5-10 Tons Small Blue Gold Separation Machine Mobile Trommel Screen for Ore Processing

5-10 Tons Small Blue Gold Separation Machine Mobile Trommel Screen for Ore Processing

Product Details:

Place of Origin: Henan, China
Brand Name: Sinolion
Certification: ISO CE

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: $4,080.00/sets 1-1 sets
Packaging Details: This gold mobile trommel screen 0519 will be processed to be rustproof and moisture proof before delivery.<br>20GP container or 40GP container<br>Equipment is packed with plastic wrap or steel case, depends on machine weight.<br>Motor is packed with steel
Supply Ability: 100 Set/Sets per Month gold mining trommel screening plant
Get Best Price Contact Now

Detail Information

Applicable Industries: Home Use, Energy & Mining Showroom Location: Canada, United States, Mexico, Colombia, Australia
Condition: New Type: Gold Mining Trommel Screen
Production Capacity: 5-10t/h Voltage: 380V/415V/440V
Dimension(L*W*H): 3000*1000*1800 Weight: 520 KG
Warranty: 1 Year Marketing Type: New Product 2022
Machinery Test Report: Provided Video Outgoing-inspection: Provided
Warranty Of Core Components: 1 Year Core Components: Motor, Engine
Key Selling Points: Easy To Operate Product Name: Gold Mining Trommel Screen 0519
Keywords: Gold Separation Machine Core Components: Motor
Installation: Supply Manual To Guide User Feeding Size: Less Than 300mm
Discharge Size: As Request MOQ: 1Set
Usage: Washing Gold Color: Yellow,white,fed,blue,gray( Or As Client Request)
Port: Qingdao, Tianjin, Lianyungang, Shanghai Guangzhou( As Client Request)

Product Description

5-10 Tons Small Blue Gold Separation Machine Mobile Trommel Screen for Ore Processing 0
5-10 Tons Small Blue Gold Separation Machine Mobile Trommel Screen for Ore Processing 1
5-10 Tons Small Blue Gold Separation Machine Mobile Trommel Screen for Ore Processing 2
5-10 Tons Small Ore Processing Mobile Equipment Nugget Gold Washing Machine Gold Mining Trommel Screen
Mobile Gold Mining Equipment Is Represented By Trommel Screen, Which Is Also Widely Used In Separation Technology. Its Working Principle Is To Control The Size Of Particle Size To Control The Separation Of Waste, Thus Improving The Separation Efficiency.
The Advantages Of Small Trommel Screen Are Obvious, And It Is More Flexible And Convenient Than Large-scale Mobile Screen In Terms Of Movement. Trommel Screen Internal Equipment, The Main Roller Screen Shall Have Motor, Reducer, Roller Device, Frame, Seal Cover, Inlet And Outlet Composition. The Roller Device Is Tilted On The Rack And Passed Through The Drum Device. The Axles Are Connected Together To Drive The Drum Device To Rotate Around Its Axis.
5-10 Tons Small Blue Gold Separation Machine Mobile Trommel Screen for Ore Processing 3
5-10 Tons Small Blue Gold Separation Machine Mobile Trommel Screen for Ore Processing 4
5-10 Tons Small Blue Gold Separation Machine Mobile Trommel Screen for Ore Processing 5

Structure and Principle:

The Alluvial Gold Trommel Screen Machine Uses The Principle Of Gravity Separation, The Original Ore Through A Layer Of Screening And Classification Under The Impact Of Water Into The Agitation Sluice Chute For Next Step Coarse Separation, If There Is Capillary Gold In The Original Mine, Adding The Agitation Chute Fixed Chute In The Tail To Avoid Tails Running. If There Is Clay Mud In Original Ore, We Will Add Stirring In Front Of The Screen And Flushing Device In Screen Drum, So That The Unfavorable Factors Caused By High Mud Content Can Be Solved Well, And Can Be Adjusted According To Ore Body Condition And Site.
1. Input Of Raw Materials Raw Materials Inputted Through The Entrance Of The Hopper Will Be Pushed Into The Trommel Screen By The Strong Water Pressure Of The Shower Equipped In The Hopper.
2. Selection And Cleaning Of Raw Materials Raw Materials Of The Trommel Screen Will Be Cleaned And Selected By The Rotation Of Trommel Screen And By Watering Of The Shower Inside, Run Into The Gold Dust Separate Panel.
3. Collecting Of Gold Dust Separated Soil And Sands With Lighter Specific Gravity Will Flow Away But Gold Dusts With Greater Specific Gravity Will Be Staying In The Gathering Mat To Be Collected.
5-10 Tons Small Blue Gold Separation Machine Mobile Trommel Screen for Ore Processing 6
Product Name
Model
Capacity (t/h)
Power(kw)
Diameter(mm)
Length(mm)
gold trommel screen
GMTS0519
5-10
1.5
500
1910
5-10 Tons Small Blue Gold Separation Machine Mobile Trommel Screen for Ore Processing 7
5-10 Tons Small Blue Gold Separation Machine Mobile Trommel Screen for Ore Processing 8
5-10 Tons Small Blue Gold Separation Machine Mobile Trommel Screen for Ore Processing 9
5-10 Tons Small Blue Gold Separation Machine Mobile Trommel Screen for Ore Processing 10
5-10 Tons Small Blue Gold Separation Machine Mobile Trommel Screen for Ore Processing 11
5-10 Tons Small Blue Gold Separation Machine Mobile Trommel Screen for Ore Processing 12
5-10 Tons Small Blue Gold Separation Machine Mobile Trommel Screen for Ore Processing 13
5-10 Tons Small Blue Gold Separation Machine Mobile Trommel Screen for Ore Processing 14
