Mobile Alluvial Gold Mining Equipments Trommel Screen Washing Plant with High Capacity

Mobile Alluvial Gold Mining Equipments Trommel Screen Washing Plant with High Capacity

Product Details:

Place of Origin: Henan, China
Brand Name: sinolion

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: $5,310.00 - $24,000.00/sets
Packaging Details: All products will be processed to be rustproof and moisture proof before delivery. <br>20GP container or 40GP container <br>Equipment is packed with plastic wrap or steel case or free fumigation wooden cases, depends on machine weight. <br>Motor is packed
Supply Ability: 40 Set/Sets per Month coke trommel screen
Get Best Price Contact Now

Detail Information
Applicable Industries: Building Material Shops, Construction Works , Energy & Mining Showroom Location: Canada, United States, Brazil, Mexico, Russia, Kenya, South Africa, Nigeria, Australia
Condition: New Type: Gravity Separator
Production Capacity: 98% Voltage: 380v/415v/440v
Dimension(L*W*H): Depends On Models Weight: 2200 KG
Warranty: 1 Year Marketing Type: New Product 2020
Machinery Test Report: Provided Video Outgoing-inspection: Provided
Warranty Of Core Components: 1 Year Core Components: Motor, Gear, PLC, Pressure Vessel, Engine, Gearbox
Key Selling Points: Automatic Power: 3-30KW
Screen Material: Steel Bar, Steel Plate Punch Hole, Steel Wire Woven, Stainless Steel Dimension: According To Capacity
Installation: Supply Manual To Guide User Capacity: 50-500 Tons Per Hour
Feeding Size: Less Than 300mm Discharge Size: As Request
Color: Yellow, White, Red, Blue, Gray( Or As Client Request) Product Name: Gold Ore Processing Plant Gold Mining Trommel Equipment For Sale
Keywords: Gold Ore Processing Plant Port: Qingdao, Dalian, Tianjin, Lianyungang, Dalian, Shanghai, Guangzhou( As Client Request)

Product Description

Mobile Alluvial Gold Mining Equipments Trommel Screen Washing Plant with High Capacity 0
Mobile Alluvial Gold Mining Equipments Trommel Screen Washing Plant with High Capacity 1
Mobile Alluvial Gold Mining Equipments Trommel Screen Washing Plant with High Capacity 2
THE GMTS1548 IS sinolion’S HIGHEST PRODUCTION GOLD WASH PLANTS TO DATE.
As one of the most durable and easy-to-operate gold wash plants on the market, the GMTS1548 features a fully welded tube construction, plant mounted generator to power screen deck, and large diameter skids for easy travel through wet terrain. This 1.7m*2m Shaker deck is capable of processing 80-150t per hour. Its quick clean-up system and highly mobile design makes the GMTS1548 very user friendly. The GMTS1548 is also available in various stationary configurations upon request.
↓↓↓
☛ Check out the GMTS1548 technical documents ☚
Mobile Alluvial Gold Mining Equipments Trommel Screen Washing Plant with High Capacity 3
Mobile Alluvial Gold Mining Equipments Trommel Screen Washing Plant with High Capacity 4
Mobile Alluvial Gold Mining Equipments Trommel Screen Washing Plant with High Capacity 5
Mobile Alluvial Gold Mining Equipments Trommel Screen Washing Plant with High Capacity 6

All-in-one Gold Mining Wash Plant

Each machine is a complete portable plant; there is no need for additional screens or sluice boxes! At the top is an extreme duty grizzly bar section that will take up to 24-inch rocks (91 cm). Classification begins when the material is placed on the grizzly bars, and high-pressure water separates the sub-1” (25.4 mm) material from the large rocks. Next, the screen deck further classifies the material, and sub-.25” (6.35 mm) material drops into the sluice boxes, remaining sub-1” material passes through the nugget trap into the final riffle set for capture, and larger rocks get discarded.
The sluicing system has three boxes that are independently adjustable, and with anywhere from 20 feet of sluice box on our 50-ton units to 40 feet of wider boxes on the 200-ton units, gold recovery is excellent. It often exceeds 95%, even with fine gold down to 200 mesh! What’s the key to such remarkable recovery? Science. This portable gold mining equipment was based on the performance data found in a landmark technical report on sluice boxes and riffle systems. Watch the video of our GMTS1548 wash plant.

Mobile Alluvial Gold Mining Equipments Trommel Screen Washing Plant with High Capacity 7
Product Name
Gold Trommel Screen
Model
GMTS0519
GMTS1020
GMTS1225
GMTS1548
GMTS1848
Capacity (t/h)
5-10
10-30
30-50
80-150
100-200
Power(kw)
1.5
4
5.5
11
15
Diameter(mm)
500
1000
1200
1500
1800
Length(mm)
1910
2000
2500
4800
4800
Mobile Alluvial Gold Mining Equipments Trommel Screen Washing Plant with High Capacity 8
Mobile Alluvial Gold Mining Equipments Trommel Screen Washing Plant with High Capacity 9
Mobile Alluvial Gold Mining Equipments Trommel Screen Washing Plant with High Capacity 10
Mobile Alluvial Gold Mining Equipments Trommel Screen Washing Plant with High Capacity 11
Mobile Alluvial Gold Mining Equipments Trommel Screen Washing Plant with High Capacity 2
Mobile Alluvial Gold Mining Equipments Trommel Screen Washing Plant with High Capacity 13
Mobile Alluvial Gold Mining Equipments Trommel Screen Washing Plant with High Capacity 14
Mobile Alluvial Gold Mining Equipments Trommel Screen Washing Plant with High Capacity 15
Mobile Alluvial Gold Mining Equipments Trommel Screen Washing Plant with High Capacity 16
Mobile Alluvial Gold Mining Equipments Trommel Screen Washing Plant with High Capacity 17
Mobile Alluvial Gold Mining Equipments Trommel Screen Washing Plant with High Capacity 18
Mobile Alluvial Gold Mining Equipments Trommel Screen Washing Plant with High Capacity 19
