Supply Manual and Engineer Guide Stone Secondary Crushing Equipment Sand Making Roll Mill Crusher for Ore
Product Details:
Place of Origin: | Henan, China |
Brand Name: | Sinolion |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 unit |
---|---|
Price: | $2,000.00/sets >=1 sets |
Detail Information |
|||
Applicable Industries: | Manufacturing Plant, Machinery Repair Shops, Other | Showroom Location: | None |
---|---|---|---|
Condition: | New | Type: | Roller Crusher, Motor Driving |
Application: | Chemical Industry, Stone, Ore, Glass, Coal | Motor Type: | AC Motor |
Capacity(t/h): | 5-120t/h | Dimension(L*W*H): | As Per Different Model |
Weight: | 1260 KG | Warranty: | 2 Years |
Marketing Type: | Other | Machinery Test Report: | Provided |
Video Outgoing-inspection: | Provided | Warranty Of Core Components: | 1 Year |
Core Components: | Motor, Pump | Key Selling Points: | Easy To Operate |
Product Name: | Stone Secondary Crushing Equipment Sand Making Roll Mill Crusher | Model: | Double Roll Crusher Machine |
Installation: | Supply Manual And Send Engineer To Guide User | Feeding Size: | 0-25mm |
Discharge Size: | Adjustable From 0-40mm | Double Roller Material: | Manganese Steel |
Motor Quantity: | 2 Motors | Wearing Parts: | Rollers And V-belt |
Color: | Yellow, White, Red, Blue, Gray( Or As Client Request) |
Product Description
Double Roller Crusher Types
The major types of roller crusher are toothed roll crusher and smooth roller crusher. According to the requirements, the rolls are smooth (double roller crusher) or toothed (toothed roller crusher). When rotating, ore and othermaterials pass the two crushing rollers, and they are crushed or grounded intosmaller pieces. Capacity range of roller crusher is from 5 - 110 t/h.
Stone Roller Crusher:
The particles are drawn into the gap between the rolls by their rotating motion and a friction angle formed between the rolls and the particle, called the nip angle. The two rolls force the particle between their rotating surface into the ever smaller gap area, and it fractures from the compressive forces presented by the rotating rolls.
Some major advantages of stone roller crusher/roll crushers are they give a very fine product size distribution and they produce very little dust or fines. Stone roller crushers are effectively used in minerals crushing where the ores are not too abrasive and they are also used in smaller scale production mining of more abrasive metal ores, such as gold.
Double roll crusher technical parameters:
Model | Roller diameter (mm) | Roller length (mm) | Input size (mm) | Output size (mm) | Capacity (t/h) | Power (KW) | Weight (t) |
2PG-400X250 | 400 | 250 | ≤25 | 0-8 | 5-10 | 5.5x2 | 1.5 |
2PG-500X400 | 500 | 400 | ≤30 | 0-10 | 8-20 | 11x2 | 3.2 |
2PG-610X400 | 610 | 400 | ≤40 | 0-20 | 13-35 | 15x2 | 4.5 |
2PG-610X800 | 610 | 800 | ≤40 | 0-20 | 15-40 | 18.5x2 | 12.25 |
2PG-750X500 | 750 | 500 | ≤45 | 0-20 | 15-40 | 18.5x2 | 12.25 |
2PG-750X700 | 750 | 700 | ≤45 | 0-20 | 20-50 | 22x2 | 14 |
2PG-900X500 | 900 | 500 | ≤55 | 0-40 | 20-50 | 22x2 | 14 |
2PG-900X900 | 900 | 900 | ≤55 | 0-50 | 20-70 | 37x2 | 16.8 |
2PG-900X1200 | 900 | 1200 | ≤55 | 0-50 | 25-90 | 55x2 | 20.8 |
2PG-1200X1000 | 1200 | 1000 | ≤70 | 0-60 | 25-100 | 45x2 | 40.2 |
