0~100

≤300

GTS1560

6-10

11

1500

6000

0~100

≤400

GTS2080

10-20

15

2000

8000

0~100

≤400



50-500t/h Capacity Counter Flow Firewood Chip/Compost Fertilizer Rotary Drum Screen 0

Packaging & Shipping

50-500t/h Capacity Counter Flow Firewood Chip/Compost Fertilizer Rotary Drum Screen 1



Case

 50-500t/h Capacity Counter Flow Firewood Chip/Compost Fertilizer Rotary Drum Screen 2

Company Information



50-500t/h Capacity Counter Flow Firewood Chip/Compost Fertilizer Rotary Drum Screen 3

50-500t/h Capacity Counter Flow Firewood Chip/Compost Fertilizer Rotary Drum Screen 4

50-500t/h Capacity Counter Flow Firewood Chip/Compost Fertilizer Rotary Drum Screen 5

50-500t/h Capacity Counter Flow Firewood Chip/Compost Fertilizer Rotary Drum Screen 6

FAQ

Question 1: Can you give me a solution and quotation?

Answer: Absolutely sure, we can provide accurate solution and quotation, please give us background information, including, raw material, the capacity, max. input size, the output size, the usage of final products, etc.



Question 2: Way of payment
Answer: Welcome clients place the order by alibaba online one-touch! Deya also offers various ways of payment, T/T, against copy of B/L, L/C, D/A, D/P, West union, etc. All can be negotiated.



Question 3: What’s the delivery time after I pay the deposit ?

Answer: Normal delivery time within 10 to 20 working days, complete production line or larger equipment may take longer. Exact delivery shall be confirmed when place the order.



Question 4: How long of your machine quality guarantee terms?

Answer: Equipment from Zhengzhou Sinolion Machinery Co., Ltd. with 18 months warranty, can be extended to 24 months as request.
