Like all machines in the MTS series, the MTS 1230 not picky about sifting out waste and raw materials regards. It is equally suitable for compost, soil,light rubble, wood, biomass, sand and gravel etc.
Screening materials: earth, sand, gravel, compost, wood chips, construction waste, recycling material, slag, crushed stone and
stone in grain sizes from 2 mm to 80 mm
Mobile Trommel Screener MTS1230 for Earth Sand Gravel Compost Wood Chips High Capacity
Product Details:
Place of Origin: | Henan, China |
Brand Name: | sinolion |
Certification: | ISO9001:2008 |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 unit |
---|---|
Price: | $15,900.00/sets |
Detail Information |
|||
Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops | Showroom Location: | Canada, United Kingdom, United States, Germany, Brazil, Mexico, Russia, Australia |
---|---|---|---|
Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
Marketing Type: | Ordinary Product | Warranty Of Core Components: | 1 Year |
Core Components: | Bearing, Motor, Gear | Condition: | New |
Type: | Flotation Separator | Voltage: | 380v/415v/440v |
Dimension(L*W*H): | Depends On Models | Weight: | 3200 KG |
Warranty: | 1 Year | Product Name: | Mobile Trommel Screener For Earth, Sand, Gravel, Compost, Wood Chips |
Application: | Earth, Sand, Gravel, Compost, Wood Chips, Construction Waste | Screen Material: | Steel Bar, Steel Plate Punch Hole, Steel Wire Woven, Stainless Steel |
Discharge Size: | As Request | After-sales Service Provided: | Field Maintenance And Repair Service |
Product Description
Product Overview
Mobile trommel screener MTS1230 for earth, sand, gravel, compost, wood chips
This wheeled mobile trommel screen systems’ high flexibility and the comprehensive range of products, from the smallest screening machine with less than 1.8 tons to the largest with up to 20 tons, enable the company to serve customers from the gardening,landscaping, recycling, timber, civil engineering, glass and even gravel pits and quarries. This wheeled mobile machine are not only used in the processing of earth materials, but also in more specific fields of application, such as the extraction of recyclable fractions of plastics, foils and wood chips and in the processing of compost, milled material, building rubble, stones, gravel, as well as glass or even in the recycling of sandbags.
FEATURES AT A GLANCE

Scope of application
Advantages
·Quick change system for the sieve insert, optionally drum or star screen insert
·Large 2 m³ feed hopper with a loading height of just 1.8 m ·2.5 m long discharge belts with 1.75 m delivery height
·Electronic load control for a perfect screening result optimal throughput
·Perfect mobility thanks to compact transport dimensions
·Large 2 m³ feed hopper with a loading height of just 1.8 m ·2.5 m long discharge belts with 1.75 m delivery height
·Electronic load control for a perfect screening result optimal throughput
·Perfect mobility thanks to compact transport dimensions






PRODUCT SPECIFICATIONS
Model | Trommel diameter (mm) | Trommel length (mm) | Capacity (m3/h) | Weight (Kg) | Dimensions (L*W*H) |
MTS1230 | 1200 | 3000 | ≤60 | 3210 | 5.4*2.1*2.7 |
Successful Project


Company Profile





FAQ
1. What's the delivery time after I pay the deposit ?
In your first inquiry, please let us know your information and requirements, we will give you guidance for choosing the right
machine.
2. Is mineral samples analysis available?
Sure, we supply samples analysis service for free. After the testing, we will give you the reasonable flow chart, suitable
solution and equipment selection.
3. What's the delivery time after I pay the deposit?
We will clear delivery time in slaes contract, Single movable drum sieve often deliveried within 10-15 working days after receipt of the pre-payment. Complete production line will delivery within 25-40 working days after receipt of the pre-payment.
4. How long of your machine quality guarantee terms ?
Quality guarantee time is one year(wearing parts excluded).
In your first inquiry, please let us know your information and requirements, we will give you guidance for choosing the right
machine.
2. Is mineral samples analysis available?
Sure, we supply samples analysis service for free. After the testing, we will give you the reasonable flow chart, suitable
solution and equipment selection.
3. What's the delivery time after I pay the deposit?
We will clear delivery time in slaes contract, Single movable drum sieve often deliveried within 10-15 working days after receipt of the pre-payment. Complete production line will delivery within 25-40 working days after receipt of the pre-payment.
4. How long of your machine quality guarantee terms ?
Quality guarantee time is one year(wearing parts excluded).
Want to Know more details about this product
