Product Details:

Place of Origin: Henan, China
Brand Name: Sinolion
Certification: CE

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: $4,080.00 - $17,900.00/sets
Packaging Details: All products will be processed to be rustproof and moisture proof before delivery. <br>20GP container or 40GP container <br>Equipment is packed with plastic wrap or steel case, depends on machine weight. <br>Motor is packed with steel case or wooden case.
Supply Ability: 50 Set/Sets per Month gold trommel screening plant
Get Best Price Contact Now

Detail Information
Applicable Industries: Energy & Mining Showroom Location: United States, Italy, Germany, Mexico, Russia, UAE, Colombia, Australia
Condition: New Type: Gravity Separator
Production Capacity: 5-200t/h Voltage: 220V/380V
Dimension(L*W*H): According To Different Models Weight: 2200 KG
Warranty: 1 Year Marketing Type: New Product 2023
Machinery Test Report: Provided Video Outgoing-inspection: Provided
Warranty Of Core Components: 1 Year Core Components: Bearing, Motor, Gear, Engine
Key Selling Points: Easy To Operate Product Name: Mobile Gold Trommel Scsreen
Screen Material: Steel Bar, Steel Plate Punch Hole, Steel Wire Woven, Stainless Steel Feeding Size: Less Than 300mm
Dimension: According To Capacity Discharge Size: As Request
After Sale Service: One Year Color: Yellow, White, Red, Blue, Gray( Or As Client Request)
Installation: Supply Manual To Guide User MOQ: 1Set
Port: Qingdao, Tianjin, Lianyungang, Shanghai Guangzhou( As Client Request)

Product Description

High Capacity Mobile Gold Mine Equipment Easy to Operate Gold Washiner Plant Machine 0
High Capacity Mobile Gold Mine Equipment Easy to Operate Gold Washiner Plant Machine 1
High Capacity Mobile Gold Mine Equipment Easy to Operate Gold Washiner Plant Machine 2
Hot Sales Mobile Gold Mine Equipment Gold Washiner Plant Machine
The trommel screen, also known as the rotary screen, is a mechanical screening machine for separating mineral ore materials, and is mainly used in the screening industry of gold beneficiation plants. The trommel screen controls the beneficiation according to the particle size, and the separation accuracy is high.
Gelin Provide different specifications trommel screen with Stationary and Mobile Type;
Sieve size, Layer quantity, Power type, Wheel type... can be customization as required.
Features
1.Customization available:The length diameter of the drum, screen mesh, mesh layer, portable or stationary etc can be customized.
2.Large capacity range from 5t/h to 200t/h;.
3.Easy move around,operation,and maintenance;
4.Low investment,long service life.
High Capacity Mobile Gold Mine Equipment Easy to Operate Gold Washiner Plant Machine 3
High Capacity Mobile Gold Mine Equipment Easy to Operate Gold Washiner Plant Machine 4
High Capacity Mobile Gold Mine Equipment Easy to Operate Gold Washiner Plant Machine 5
High Capacity Mobile Gold Mine Equipment Easy to Operate Gold Washiner Plant Machine 6
High Capacity Mobile Gold Mine Equipment Easy to Operate Gold Washiner Plant Machine 7

Structure and Principle

The cylinder of the drum screen is generally divided into several sections, depending on the specific circumstances, the screen holes from small to large arrangements, each section on the same size of the screen hole. The trommel screen mainly comprises a motor, a reducer, a roller device, a machine frame, a sealing cover and an inlet and outlet.
When feeding ore material into the drum, the material begins to rotate and tumble inside the drum before calming down
intermittently. This revolution is completed along the length of the drum. Hence, the larger ones tumble to their exit through the rear end of the drum while the finer materials pass through the screen openings and then pass to the downstream process equipment, which can be in various forms, such as gold concentrator, spiral chutes, jig machines, Sluice box with carpet etc.Separation of different materials is done efficiently.

High Capacity Mobile Gold Mine Equipment Easy to Operate Gold Washiner Plant Machine 8
Product Name
Gold Trommel Screen
Model
GMTS0519
GMTS1020
GMTS1225
GMTS1548
GMTS1848
Capacity (t/h)
5-10
10-30
30-50
80-150
100-200
Power(kw)
1.5
4
5.5
11
15
Diameter(mm)
500
1000
1200
1500
1800
Length(mm)
1910
2000
2500
4800
4800
Product Details
High Capacity Mobile Gold Mine Equipment Easy to Operate Gold Washiner Plant Machine 9
High Capacity Mobile Gold Mine Equipment Easy to Operate Gold Washiner Plant Machine 10
High Capacity Mobile Gold Mine Equipment Easy to Operate Gold Washiner Plant Machine 11
High Capacity Mobile Gold Mine Equipment Easy to Operate Gold Washiner Plant Machine 12
High Capacity Mobile Gold Mine Equipment Easy to Operate Gold Washiner Plant Machine 13
High Capacity Mobile Gold Mine Equipment Easy to Operate Gold Washiner Plant Machine 14
High Capacity Mobile Gold Mine Equipment Easy to Operate Gold Washiner Plant Machine 15
High Capacity Mobile Gold Mine Equipment Easy to Operate Gold Washiner Plant Machine 16
High Capacity Mobile Gold Mine Equipment Easy to Operate Gold Washiner Plant Machine 17
High Capacity Mobile Gold Mine Equipment Easy to Operate Gold Washiner Plant Machine 18
High Capacity Mobile Gold Mine Equipment Easy to Operate Gold Washiner Plant Machine 19
High Capacity Mobile Gold Mine Equipment Easy to Operate Gold Washiner Plant Machine 20
Packing & Delivery
High Capacity Mobile Gold Mine Equipment Easy to Operate Gold Washiner Plant Machine 21
High Capacity Mobile Gold Mine Equipment Easy to Operate Gold Washiner Plant Machine 22
High Capacity Mobile Gold Mine Equipment Easy to Operate Gold Washiner Plant Machine 17
Application
High Capacity Mobile Gold Mine Equipment Easy to Operate Gold Washiner Plant Machine 24
High Capacity Mobile Gold Mine Equipment Easy to Operate Gold Washiner Plant Machine 25
High Capacity Mobile Gold Mine Equipment Easy to Operate Gold Washiner Plant Machine 26
High Capacity Mobile Gold Mine Equipment Easy to Operate Gold Washiner Plant Machine 27
High Capacity Mobile Gold Mine Equipment Easy to Operate Gold Washiner Plant Machine 28
High Capacity Mobile Gold Mine Equipment Easy to Operate Gold Washiner Plant Machine 29
High Capacity Mobile Gold Mine Equipment Easy to Operate Gold Washiner Plant Machine 30
High Capacity Mobile Gold Mine Equipment Easy to Operate Gold Washiner Plant Machine 31
High Capacity Mobile Gold Mine Equipment Easy to Operate Gold Washiner Plant Machine 32
High Capacity Mobile Gold Mine Equipment Easy to Operate Gold Washiner Plant Machine 33
