Small Processing Capacity Mobile Rotary Screening Equipment with High Recovery Rate
Product Details:
| Place of Origin: | Henan, China |
| Brand Name: | Sinolion |
| Certification: | CE |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 unit |
|---|---|
| Price: | $4,100.00/sets 1-1 sets |
| Packaging Details: | All products will be processed to be rustproof and moisture proof before delivery. <br>20GP container or 40GP container <br>Equipment is packed with plastic wrap or steel case, depends on machine weight. <br>Motor is packed with steel case or wooden case. |
| Supply Ability: | 50 Set/Sets per Month mobile trommel screening |
|
Detail Information |
|||
| Applicable Industries: | Farms, Home Use, Other | Showroom Location: | Canada, United States, Germany, Colombia, Nigeria, Australia |
|---|---|---|---|
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2022 | Warranty Of Core Components: | 1 Year |
| Core Components: | Engine, Bearing, Motor | Condition: | New |
| Type: | Circular | Voltage: | 220V/380V/415V |
| Dimension(L*W*H): | 3.15*1.1*1.65m, As Per Different Model | Weight: | 520 KG |
| Warranty: | 1 Year | Product Name: | Mobile Screener |
| Feeding Size: | Less Than 300mm | Dimension: | Depends On Model |
| Installation: | Supply Manual To Guide User | Discharge Size: | Less Than 6mm |
| Feature: | High Recovery Rate Easy | After Sale Service: | Life-long Service |
| Color: | Yellow, White, Red, Blue, Gray( Or As Client Request) | Port: | Qingdao, Tianjin, Lianyungang, Shanghai Guangzhou( As Client Request) |
Product Description
Small Processing Capacity Mobile Screener Compost Rotary Screening Equipment
Small mobile trommel screen is a new screening equipment based on the advantages of similar products both at home and abroad. It has a simple structure and is easy to maintain. This equipment has no vibration and noise. With a high screen transmittance rate, it is particularly suitable for the screening of wet and sticky materials. The screen pores can never be blocked. block proof rotary drum screen is widely used for the screening and grading of coal, sand, gravel and other materials in electric power, mining, metallurgy, building materials, chemical and other industries.
Structure and Principle
The classification work of the mobile trommel screen is simple, mainly composed of the inlet and outlet, motor, reducer, frame, drum device, and sealing cover. The whole is in an inclined state with the ground, and the outside is sealed by a sealing isolation cover to prevent environmental pollution. The screening cylinder rotates at a certain number of revolutions through the variable speed reduction system, and the materials are separated through the screening cylinder from top to bottom. The fine material is discharged from the lower part of the front end of the screening cylinder, and the coarse material is discharged from the tail of the screening cylinder.
Model | Trommel diameter (mm) | Trommel length (mm) | Capacity (m3/h) | Weight (Kg) | Dimensions (L*W*H) |
MTS0818 | 800 | 1800 | ≤15 | 650 | 3.15*1.1*1.65 |
