Product Details:

Place of Origin: Henan, China
Brand Name: Sinolion

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: $1,500.00/sets >=1 sets
Get Best Price Contact Now

Detail Information
Applicable Industries: Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops Showroom Location: Canada, United Kingdom, United States, Germany, Brazil, Mexico, Russia, Australia
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Marketing Type: New Product 2020 Warranty Of Core Components: 2 Years
Core Components: Gearbox, Motor Condition: New
Type: Other Application: Other, Glass, Mulch, Organics, Bark, MSW, Plaster Board
Voltage: As Client Request Dimension(L*W*H): As Per Different Model
Weight: 2200 KG Warranty: 24 Months
Product Name: Coal Ash Screening Machine / Mill Trommel Screen For Sale Screen Material: Steel Bar, Steel Plate, Manganese Steel Wire Woven, Stainless Steel
Power: 3-45KW Dimension: 5600x2015x2010mm
Capacity: 1-200 Tons Per Hour Feeding Size: Less Than 300mm
Discharge Size: Less Than 6mm Or As Request Keyword: Coal Ash Screening Machine

Product Description

Automatic waste management sorting plant hot sale garbage recycling machine

Product Description

Trommel Vibrating Screen widely used for alluvial gold sieving and graded washing.It provides a simple, efficient and economical solution to upgrade a wide range of material and optimize the subsequent process steps of recovery. This method of screening helps to reduce operating and investment cost and to increase product quality, while allowing rapid and large volume processing.

1-200 Tons Per Hour Capacity Waste Garbage Recycling Line Coal Ash Screening Machine 0



• Trommel screens are constructed of high quality material, designed for high performance, high production rates, lower operating costs and lower maintenance.
• Downstream process equipment can be in various forms such as centrifugal Concentrator, spirals, jigs etc.
• After the materials are fed into the drum, the materials are classified, while the bigger materials flow forward along the inclination of drum and was classified through different mesh screens gradually. Classified small materials fell into respective bunker, and are delivered into finished product stack through manpower or belt conveyor. 1-200 Tons Per Hour Capacity Waste Garbage Recycling Line Coal Ash Screening Machine 1
1-200 Tons Per Hour Capacity Waste Garbage Recycling Line Coal Ash Screening Machine 21-200 Tons Per Hour Capacity Waste Garbage Recycling Line Coal Ash Screening Machine 3

1-200 Tons Per Hour Capacity Waste Garbage Recycling Line Coal Ash Screening Machine 4



Application:munlcpal solid waste,construction waste,stone,compost,wood ships,sawdust,soil,coal,river sand,refractory materials,chemiacal,etc



Technical Parameters



Model Capacity (t/h) Motor (kw) Drum size (mm) Feed Size (mm) Overall size (mm) Weight (KG)
GTS-1015 5-20 3 1000×1500 less than 200 mm 2600×1400×1700 2200
GTS-1020 10-30 4 1000×2000 less than 200 mm 3400×1400×2200 2800
GTS-1225 20-80 5.5 1200×2500 less than 200 mm 4200×1500×2680 4200
GTS-1530 30-100 7.5 1500×3000 less than 200 mm 4500×1900×2820 5100
GTS-1545 50-120 11 1500×4500 less than 200 mm 6000×1900×3080 6000
GTS-1848 80-150 15 1800×4800 less than 200 mm 6500×2350×4000 7500
GTS-2055 120-250 22 2000×5500 less than 200 mm 7500×2350×4800 9600
GTS-2265 200-350 30 2200×6500 less than 200 mm 8500×2750×5000 12800
