Technology Small Scale Mobile Placer Gold Washing Machine for Ghana Australia Bolivia
Product Details:
| Place of Origin: | Henan, China |
| Brand Name: | Sinolion |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 unit |
|---|---|
| Price: | $4,080.00 - $24,000.00/sets |
|
Detail Information |
|||
| Applicable Industries: | Energy & Mining | Showroom Location: | None |
|---|---|---|---|
| Condition: | New | Type: | Gravity Separator |
| Production Capacity: | 98% | Voltage: | 380V/415V/440V( As Client Request) |
| Dimension(L*W*H): | As Per Different Model | Weight: | 2200 KG, 6500kg |
| Warranty: | 24 Months Excluding Spare Parts | Marketing Type: | New Product 2021 |
| Machinery Test Report: | Provided | Video Outgoing-inspection: | Provided |
| Warranty Of Core Components: | 1 Year | Core Components: | Gearbox |
| Key Selling Points: | Placer Gold Washing Machine | Application: | Alluvial Gold Washing, Diamond, Rock, Soil, River Gold |
| Model: | Placer Gold Washing Machine | Dimension: | 5600x2015x2010mm |
| Installation: | Supply Manual To Guide User | Capacity: | 30-200 Tons Per Hour |
| Feeding Size: | Less Than 300mm | Discharge Size: | Less Than 6mm |
Product Description
Placer gold washing machine:
Placer gold washing machine for sale description:
The placer gold trommel screen can be used for gold washing and screening. The gold trommel screen offer an expanded processing capacity that rivals all competitor mobile gold wash plant trommel equipment. The gold trammel screen has an average of 100-300 m³/h OR 170-510 tons per hour based upon 1.7 tons of material weight per cubic meter conversion.
Designing & Building Custom Placer Gold washing machine for sale:
Bring your mining details and we can design and build a plant to target your minerals. If you want assistance with getting your plant setup on site and operational, we provide those services based on decades of our successful mining.
Help us understand your situation by knowing your mining area. Carefully review graves and environment, along with the historical information.
Placer gold washing machine for river gold washing flow chart:
Input of raw materials through heavy equipment
Raw materials inputted through the entrance of the hopper will be pushed into the gold trommel screen by the strong water pressure of the shower equipped in the hopper.
Selection and cleaning of raw materials
Raw materials of the trommel screen will be cleaned and selected by the rotation of trommel screen and, by watering of the shower inside, run into the gold dust separate panel.
Collecting of gold dust separated
Soil and sands with lighter specific gravity will flow away but gold dusts with greater specific gravity will be staying in the gathering mat to be collected.
Placer gold trommel screen specifications:
| Model | Capacity (t/h) | Power (kw) | Diameter (mm) | Length (mm) | Discharger (mm) | Input Size (mm) | Dimension ((mm) |
| YGTS1020 | 20-30 | 4 | 1000 | 2000 | 0~100 | ≤300 | 3390×1400×2140 |
| YGTS1225 | 30-50 | 5.5 | 1200 | 2500 | 0~100 | ≤300 | 4146×1600×2680 |
| YGTS1545 | 50-120 | 11 | 1500 | 4500 | 0~100 | ≤300 | 8160×2300×2500 |
| YGTS1548 | 120-200 | 15 | 1500 | 4800 | 0~100 | ≤300 | 8460×2300×2500 |
| YGTS2060 | 200-300 | 22 | 2000 | 6000 | 0~100 | ≤300 | 9680×2300x3420 |
1. Pre-sale service:
1) Sinolion will provide production line design, quotation sheet, working sites video, machinery photos, sample testing(gold ore, tin ore , iron ore, tungsten processing in laboratory).
2) Welcome to visit us at any time, we will pick you up.
2. Sale service:
1) Keep clients updated when our company gets advance payment.
2) Confirm production details with clients.
3) Take photos and send all pictures to customers during production.
4) Inspection and testing the product before delivery;
5) Clients are welcome to inspect the equipment when the equipment are ready to delivery.
6) logistics service if needed.
3. After Sale service:
1) Provide foundation drawing to the clients for installation.
2) Besides, our engineers are available to help with installation and workers training.
3) Repairing and maintenance if any problem during the warranty.
4) Spare parts and wearing parts will be offered with production cost in 10 years.
Question 1: What’s the delivery time after I pay the deposit ?
Answer: We will delivery the goods within 10-15 working days after receipt of the prepayment.
Question 2: Is mineral samples analysis available?
Answer: Sure, we supply samples analysis service for free. After the testing, we will give you the reasonable flow chart, suitable solution and equipment selection.
Question 3: Do you have client in my country?
Answer: Our products have exported to Malaysia, Indonesia, the Philippines, Vietnam, Myanmar, Korea, Singapore, Thailand, Mongolia, Ghana, Sudan, Serbia, Kazakhstan, Canada, Nigeria, Australia, Chile, Brazil, Columbia, Ecuador, Peru, Bolivia, etc
Question 4: How long of your machine quality guarantee terms ?
Answer: Quality guarantee time is one year(wearing parts excluded).
