Product Details:

Place of Origin: Henan, China
Brand Name: sinolion

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: $14,500.00/sets >=1 sets
Get Best Price Contact Now

Detail Information
Applicable Industries: Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Farms, Energy & Mining, Other Showroom Location: United States, Australia
Condition: New Type: Gravity Separator
Production Capacity: 80-150T/H Voltage: 220V/380V/415V/480V
Dimension(L*W*H): Varies Weight: 6500 KG
Warranty: 1 Year Marketing Type: Ordinary Product, Hot Product 2023
Machinery Test Report: Provided Video Outgoing-inspection: Provided
Warranty Of Core Components: 1 Year Core Components: Bearing, Motor, Pump, Other, Engine
Key Selling Points: Easy To Operate, Work Efficiently Installation: Supply Manual To Guide User
Feeding Size: Less Than 300mm Customizable: Logo / Packing / Graphic
Double Screen: Multiple Material Output

Product Description

Product Description
Our equipment is called gold mobile trommel screen, which is used to collect gold from placer gold、alluvial gold and rock gold .Its advantages are flexible movement, simple operation,convenient cleaning，high gold recovery capacity， and obvious gold selection effect, and the equipment can work in different construction and operation areas, it can be moved with a trailer hitch ,and the operation cost is low.
High Capacity Energy Mining Mobile Gold Sand Separator Mining Trommel Screen Equipment 0
High Capacity Energy Mining Mobile Gold Sand Separator Mining Trommel Screen Equipment 1
High Capacity Energy Mining Mobile Gold Sand Separator Mining Trommel Screen Equipment 2
The mobile gold washing trommel screen is a kind of gold equipment which can be moved on land. It has the characteristics of compact structure, strong integrity, light weight, large handling capacity, simple operation, reliable operation, easy maintenance and convenient operation.We has been exported to Sudan, Africa, North Korea, Tanzania, Ghana etc.
High Capacity Energy Mining Mobile Gold Sand Separator Mining Trommel Screen Equipment 3
High Capacity Energy Mining Mobile Gold Sand Separator Mining Trommel Screen Equipment 4
High Capacity Energy Mining Mobile Gold Sand Separator Mining Trommel Screen Equipment 5
High Capacity Energy Mining Mobile Gold Sand Separator Mining Trommel Screen Equipment 6
Double Screen
The drum part is made of round steel and manganese wire, and the outer screen is made of manganese wire.which is strong and durable. the screen can be designed with two different sizes of apertures,the maximum product under the screen is 100mm, the middle is 10-50mm, and the thinnest can be up to 3mm . The design of the double-layer screen improves the screening efficiency on the one hand. and can screen materials of three specifications ,on the other hand. it protects and improves the service life of the screen.
High Capacity Energy Mining Mobile Gold Sand Separator Mining Trommel Screen Equipment 7
Working Principle
First, the material is poured into the feeding hopper by the loader, and transported to the trommel screen by the conveyor of the feeding hopper, Then the motor reducer drives the idler to rotate the drum through the coupling, and the material particles in the drum follow the screen, and the drum rotates to a certain height, throws and drops by gravity, and filters the finished product through the screen. Then the motor reducer drives the idler to rotate the drum through the coupling, and the material particles in the drum follow the screen, and the drum rotates to a certain height, throws and drops by gravity, and filters the finished product through the screen.
High Capacity Energy Mining Mobile Gold Sand Separator Mining Trommel Screen Equipment 8
Technical Parameters
Model
Capacity (t/h)
Power (kw)
Diameter (mm)
Length(mm)
Discharge(mm)
Input(mm)
Dimension (mm)
GMTS0519
5—10
1.5
500
1910
≤300
0—100
3000*1000*1800
GMTS1020
10—30
4
1000
2000
≤300
0—100
3200*1400*1900
GMTS1225
30—50
5.5
1200
2500
≤300
0—100
4300*1650*2220
GMTS1548
80—150
11
1500
4800
≤300
0—100
8000*2200*3600
GMTS1848
100—200
15
1800
4800
≤300
0—100
8000*2200*4000
Case
High Capacity Energy Mining Mobile Gold Sand Separator Mining Trommel Screen Equipment 9
High Capacity Energy Mining Mobile Gold Sand Separator Mining Trommel Screen Equipment 10
Packing & Delivery
High Capacity Energy Mining Mobile Gold Sand Separator Mining Trommel Screen Equipment 11
High Capacity Energy Mining Mobile Gold Sand Separator Mining Trommel Screen Equipment 12
Ways Of Packing 1. Small parts packed in the wooden cases 2.Big parts or the whole big machine is loaded in the container by the Ocean Shipping or others .
