5-100 T/H Mini Lab Double Dual Two Roller Crusher for Coke Coal Clay at Affordable
Product Details:
| Place of Origin: | China |
| Brand Name: | Sinolion |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 unit |
|---|---|
| Price: | $2,000.00/sets >=1 sets |
|
Detail Information |
|||
| Applicable Industries: | Energy & Mining | Showroom Location: | None |
|---|---|---|---|
| Condition: | New | Type: | Roller Crusher, Motor Driving |
| Application: | Stone, Ore, Glass, Coal, Cement, Clinker, E Waste | Motor Type: | AC Motor |
| Capacity(t/h): | 5-70t/h | Dimension(L*W*H): | As Per Different Model |
| Weight: | KG | Warranty: | 24 Months Excluding Spare Parts |
| Marketing Type: | New Product 2021 | Machinery Test Report: | Provided |
| Video Outgoing-inspection: | Provided | Warranty Of Core Components: | 1 Year |
| Core Components: | Gearbox | Key Selling Points: | Manganese Steel Roller |
| Model: | Two Roller Crusher 2PG-750*500 | Installation: | Supply Manual And Send Engineer To Guide User |
| Feeding Size: | 0-25mm | Discharge Size: | Adjustable From 0-40mm |
| Double Roller Material: | Manganese Steel | Motor Quantity: | 2 Motors |
| Wearing Parts: | Rollers And V-belt | Roller Materials:: | High Manganese Steel |
| Color: | Yellow, White, Red, Blue, Gray( Or As Client Request) | ||
Product Description
Smooth double two roller crusher:
Double two roller crusher operating principle:
When the material comes into the crushing cavity,under the impact of rotating and biting forces of the double roller,the machine uses strong grinding force produced by the relative rotation of high strength wear-resisting rollers to twist,grind and crush the material.
Double two roller crusher technical parameters:
| Model | Roller diameter (mm) | Roller length (mm) | Input size (mm) | Output size (mm) | Capacity (t/h) | Power (KW) | Weight (t) |
| 2PG-400X250 | 400 | 250 | ≤25 | 0-8 | 5-10 | 5.5x2 | 1.5 |
| 2PG-500X400 | 500 | 400 | ≤30 | 0-10 | 8-20 | 11x2 | 3.2 |
| 2PG-610X400 | 610 | 400 | ≤40 | 0-20 | 13-35 | 15x2 | 4.5 |
| 2PG-610X800 | 610 | 800 | ≤40 | 0-2 | 15-40 | 18.5x2 | 12.25 |
| 2PG-750X500 | 750 | 500 | ≤45 | 0-20 | 15-40 | 18.5x2 | 12.25 |
| 2PG-750X700 | 750 | 700 | ≤45 | 0-20 | 20-50 | 22x2 | 14 |
| 2PG-900X500 | 900 | 500 | ≤55 | 0-40 | 20-50 | 22x2 | 14 |
| 2PG-900X900 | 900 | 900 | ≤55 | 0-50 | 20-70 | 37x2 | 16.8 |
| 2PG-900X1200 | 900 | 1200 | ≤55 | 0-50 | 25-90 | 55x2 | 20.8 |
| 2PG-1200X1000 | 1200 | 1000 | ≤70 | 0-60 | 25-100 | 45x2 | 40.2 |
Zhengzhou Sinolion 2-roller crushers mainly have two kinds: 2PG double smooth roll crusher and 2PGC double teeth roll crusher. 2PG series of lab 2-roller crusher is for fine crushing materials, but the 2PGC series of double roll tooth crusher is suitable for coarse and meduim crushing various of ore materials.
2-roller crusher structure
2PGC series of river stone crusher price mainly consist of roller, the roller support bearings, pinch and adjust parts of the device and the driving device and other components.
Teeth roller crusher technical parameters:
| Model | Feed size (mm) | Capacity(t/h) | Power (KW) | Weight (t) | ||||
| Discharge size(mm) | ||||||||
| 15 | 30 | 50 | 75 | 125 | ||||
| 2PGC-450x500 | 80-150 150-300 | 20 | 35 | 80 50 | 85 | 145 | 11x2 | 4.15 |
| 2PGC-400x600 | 80-150 150-300 | 30 | 50 | 105 70 | 85 | 190 | 15x2 | 4.6 |
| 2PGC-500x750 | 80-150 150-300 | 42 | 68 | 145 85 | 120 | 255 | 22x2 | 5.7 |
| 2PGC-600x900 | 80-150 150-300 | 58 | 80 | 180 100 | 145 | 320 | 30x2 | 7.2 |
| 2PGC-750x750 | 80-200 200-400
| 60 | 80 | 185 90 | 140 | 205 | 37x2 | 11 |
| 2PGC-900x900 | 80-200 200-400 | 70 | 100 |
220 110 | 185 | 380 | 45x2 | 13.8 |
| 2PGC-750x1500 | 80-200 200-400 | 85 | 125 | 205 110 | 180 | 250 | 45x2 | 13 |
| 2PGC-750x1800 | 80-200 200-400 | 120 | 150 | 250 175 | 220 | 380 | 55x2 | 14.6 |
1. Pre-sale service:
1) Sinolion will provide production line design, quotation sheet, working sites video, machinery photos, sample testing(gold ore, tin ore , iron ore, tungsten processing in laboratory).
2) Welcome to visit us at any time, we will pick you up.
2. Sale service:
1) Keep clients updated when our company gets advance payment.
2) Confirm production details with clients.
3) Take photos and send all pictures to customers during production.
4) Inspection and testing the product before delivery;
5) Clients are welcome to inspect the equipment when the equipment are ready to delivery.
6) logistics service if needed.
3. After Sale service:
1) Provide foundation drawing to the clients for installation.
2) Besides, our engineers are available to help with installation and workers training.
3) Repairing and maintenance if any problem during the warranty.
4) Spare parts and wearing parts will be offered with production cost in 10 years.
Zhengzhou Sinolion Machinery Co., Ltd. is a high-tech company which professional manufacturing the production of briquette equipment, building material equipment, and mining machinery.
After 30 years of development, Sinolion is now setting up branches, integrating engineering, trade, research and development, production and sale to develop to be a large sized enterprise. SINOLION has modern standard workshops, as well as advanced technology and testing equipment. Extensively cooperating with coal research institutions and other research departments, SINOLION has continuously improved product values and performance. Now, 10,000-300,000 tons briquette production lines are renowned in domestic and foreign markets, and SINOLION products have been exported to Indonesia, Kazakhstan, Vietnam, North Korea, Egypt and other countries and regions. It is ideal equipment for briquetting mine power in the world market.
SINOLION provides space planning and design, equipment installation and commissioning support. Our company persists in the philosophy of ''quality for survival, reputation and development'', and SINOLION strives to build a world well known brand to satisfy customers in order to let them rest assured with comfort. SINOLION Company is willing to take full use of the new technology, dedicated to providing superior products with reliable quality, favorable prices and perfect service for users who need us to design, manufacture and install coal production lines.
We will continue to adhere to "Quality is our eternal pursuit and pride", create new glories with customers! Welcome to SINOLION for visiting and seeking common development.
Question 1: What’s the delivery time after I pay the deposit ?
Answer: We will delivery the goods within 10-15 working days after receipt of the prepayment.
Question 2: Is mineral samples analysis available?
Answer: Sure, we supply samples analysis service for free. After the testing, we will give you the reasonable flow chart, suitable solution and equipment selection.
Question 3: Do you have client in my country?
Answer: Our products have exported to Malaysia, Indonesia, the Philippines, Vietnam, Myanmar, Korea, Singapore, Thailand, Mongolia, Ghana, Sudan, Serbia, Kazakhstan, Canada, Nigeria, Australia, Chile, Brazil, Columbia, Ecuador, Peru, Bolivia, etc
Question 4: How long of your machine quality guarantee terms ?
Answer: Quality guarantee time is one year(wearing parts excluded).
