Product Details:

Place of Origin: Henan, China
Brand Name: Sinolion

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: $1,650.00/sets >=1 sets
Get Best Price Contact Now

Detail Information

Applicable Industries: Energy & Mining Showroom Location: None
Condition: New Type: Gravity Separator
Production Capacity: Above 98% Voltage: 380V/415V/440V( As Client Request)
Dimension(L*W*H): 545x1825x1242 Weight: 1012 KG
Warranty: 12 Months Excluding Spare Parts Marketing Type: New Product 2020
Machinery Test Report: Provided Video Outgoing-inspection: Provided
Warranty Of Core Components: 1 Year Core Components: Motor, Gearbox
Key Selling Points: Firbe Glass Model: 6-S
Material: Fiber Glass Product Name: Gold Shaking Table
Dimension: 5454x1825x1242 Application: Gold, Chormite, Tungsten Ore, Tin, Tantalum Ore, Niobium Mine
Installation: Supply Manual To Guide User Capacity: 0.5-1.2 Tons Per Hour
Feeding Size: 0.074-2mm Slurry Density: 15-30%
Color: Yellow, White, Red, Blue, Gray( Or As Client Request)

Product Description

Product Description

Gold concentrator table application


1. Gold concentrator table is a gravity dressing machine,which has high separation efficiency.It is designed to wet gravity-based separation of minerals and other granular materials.


2. Gold concentrator table does not need reagent compared with the traditional process as well as it can make the materials concentrated at one time.

3. Gold concentrator table is widely used for the separation of mineral ores, such as gold ore,iron ore,silver ores,etc.

4. Gold concentrator table is mainly composed of bed head, electromotor, adjusting gradient device, bed surface, ore chute, water chute, rifle bar and lubricating system.


Gold concentrator table specifications:



Model


Unit


Coarse ore Deck

Fine sand

Deck



Slime Deck


Deck
size
Length
mm
4450
4450
4450
transmission end width
mm
1855
1855
1855
Concentrate end width
mm
1546
1546
1546
Maximum Feeding Size
         mm
2
0.5
0.15
Feeding Amount
t/d
30-60
10-20
15-25
Feeding Density
%
25-30
20-25
15-25
Stroke
mm
16-22
11-16
8-16
Frequency
f
45-48
18-53
50-57
Water added
t/d
80-150
30-60
10-17
Transverse slope of Deck
°
2°30-4°30
1°30-3°30
1°-2°
Longitudinal slope of Deck
°
1.4
0.92
-
Beneficiation Area
7.6
7.6
7.6
Cross-section Shape of Deck

rectangular
sawtooth
triangle
Motor Power
KW
1.1
1.1
1.1
Transmission Mechanism
Eccentric linkage
Affordable Fiber Mini Shaking Table Gold Concentrator Table for Small Scale Operations 0
Affordable Fiber Mini Shaking Table Gold Concentrator Table for Small Scale Operations 1
Affordable Fiber Mini Shaking Table Gold Concentrator Table for Small Scale Operations 2
Affordable Fiber Mini Shaking Table Gold Concentrator Table for Small Scale Operations 3

Main Features of shaking table:


The Shaking Table has the advantages of good separation capacity, stable performance, high efficiency, smooth, lower noise, easy operation and maintenance, etc.

Shaking table is especially for tungsten ore with a variety of sulfide minerals. It has the following advantages compared with the gold table : it is easy to observe changes of slurry on shaking table; easy to operate; it has many different specifications for choosing.

It is proved by a large number of actual production data and feedback from the customer after-sales information that this gold shaking table is simple operation in production process. The separation effect is especially prominent for tungsten mine including sulfur and other Sulfide Minerals. Secondly, its capacity is larger than 6-S shaking table. Its overall production costs are much lower than 6-S shaking table.

Structure
Affordable Fiber Mini Shaking Table Gold Concentrator Table for Small Scale Operations 4

1. Head Motion


Gold shaking table cast iron to contain an oil reservoir for perfect splash lubricaion.

This feature protects the moving parts, reducing the operating and maintenance cost to minimum.


2. Deck: shaking Table have three distinct deck designs available.


Affordable Fiber Mini Shaking Table Gold Concentrator Table for Small Scale Operations 5

Course ore deck

(1). Course ore deck is designed for recovering particles size from 0.5 mm to 2 mm;

Affordable Fiber Mini Shaking Table Gold Concentrator Table for Small Scale Operations 6

Fine sand deck

(2). Fine sand deck is designed for recovering fine particles in the range of 0.074 mm to 0.5 mm;

Affordable Fiber Mini Shaking Table Gold Concentrator Table for Small Scale Operations 7

Slime deck

(3). Slime deck is designed for recovering super extremely fine particles in the range of 0.05 mm to 0.074 mm.

3. Base Support


Three styles of installing foundation of shaking table.
Affordable Fiber Mini Shaking Table Gold Concentrator Table for Small Scale Operations 8

(1) Ordinary foundation

Affordable Fiber Mini Shaking Table Gold Concentrator Table for Small Scale Operations 9

(2) 10# Small Channel Steel Support

Affordable Fiber Mini Shaking Table Gold Concentrator Table for Small Scale Operations 10

(3) 28# Big Channel Steel Support

Detailed Images
Affordable Fiber Mini Shaking Table Gold Concentrator Table for Small Scale Operations 11
Our Service

1. Pre-sale service:

1) Sinolion will provide production line design, quotation sheet, working sites video, machinery photos, sample testing(gold ore, tin ore , iron ore, tungsten processing in laboratory).

2) Welcome to visit us at any time, we will pick you up.

2. Sale service:

1) Keep clients updated when our company gets advance payment.

2) Confirm production details with clients.

3) Take photos and send all pictures to customers during production.

4) Inspection and testing the product before delivery;

5) Clients are welcome to inspect the equipment when the equipment are ready to delivery.

6) logistics service if needed.

3. After Sale service:

1) Provide foundation drawing to the clients for installation.

2) Besides, our engineers are available to help with installation and workers training.

3) Repairing and maintenance if any problem during the warranty.

4) Spare parts and wearing parts will be offered with production cost in 10 years.
