Product Details:

Place of Origin: Henan, China
Brand Name: Sinolion

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: $4,080.00/sets 1-1 sets
Packaging Details: All products will be processed to be rustproof and moisture proof before delivery. <br>20GP container or 40GP container <br>Equipment is packed with plastic wrap or steel case, depends on machine weight. <br>Motor is packed with steel case or wooden case.
Supply Ability: 100 Set/Sets per Month gold trommel screening plant
Get Best Price Contact Now

Detail Information

Applicable Industries: Energy & Mining Showroom Location: Canada, United States, South Africa, Nigeria
Condition: New Type: Gravity Separator
Production Capacity: 5-10t/h Voltage: 380V/415V/440V
Dimension(L*W*H): 3000x1000x1800mm Weight: 520 KG
Warranty: 1 Year Marketing Type: Ordinary Product
Machinery Test Report: Provided Video Outgoing-inspection: Provided
Warranty Of Core Components: 1 Year Core Components: Motor, Pump, Engine
Key Selling Points: Easy To Operate Product Name: Mobile Gold Trommel Screen
Installation: Supply Manual To Guide User Color: Yellow, White, Red, Blue, Gray( Or As Client Request)
Spare Parts Supplying: Lifelong Provide Certificate: CE
Feeding Size: Less Than 300mm Discharge Size: As Request
Cleaning System: Rubber Ball Screen Material: Steel Bar, Steel Plate Punch Hole, Steel Wire Woven
MOQ: 1Set Port: Qingdao, Tianjin, Lianyungang, Shanghai Guangzhou( As Client Request)

Product Description

Mobile Type Small Production Gold Trommel Screen With Traction Hook For Easy Handling 0
Mobile Type Small Production Gold Trommel Screen With Traction Hook For Easy Handling 1
Mobile Type Small Production Gold Trommel Screen With Traction Hook For Easy Handling 2
Hot Selling Products Mobile Type Small Production Capacity Collection Gold Trommel Screen With Traction Hook
Mobile Gold Mining Equipment Is Represented By Trommel Screen, Which Is Also Widely Used In Separation Technology. Its Working Principle Is To Control The Size Of Particle Size To Control The Separation Of Waste, Thus Improving The Separation Efficiency. The Advantages Of Small Trommel Screen Are Obvious, And It Is More Flexible And Convenient Than Large-scale Mobile Screen In Terms Of Movement. Trommel Screen Internal Equipment, The Main Roller Screen Shall Have Motor, Reducer, Roller Device, Frame, Seal Cover, Inlet And Outlet Composition. The Roller Device Is Tilted On The Rack And Passed Through The Drum Device. The Axles Are Connected Together To Drive The Drum Device To Rotate Around Its Axis.
Mobile Type Small Production Gold Trommel Screen With Traction Hook For Easy Handling 3
Mobile Type Small Production Gold Trommel Screen With Traction Hook For Easy Handling 4
Mobile Type Small Production Gold Trommel Screen With Traction Hook For Easy Handling 5
Mobile Type Small Production Gold Trommel Screen With Traction Hook For Easy Handling 6
Mobile Type Small Production Gold Trommel Screen With Traction Hook For Easy Handling 7

Structure and Principle

The Alluvial Gold Trommel Screen Machine Uses The Principle Of Gravity Separation, The Original Ore Through A Layer Of Screening And Classification Under The Impact Of Water Into The Agitation Sluice Chute For Next Step Coarse Separation, If There Is Capillary Gold In The Original Mine, Adding The Agitation Chute Fixed Chute In The Tail To Avoid Tails Running. If There Is Clay Mud In Original Ore, We Will Add Stirring In Front Of The Screen And Flushing Device In Screen Drum, So That The Unfavorable Factors Caused By High Mud Content Can Be Solved Well, And Can Be Adjusted According To Ore Body Condition And Site.
1. Input Of Raw Materials Raw Materials Inputted Through The Entrance Of The Hopper Will Be Pushed Into The Trommel Screen By The Strong Water Pressure Of The Shower Equipped In The Hopper.
2. Selection And Cleaning Of Raw Materials Raw Materials Of The Trommel Screen Will Be Cleaned And Selected By The Rotation Of Trommel Screen And By Watering Of The Shower Inside, Run Into The Gold Dust Separate Panel.
3. Collecting Of Gold Dust Separated Soil And Sands With Lighter Specific Gravity Will Flow Away But Gold Dusts With Greater Specific Gravity Will Be Staying In The Gathering Mat To Be Collected.
Mobile Type Small Production Gold Trommel Screen With Traction Hook For Easy Handling 8
Product Name
Model
Capacity (t/h)
Power(kw)
Diameter(mm)
Length(mm)
Mobilel trommel screen
GMTS0519
5-10
1.5
500
1910
Mobile Type Small Production Gold Trommel Screen With Traction Hook For Easy Handling 9
Mobile Type Small Production Gold Trommel Screen With Traction Hook For Easy Handling 10
Mobile Type Small Production Gold Trommel Screen With Traction Hook For Easy Handling 11
Mobile Type Small Production Gold Trommel Screen With Traction Hook For Easy Handling 12
Mobile Type Small Production Gold Trommel Screen With Traction Hook For Easy Handling 13
Mobile Type Small Production Gold Trommel Screen With Traction Hook For Easy Handling 14
Mobile Type Small Production Gold Trommel Screen With Traction Hook For Easy Handling 15
Mobile Type Small Production Gold Trommel Screen With Traction Hook For Easy Handling 16
Mobile Type Small Production Gold Trommel Screen With Traction Hook For Easy Handling 17
Mobile Type Small Production Gold Trommel Screen With Traction Hook For Easy Handling 18
