Dry or Batch Type Calcium Lime Ball Mill for Gold Processing in Small Mini Laboratory
Product Details:
Place of Origin: | China |
Brand Name: | Sinolion |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 unit |
---|---|
Price: | $2,686.00/sets >=1 sets |
Detail Information |
|||
Applicable Industries: | Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Construction Works , Energy & Mining | Showroom Location: | None |
---|---|---|---|
Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
Marketing Type: | New Product 20201 | Warranty Of Core Components: | 2 Years |
Core Components: | PLC, Engine, Motor, Pump | Condition: | New |
Type: | LimesBall Mill | Motor Type: | AC Motor |
Capacity(t/h): | 0.5-83t/h | Dimension(L*W*H): | Depend On Models |
Weight: | 2000 KG | Warranty: | 1 Year |
Keywords: | Calcium Limee Grinding Equipment | Application: | Gold Iron Copper, Quartz Limestone, Clinker, Cement, Chrom, Chromite |
Grinding Way: | Wet, Dry Or Batch Type | Operation: | Automatic Or Manual |
Driving Type: | Diesel Engine Or Motor | Liner: | High Manganese, Rubber, Ceramic(as Client Request) |
After-sales Service: | Engineers Available Service Overseas | Brand: | Sinolion |
Product Name: | Calcium Lime Ball Mill Gold Processing Grinding Ball Mill | Name: | Calcium Lime Ball Mill |
Product Description
Gold mine grinding equipment description
Main technical parameters of gold mine grinding equipment
Model | Cylinder rotating (r/min) | Grinding media loading (t) | Feed size (mm) | Discharge size (mm) | Capacity (t/h) | Powder (kw) | Weight (t) |
Φ900x1800 | 38 | 1.5 | ≤ 20 | 0.075-0.89 | 0.65-2 | 18.5 | 3.6 |
Φ900*3000 | 38 | 2.51 | ≤ 20 | 0.075-0.89 | 1.1-3.5 | 22 | 4.6 |
Φ1200*2400 | 32 | 3.8 | ≤ 25 | 0.075-0.6 | 1.5-4.8 | 30-45 | 12.5 |
Φ1200*3000 | 32 | 5 | ≤ 25 | 0.074-0.4 | 1.6-5 | 30-45 | 12.8 |
Φ1200*4500 | 32 | 7 | ≤ 25 | 0.074-0.4 | 1.6-5.5 | 55 | 13.8 |
Φ1500*3000 | 27 | 8 | ≤ 25 | 0.074-0.4 | 2-5.8 | 75-90 | 17 |
Φ1500*4500 | 27 | 14 | ≤ 25 | 0.074-0.4 | 3-6.5 | 90-110 | 21 |
Φ1500*5700 | 27 | 15 | ≤ 25 | 0.074-0.4 | 3.5-8 | 110-132 | 24.7 |
Φ1830*3000 | 24 | 11 | ≤ 25 | 0.074-0.4 | 4-10 | 132-180 | 28 |
Φ1830*6400 | 24 | 23 | ≤ 25 | 0.074-0.4 | 6.5-10 | 210 | 34 |
Φ1830*7000 | 24 | 25 | ≤ 25 | 0.074-0.4 | 7.5-17 | 210-245 | 36 |
Φ2200*5500 | 21 | 30 | ≤ 25 | 0.074-0.4 | 10-22 | 370 | 48 |
Φ2200*6500 | 21 | 31 | ≤ 25 | 0.074-0.4 | 14-26 | 380 | 50 |
Φ2200*7500 | 21 | 33 | ≤ 25 | 0.074-0.4 | 15-29 | 475 | 56 |
Φ2400*7000 | 21 | 39 | ≤ 25 | 0.074-0.4 | 16-33 | 475 | 69 |
Φ2400*11000 | 21 | 51.5 | ≤ 25 | 0.04-0.08 | 16-35 | 630 | 99 |
Φ2700*3600 | 21 | 39 | ≤ 25 | 0.074-0.4 | 16-29 | 475 | 74 |
Φ2700*4500 | 21 | 43.5 | ≤ 25 | 0.074-0.4 | 20-35 | 500 | 80 |










Main features of gold mine grinding equipment
1) Simple structure in linear type ,easy in installation and maintation.
2) Adopting advanced world famous brand components in pneumatic parts, electric parts and operation parts.
3) Mine ball mill in a high automatization and intellectualization, no pollution.
The gold mine grinding equipment is a horizontal rotating device transmitted by the outer gear. The materials are transferred to the grinding chamber through the quill shaft uniformly. There are ladder liner and ripple liner and different specifications of steel balls in the chamber. The centrifugal force caused by rotation of barrel brings the steel balls to a certain height and impact and grind the materials. The ground materials are discharged through the discharging board thus the grinding process is finished.






●Pre-sales service: We provide you with the prophase plan, process flow design and manufacturer equipment according to your special demand. ●Sales service: Send technicians to the jobsite guiding the installation and adjustment, training operators and finishing the check and accept together with you. ●After-sales service: To establish long term friendship, we will reg-ularly pay return visit to customers. Supplying technique, building design, instruction, installation and debugging for free. ●Lifelong service: One year warranty to make sure your machine runs constantly. Always provide spare parts for a long term.

Packaging of gold ore grinding ball mill | ||
Size | Depend on models | |
Weight | Depend on models | |
Packaging Details | The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request. |
