River Gold Trommel Screen for Mobile Small Gold Washing Equipment Depends on Model

River Gold Trommel Screen for Mobile Small Gold Washing Equipment Depends on Model

Product Details:

Place of Origin: Henan, China
Brand Name: Sinolion
Certification: ISO9001:2008

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: $4,080.00 - $24,000.00/sets
Packaging Details: All products will be processed to be rustproof and moisture proof before delivery. <br>20GP container or 40GP container <br>Equipment is packed with plastic wrap or steel case, depends on machine weight. <br>Motor is packed with steel case or wooden case.
Supply Ability: 50 Set/Sets per Month gold trommel for sale
Get Best Price Contact Now

Detail Information

Applicable Industries: Energy & Mining Showroom Location: None
Condition: New Type: Gravity Separator
Production Capacity: 98% Voltage: 380V/415V/440V
Dimension(L*W*H): As Per Different Model Weight: 2200 KG
Warranty: 1 Year Marketing Type: New Product 2020
Machinery Test Report: Provided Video Outgoing-inspection: Provided
Warranty Of Core Components: 1.5 Years Core Components: Bearing, Motor, PLC, Engine
Key Selling Points: Long Service Life Model: Gold Trommel For Alluvial Gold Wash Plant
Power: 5.5KW, 7.5KW, 11KW Dimension: Depends On Model
Application: Alluvial Gold Washing, Diamond, Rock, Soil, River Gold Installation: Supply Manual To Guide User
Capacity: 30-200 Tons Per Hour Feeding Size: Less Than 300mm
Discharge Size: Less Than 6mm Color: Yellow, White, Red, Blue, Gray( Or As Client Request)
Port: Qingdao, Tianjin, Lianyungang, Shanghai Guangzhou( As Client Request)

Product Description

Product Description

The gold machine movement is very convenient and can be applied to a variety of terrain, terrain is soft sandy or hard rock, stone or more can be applied, and must also very convenient, can satisfy the development of mining while walking. This method has a good effect on a large range of sand gold mining areas, which can save more production costs and increase mining efficiency.



Outstanding Advantages::
1.Barrel of trommel screen includes infeed diverter rings for minimizing the material loss.
2.Modular replaceable screen segments according to customer requirements. Customer choose woven wire and plate per their demands.
3.Trommel screens allow access to screens for maintenance and inspection.
4.Alternative discharge belt conveyor, can supply diverse belt conveyor for discharging material of after screened.
5.The main frame of heavy steel structure is designed with components for minimizing material accumulation.
6.Heavy duty structure includes integrated leveling system, it is easy to install.
7.Nylon bristle, cleaning device can be changeable quickly and individually for minimizing downtime of equipment, and that improving efficiency.
8.Trunnion components mounted to heavy duty roller bearings to prolong service life.
9.Low stress welded, structural tubing lifter assemblies
10.Alternative feed and discharge chutes.





River Gold Trommel Screen for Mobile Small Gold Washing Equipment Depends on Model 0

technical parameters



Model

Capacity

(t/h)

Power

(kw)

Diameter

(mm)

Length

(mm)

Discharge

(mm)

Input

(mm)

Dimension

(mm)

YGTS0520

5-10

3

500

2000

0-100

≤300

3390×1100×1640

YGTS1020

20-30

4.0

1000

2000

0-100

≤300

3390×1400×2140

YGTS1225

30-50

5.5

1200

2500

0-100

≤300

4146×1600×2680

YGTS1545

50-120

11

1500

4500

0-100

≤400

8160×2300×2500

YGTS1548

80-150

15

1500

4800

0-100

≤400

8460×2300×2500

YGTS1848

100-200

15

1800

4800

0-100

≤400

8460×2300×2700

YGTS2060

200-350

30

2000

6000

0-100

≤400

9680×2300x3420



River Gold Trommel Screen for Mobile Small Gold Washing Equipment Depends on Model 1

River Gold Trommel Screen for Mobile Small Gold Washing Equipment Depends on Model 2 The gold washing machine can be used for gold washing and screening. The gold washing machine offer an expanded processing capacity that rivals all competitor mobile gold wash plant trommel equipment. The gold washing machine has an average of 100-300 m³/h OR 170-510 tons per hour based upon 1.7 tons of material weight per cubic meter conversion.

Input of raw materials
Raw materials inputted through the entrance of the hopper will be pushed into the trommel screen by the strong water pressure of the shower equipped in the hopper. Selection and cleaning of raw materials Raw materials of the gold washing machine will be cleaned and selected by the rotation of gold washing machine and by watering of the shower inside, run into the gold dust separate panel.

River Gold Trommel Screen for Mobile Small Gold Washing Equipment Depends on Model 3
River Gold Trommel Screen for Mobile Small Gold Washing Equipment Depends on Model 4

Motor
Brand of driving device can choose on your request.
International brands like SEW, ABB, SUMITOMO, SIEMENS.China brand like Yutong,Tailong,Guomao,Taixing,Nangaochi.
Powerful enclosed and compact efficient motor drive
Shaft mounted and underslung gearbox reducer.
Optimization YOX & YOT constant filling hydrodynamic coupling. Good balance and strong braking force Brake.



Screen mesh
The mesh hole is not easy to block.
Screen mesh with special material wire mesh
High screening efficiency,
Bold material, heavy bearing, long use time
It is easy to replace the screen with a bead
According to the characteristics of the screening material, a fully enclosed structure or an open structure can be selected.



River Gold Trommel Screen for Mobile Small Gold Washing Equipment Depends on Model 5
River Gold Trommel Screen for Mobile Small Gold Washing Equipment Depends on Model 6

Gold washing mat
Collecting of gold dust separated Soil and sands with lighter specific gravity will flow away but gold dusts with greater specific gravity will be staying in the gathering mat to be collected.

Fine Size Gold Recovery System
Name: Knelson type gold centrifugal concentrator Processing capacity: 15tph-60tph dry solids

Quantity: 2- 4 pcs
Remark: Fully continuous type
Function: for fine size dust gold recovery (-6mm)
Recovery Rate: 99%



River Gold Trommel Screen for Mobile Small Gold Washing Equipment Depends on Model 7
River Gold Trommel Screen for Mobile Small Gold Washing Equipment Depends on Model 8 Gold shaking table is a gravity dressing machine,which has high separation efficiency.It is designed to wet gravity-based separation of minerals and other granular materials.
Gold shakint table does not need reagent compared with the traditional process as well as it can make the materials concentrated at one time.
Gold shaking table is mainly composed of bed head, electromotor, adjusting gradient device, bed surface, ore chute, water chute, rifle bar and lubricating system

Powering system
Name: Cummins diesel engine generator set
Power: 50Kw-350Kw
Brand: Cummins, Weichai, or as required
Function: supplying power to all the systems



River Gold Trommel Screen for Mobile Small Gold Washing Equipment Depends on Model 9
River Gold Trommel Screen for Mobile Small Gold Washing Equipment Depends on Model 10

Mercury Amalgamator
Type: drum type
Working mode: amalgamator + distiller retort
Function: With the help of Mercury, to extract allthe gold out from the concentrates that recoveredby the sluice and concentrators
Recovery rate: 100%

Gold Smelting Furnace
Capacity: 10-15kg per batch

Moulds: 100g; 200g; 500g; 1000g
Function: to smelting thegold sand and make
into final product of gold bars



River Gold Trommel Screen for Mobile Small Gold Washing Equipment Depends on Model 11





Packaging & Shipping

River Gold Trommel Screen for Mobile Small Gold Washing Equipment Depends on Model 12



if you need more photos and video , please click here to contact me :



Case

River Gold Trommel Screen for Mobile Small Gold Washing Equipment Depends on Model 13



if you need more photos and video , please click here to contact me :



Company Information

River Gold Trommel Screen for Mobile Small Gold Washing Equipment Depends on Model 14

River Gold Trommel Screen for Mobile Small Gold Washing Equipment Depends on Model 15River Gold Trommel Screen for Mobile Small Gold Washing Equipment Depends on Model 16
Sinolion company is willing to take full use of the new technology, dedicated to providing superior products with reliable quality, favorable prices and perfect service for users who need us to design, manufacture and install.Sinolion holding the concept of "To survive with quality and develop with credit". Our company strives to build a brand enterprise with satisfaction of customers. Let customers buy reassured and use comfortably! For users who ask us to design, manufacture and install formed coal production line, our company will provide satisfactory products with the latest technology, reliable quality, favorable price and perfect service, we welcome friends from all circles.

FAQ

Question 1: Can you give me a solution and quotation?

Answer: Absolutely sure, we can provide accurate solution and quotation, please give us background information, including, raw material, the capacity, max. input size, the output size, the usage of final products, etc.



Question 2: Way of payment
Answer: Welcome clients place the order by alibaba online one-touch! also offers various ways of payment, T/T, against copy of B/L, L/C, D/A, D/P, West union, etc. All can be negotiated.



Question 3: What’s the delivery time after I pay the deposit ?

Answer: Normal delivery time within 10 to 20 working days, complete production line or larger equipment may take longer. Exact delivery shall be confirmed when place the order.



Question 4: How long of your machine quality guarantee terms?

Answer: Equipment from Zhengzhou Sinolion Machinery Co., Ltd. with 18 months warranty, can be extended to 24 months as request.
