Professional Industrial Spiral Sand and Gravel Washer Machines for Sand Washing Plant
Product Details:
| Place of Origin: | Henan, China |
| Brand Name: | Sinolion |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 unit |
|---|---|
| Price: | $1,500.00/sets >=1 sets |
|
Detail Information |
|||
| Applicable Industries: | Energy & Mining | Showroom Location: | Canada, United Kingdom, United States, Brazil, Mexico, Russia, Australia |
|---|---|---|---|
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 1 Year |
| Core Components: | Motor | Condition: | New |
| Motor Type: | AC Motor | Capacity(t/h): | 5-100TPH |
| Dimension(L*W*H): | Based On Different Model | Weight: | 2.7 KG |
| Warranty: | One Year | Application: | Gravel, Stone, Sand, Mica, Pebble, Rock |
| Spiral Blade Material: | Steel, Stianless Steel(or As Client Request) | Spare Parts: | Spiral Blade |
| Flow Chart And Foundation: | Supply By Seller(or As Client Request) | Operation: | Automatically |
| Motor Brand: | Chinese Famous Brand(or As Client Request) | Related Product: | Belt Conveyor, Water Pump, Hopper |
| Test & Installation: | Professional Engineer Supplies Any Help | Color: | Yellow, White, Red, Blue, Gray( Or As Client Request) |
| Product Name: | Spiral Sand And Gravel Washer Machines Price For Sand Washing Plant | ||
Product Description
Introduction of spiral gravel washer machines:
Spiral sand washer is used for separating and cleaning soil in sand stone powder, with sealing structure, reliable transmission device. It is widely used for cleaning materials in the following industries: quarry, minerals, building materials, transportation, chemical industry, water conservation and hydropower, cement mixture station, etc.
Characteristics and advantages of spiral gravel washer machines:
FG series sand washer has the characteristics of reasonable structure, convenient maintenance, high output, low power consumption, and high degree of cleanness.
Working Principle of gravel washer machines:
5. The spiral slice agitates uniformly to filter the water and remove impurities to enhance transportation efficiency.
Spiral gravel washer machines technical parameters:
| Model | Spiral diameter (mm) | Capacity(t/h) | Power |
| FG-50 | 500 | 12-20 | 5.5 |
| FG-75 | 750 | 40-55 | 7.5 |
| FG-100 | 1000 | 60-75 | 11 |
| FG-120 | 1200 | 80-100 | 15 |
| FG-150 | 1500 | 100-130 | 18.5 |
| FG-200 | 2000 | 130-160 | 22 |
| 2FG-100 | 1000 | 120-150 | 7.5x2 |
| 2FG-120 | 1200 | 160-200 | 11x2 |
Question 1: What’s the delivery time after I pay the deposit?
Answer: We will delivery the goods within 10-15 working days after receipt of the prepayment.
Question 2: Is mineral samples analysis available?
Answer: Sure, we supply samples analysis service for free. After the testing, we will give you the reasonable flow chart, suitable solution and equipment selection.
Question 3: Do you have client in my country?
Answer: Our products have exported to Malaysia, Indonesia, the Philippines, Vietnam, Myanmar, Korea, Singapore, Thailand, Mongolia, Ghana, Sudan, Serbia, Kazakhstan, Canada, Nigeria, Australia, Chile, Brazil, Columbia, Ecuador, Peru, Bolivia, etc
Question 4: How long of your machine quality guarantee terms?
Answer: Quality guarantee time is one year(wearing parts excluded).
