Gold Machinery Equipment Rotary Mobile Gold Trommel Screen with High Productivity
Product Details:
| Place of Origin: | Henan, China |
| Brand Name: | Sinolion |
| Certification: | CE ISO |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 unit |
|---|---|
| Price: | $17,900.00/sets >=1 sets |
|
Detail Information |
|||
| Applicable Industries: | Manufacturing Plant, Energy & Mining | Showroom Location: | Canada, United States, Colombia, South Africa, Australia |
|---|---|---|---|
| Condition: | New | Type: | Gravity Separator |
| Production Capacity: | As Per Different Model | Voltage: | 380V/415V/440V |
| Dimension(L*W*H): | As Per Different Model | Weight: | 2200 KG |
| Warranty: | 1 Year | Marketing Type: | New Product 2022 |
| Machinery Test Report: | Provided | Video Outgoing-inspection: | Provided |
| Warranty Of Core Components: | 1 Year | Core Components: | Motor, Motor |
| Key Selling Points: | High Productivity, Mobile Gold Washing Trommel | Product Name: | Gold Mining Trommel Screen |
| Application: | Alluvial Gold Washing, Diamond, Rock, Soil, River Gold | Dimension: | Depends On Model |
| Feeding Size: | Less Than 300mm | Color: | Yellow, White, Red, Blue, Gray( Or As Client Request) |
| Capacity: | 30-150 Tons Per Hour | Discharge Size: | Less Than 6mm |
Product Description
High Effective Gold Machinery Equipment Rotary Mobile Gold Trommel Screen
Product Description
Features of our gold mining machinery equipment:
1. 100% high quality.
2. Lower initial investment costs (compare prices).
3. Operation cost saving (excellent durability and simple mechanical structure).
4. Reduce any additional costs in the future (high productivity and mobility).
5. GTS series can accurately select gold powder, the highest yield rate is 98%.
6. Long-term uninterrupted operation and strong gold collection ability.
7. Easy to operate and easy to maintain.
Gold mining trommel screen working principle:
1. Input of raw materials: Raw materials inputted through the entrance of the hopper will be pushed into the trommel screen by thestrong water pressure of the shower equipped in the hopper.
2. Selection and cleaning of raw materials: Raw materials of the trommel screen will be cleaned and selected by the rotation of trommel screen and by watering of the shower inside, run into the gold dust separate panel.
3. Collecting of gold dust separated Soil and sands with lighter specific gravity will flow away but gold dusts with greater
specific gravity will be staying in the gathering mat to be collected.
Main technical parameter
Model | Capacity (t/h) | Diameter (mm) | Length (mm) | Discharge (mm) | Input (mm) | Dimension ((mm) |
GMTS0519 | 5-10 | 500 | 1910 | 0-100 | ≤300 | 3000x1000x1800 |
GMTS1020 | 10-30 | 1000 | 2000 | 0-100 | ≤300 | 3390×1400×2140 |
GMTS1225 | 30-50 | 1200 | 2500 | 0-100 | ≤300 | 4146×1600×2680 |
GMTS1545 | 50-120 | 1500 | 4500 | 0-100 | ≤400 | 8160×2300×2500 |
GMTS1548 | 80-150 | 1500 | 4800 | 0-100 | ≤400 | 8460×2300×2500 |
GMTS1848 | 100-200 | 1800 | 4800 | 0-100 | ≤400 | 8460×2300×2700 |
GMTS2060 | 200-350 | 2000 | 6000 | 0-100 | ≤400 | 9680×2300x3420 |
