Roller forming methods divided into two types whole forging and casting, when casting, the roller has low-density and structure is rough but economical, Forging is shaping depending on air beating gravity, thus very substantially increased roller density, due to high density, it has effectively improved the wear resistance and extended service life. This types roller suitable for verious material and run reliable, is particularly suitable for materials processing briquetting.
 |
Supply whole life of kaolin clay briquetting machine for customer satisfaction
Product Details:
| Place of Origin: | Henan, China |
| Brand Name: | Sinolion |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 unit |
|---|---|
| Price: | $2,000.00/sets >=1 sets |
|
Detail Information |
|||
| Type: | Briquette Machines | Applicable Industries: | Manufacturing Plant, Energy & Mining |
|---|---|---|---|
| Weight (KG): | 800 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 1 Year |
| Core Components: | Bearing, Gearbox, Motor, Gear | Condition: | New |
| Production Capacity: | 1-30t/h Iron | Motor Type: | AC Motor |
| Dimension(L*W*H): | Based On Different Model | Warranty: | 1 Year |
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas | Briquette Shape: | Oval, Pillow And Oblate |
| Roller Diameter: | 290-1000mm | Roller Material: | 65Mn/9Cr2Mo |
| Applicable Material: | Kaolin Clay ,Coal, Charcoal, Carbon Black, Coke, Iron,powder Etc | Material Size: | Less Then 5mm |
| Material Moisture: | Less Then 18% | Spare Parts: | Supply Whole Life Of Kaolin Clay Briquette Machine |
| Service Life: | Supply Whole Life Of Kaolin Clay Briquette Machine | Product Name: | Kaolin Clay Briquette Machine |
Product Description
Product Description
Kaolin powder briquette machine Application
Sinolion Company's SLB series kaolin clay powder briquette machine also named kaolin clay ball press machine, kaolin clay briquetting machine,kaolin clay briquette press machine, the kaolin clay powder briuqette machine can used to press various powders such as kaolin clay powder coal powder,charcoal powder, iron powder, coking coal, slag, oxidation iron sheet, carbon dust, gypsum, tailings, sludge, kaolin, active carbon and burnt powder, etc.
Kaolin clay powder briquette machine also applies on the industries such as refractory material, electric power plant, metallurgy, chemical industry, energy, transportation and heating, etc.
Sinolion kaolin clay briquette machine / kaolin clay powder ball press machine / kaolin clay briquetting machine
sinolion kaolin clay powder briquette machine main Features
1.High-Density kaolin clay powder briquette machine;
3.High briquetting ratio
4.Double rollers mine kaolin clay powder briquetting press machine
5.High pressure mine kaolin clay powder briquetting press machine
6.Durable&energy-saving kaolin clay powder briquetting machine
7.Different design according to your place.
Detailed Images
kaolin clay Briquette machine roller
kaolin clay Briquette Machine roller making
Roller material: 65Mn/9Cr2Mo
The diameter of roller based on kaolin clay briquette machine model, our engineer will design and choose suitable kaolin clay briuqette machine according to customer's actual demands.
The kaolin clay briquette shape can be oval, oblate and pillow shape etc.
The size of final kaolin clay briquette between 20-75mm
kaolin clay Briquette machine production line
Before briquetting, the raw materials should be in 0-5mm, the water content of raw materials should be 8-15%, aslo some raw materials maybe need binder in process,so in general the complete briquettes production line include Drying --- Hopper --- Crusher--- Mixer--- Briquette Machine--- Briquette--- Dryers.
Our engineer will choose which machine need in the briuqette production line together with client.
kaolin clay briquette machine application materials
The material wich can use kaolin clay briquette machine to press briquette including many industries.
Raw material size: 0-5mm
Raw material moisture:8-13%
1.Coal 2.Charcoal 3.Desulfurization Gypsum 4 charcoal
5.carbon black 6.manganese 7.light burning magnesium
8.clay 9.copper powder 10.iron powder (fines) 11.iron oxide skin 12.mill scale 13.lime powder 14.sludge 15.silicon carbide
16.gypsum 17.coke coal etc.
Working Principle
kaolin clay Briquette machine working principle
This series kaoline clay briquetting machine will pass the power on to the two pressure roller through the reducer.The two sides and roll rotation, in both the rotating roll,Natural materials to enter the briquette roll mode,with the roll rotation, material pressure on a small become larger, When the material to the two rollers rotating line contac tpoint, the pressure of materials has reached the peak. Tremendous pressure in the role of line, the materials become a finished briquette from powder.
Our Service
kaolin clay briquette machine production line
Pre-Sales Service
* Inquiry and consulting support.
* Process flowchart design and confirm.
* Sample testing support.
* View our Factory.
kaolin clay briquette machine roller drawings
After-Sales Service
* Supply all machine's foundation drawings
* Supply Training how to instal and training use the machine.
* Engineers available to service machinery overseas.
* Parts can be replaced on favorable payment long-term
Packing & Delivery
Clients Working Site
kaolin powder briquette machine production line No.1
kaolin powder briquette machine production line No.2
Final briquette out from briquette mesh belt dryer
Sinolion Company
Zhengzhou Sinolion Machinery Co.,Ltd
Zhengzhou Sinolion Machinery Co., Ltd. is a high-tech Company which professional manufacturing the production of briquette equipment, building material equipment, and mining machinery.
we will continue to adhere to "Quality is our eternal pursuit and pride", create new glories with customers! Welcome to SINOLION for visiting and seeking common development.
