Environmental Laboratory Ball Press Machine Small Briquette Compressor for Laboratory
Product Details:
| Place of Origin: | China |
| Brand Name: | Sinolion |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 unit |
|---|---|
| Price: | $2,200.00/sets >=1 sets |
|
Detail Information |
|||
| Applicable Industries: | Energy & Mining | Showroom Location: | Canada, United States, Brazil, Mexico, Russia, Kenya, Sri Lanka, Australia |
|---|---|---|---|
| Condition: | New | Type: | Roller Crusher |
| Application: | Chemical Industry, Stone, Ore, Glass, Coal, Fuel, Metallurgy,chemical Industry,coal And Refractories Industries | Motor Type: | AC Motor |
| Capacity(t/h): | 1-30t/h | Dimension(L*W*H): | As Per Different Model |
| Weight: | 720 KG | Warranty: | 1 Year |
| Marketing Type: | New Product 2020 | Machinery Test Report: | Provided |
| Video Outgoing-inspection: | Provided | Warranty Of Core Components: | 1 Year |
| Core Components: | Motor | Key Selling Points: | Easy To Operate |
| Product Name: | Laboratory Ball Press Machine Small Briquette Machine Equipment | Keyword: | Small Briquette Machine Equipment |
| Voltage: | 380v 415v | Material Moisture: | Less Than 50% |
| Color: | Client's Required | Installation: | Under Engineers Guidance Use Briquette Machine |
| Roller Diameter: | 290-1000mm | Briquette Shape: | Oval, Pillow And Oblate Iron Briquettes Etc |
| Material Size: | Coal Size Less Than 5mm | ||
Product Description
The small briquette briquetting machine is powered by an electromagnetic speed-regulating motor, and is transmitted to the driving shaft through a pin coupling through a belt pulley and a cylindrical gear reducer. The driving shaft and the driven shaft ensure synchronous operation through open gears. A hydraulic device is installed behind the passive bearing seat. The screw feeding device is driven by an electromagnetic speed-regulating motor, and is rotated by a belt pulley and a worm reducer to force the material to be pressed into the main feed inlet. Due to the constant torque characteristic of the electromagnetic speed-regulating motor, when the pressure of the screw feeder is equal to the amount of material required by the host, a constant supply pressure can be maintained to stabilize the pellet quality. If the feeding amount is too large, the electric power of the feeding device will be overloaded; if the feeding amount is too small, the ball will not be formed. Therefore, skilled operation techniques are an important condition to ensure the normal operation of briquette briquette machine.
| Model | XM290 |
| Reducer | ZQ350 |
| Roller Size | Φ290 |
| Power (Kw) | 5.5 |
| Yield (t/h) | 0.8-2 |
| Roller Material | 65Mn |
| Roller pressure (t/cm) | 1 |
Zhengzhou Sinolion Machinery Co., Ltd. is a high-tech company which professional manufacturing the production of briquette equipment, stone crusher and screening equipment. After 30 years of development, Sinolion is now setting up branches, integrating engineering, trade, research and development, production and sale to develop to be a large sized enterprise. Sinolion has modern standard workshops, as well as advanced technology and testing equipment. Extensively cooperating with coal research institutions and other research departments, Sinolion has continuously improved product values and performance. Now, 10, 000-300, 000 tons briquette production lines are renowned in domestic and foreign markets, and Sinolion products have been exported to Serbia, The United Kingdom, Turkey, Malaysia, Indonesia, Kazakhstan, Vietnam, North Korea, Egypt, Mexico, Ghana and other countries and regions.
Packing Details : All products will be processed to be rustproof and moisture proof before delivery.
20GP container or 40GP container
Equipment is packed with plastic wrap or steel case, depends on machine weight.
Motro is packed with steel case or wooden case. Control panel is packed with steel case. Loading container in factory.
Delivery Details : 15-25 days after confirming order,detail delivery date should be decided according to production season and order quantity.
Q:How do I choose a suitable briquette machine for my project?
A: In your first inquiry, please offer us information about your raw materials, its size, moisture, and the shape of final briquettes you required, also tell the output per hour you required
Q: What is the binder in process?
A: It is depend on the properties of your raw materials and also usage of briquettes. We have some formula of binders for some of raw materials, we would like to share them to our customers.
Q: How long of your machine quality guarantee terms ?
A: Quality guarantee time is one year(wearing parts excluded).
Q: After ordered a briquette machine, how do we slove the equipment installing?
A: For a small single machine, we offer you user manual, the user will install and commissioning following operating introduction. A complete production line, we will send our engineer to workplace to help with install and commissioning untill machines work normally.
| | |
