3.0m*0.8m*1.6m Gold Ore Drum Screen with Under Guidance Installation Provided
Product Details:
| Place of Origin: | Henan, China |
| Brand Name: | ZHENGZHOU Sinolion |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 unit |
|---|---|
| Price: | $4,080.00/sets |
| Packaging Details: | All products will be processed to be rustproof and moisture proof before delivery. <br>20GP container or 40GP container <br>Equipment is packed with plastic wrap or steel case, depends on machine weight. <br>Motor is packed with steel case or wooden case. |
| Supply Ability: | 50 Set/Sets per Month gold trommel screening plant |
|
Detail Information |
|||
| Applicable Industries: | Energy & Mining | Showroom Location: | Egypt, United Kingdom, France, Germany, Brazil |
|---|---|---|---|
| Condition: | New | Type: | Gravity Separator |
| Production Capacity: | 5-10t/h | Voltage: | 220V/380V/440V |
| Dimension(L*W*H): | 3.0m*0.8m*1.6m | Weight: | 400 KG |
| Warranty: | 1 Year | Marketing Type: | New Product 2023 |
| Machinery Test Report: | Provided | Video Outgoing-inspection: | Provided |
| Warranty Of Core Components: | 1 Year | Core Components: | Motor, Gear, Engine |
| Key Selling Points: | Easy To Operate | Application: | Gold |
| Product Name: | Gold Mining Machine | Keywords: | Centrifugal Gold Concentrtor |
| After-sales Service Provided: | Service Machinery Overseas | Usage: | Mining Concentration |
| Name: | Gold Ore Processing Equipment | Color: | Customized Making |
| Material: | Steel | Capacity: | 5-10t/h |
| Installation: | Under Guidance | Port: | Qingdao, Tianjin, Lianyungang, Shanghai Guangzhou( As Client Request) |
Product Description
Product Description
How to use a small gold trommel screen
Small gold trommel screens provide a simple, effective method of recovering pure gold from stream sand and sediment. Here are the basic steps: 1. Install the trommel screen on stable, level ground near a water source. Secure with blocks if necessary. 2. Load gold-containing materials into the hopper. Use a shovel to fill the hopper evenly. 3. Turn on the water supply system and provide a stable water supply through the scrubber rod. Adjust water volume as needed. 4. Start the motor to rotate the cylindrical screen. 5. The feeding amount can be controlled by adjusting the height of the hopper discharge chute. Pay attention to the best rolling movements. 6. The finer materials enter the sluice section through the screen and flow out to the tailings pile. 7. Larger materials are discharged from the end of the trommel screen into the waste pile. 8. Check the sluice box regularly and pan the concentrate to recover your gold! 9. Perform maintenance by lubricating parts and regularly checking screen condition. With practice, you will be able to optimize trommel screen performance and maximize gold recovery efficiency. If you have any further questions, please contact us!
Specification
Model | Capacity | Screen Diameter | Screen Length | Power | Weight |
GMTS0519 | 5-10 tons/hour | 500mm | 1910mm | 5.5HP/ 1.5Kw | 400kg |
Product Details
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Company Profile
Sincerely welcome to send your inquiry, you can get best quotation and professional service!
Want to Know more details about this product
