Product Details:

Place of Origin: Henan, China
Brand Name: Sinolion

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: $15,900.00/sets 1-1 sets
Get Best Price Contact Now

Detail Information

Applicable Industries: Home Use, Energy & Mining Showroom Location: Canada, United States, Germany, Australia
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Marketing Type: Hot Product 2023 Warranty Of Core Components: 1 Year
Core Components: PLC, Engine, Bearing, Gearbox, Motor, Gear Condition: New
Type: Circular Voltage: 220V/380V/415V
Dimension(L*W*H): 5400*2100*2700mm Weight: 3210 KG
Warranty: 1 Year Product Name: Mobile Trommel Screen
Application: Compost, Construction & Demolition Discharge Size: Less Than 6mm
Dimension: Depends On Model Installation: Supply Manual To Guide User
Feeding Size: Less Than 300mm Color: Yellow, White, Red, Blue, Gray( Or As Client Request)
MOQ: 1Set Certificate: CE
Capacity: 30-150 Tons Per Hour

Product Description

Industrial Machinery Movable Screening Compost Trommel Screen with 3210 KG Capacity 0
Industrial Machinery Movable Screening Compost Trommel Screen with 3210 KG Capacity 1
Industrial Machinery Movable Screening Compost Trommel Screen with 3210 KG Capacity 2
High Effective Industrial Machinery Movable Screening Compost Trommel Screen
The mobile trommel screening machine is a screening equipment developed by our company for small and medium-sized and light materials such as compost, wood chips, cow dung, sand and gravel. It has the following characteristics: 1. Smooth operation and low noise; 2. Simple structure, maintenance Convenient; 3. The screen holes are not easy to block; 4. The screening efficiency is high; 5. The screen has a long service life and is easy to replace.
Industrial Machinery Movable Screening Compost Trommel Screen with 3210 KG Capacity 3
Industrial Machinery Movable Screening Compost Trommel Screen with 3210 KG Capacity 4
Industrial Machinery Movable Screening Compost Trommel Screen with 3210 KG Capacity 5
Industrial Machinery Movable Screening Compost Trommel Screen with 3210 KG Capacity 6

Structure and Principle

The mobile trommel screen is mainly composed of silo, screen drum, idler assembly, transmission part, discharge conveyor, brush, underframe, rear axle, traction, diesel generator, control cabinet, protective cover and other parts. The basic working principle of the trommel screen: the material is poured into the silo by the loader, and transported to the trommel screen by the conveyor on the silo, and then the motor reducer drives the idler to rotate the screen cylinder, and the material particles in the screen cylinder follow the screen. The drum rotates to a certain height, is thrown and dropped by gravity, and is filtered through the screen to form a screening. Finally, the screened materials are transported to different places by different conveyors.
Industrial Machinery Movable Screening Compost Trommel Screen with 3210 KG Capacity 7
Model
Trommeldiameter
(mm)
Trommel length
(mm)
Capacity
(m3/h)
motor power
(KW)
Weight
(Kg)
Dimensions
(L*W*H)
MTS1230
1200
3000
≤60
10.6
3210
5.4*2.1*2.7
Product Name
Mobile Trommel Screen
Product Type
MTS1230
Trommel Diameter
1.2m
Trommel Length
3m
Trommel Power
4kw
Industrial Machinery Movable Screening Compost Trommel Screen with 3210 KG Capacity 8
Industrial Machinery Movable Screening Compost Trommel Screen with 3210 KG Capacity 9
Industrial Machinery Movable Screening Compost Trommel Screen with 3210 KG Capacity 10
Industrial Machinery Movable Screening Compost Trommel Screen with 3210 KG Capacity 11
Industrial Machinery Movable Screening Compost Trommel Screen with 3210 KG Capacity 12
Industrial Machinery Movable Screening Compost Trommel Screen with 3210 KG Capacity 13
Industrial Machinery Movable Screening Compost Trommel Screen with 3210 KG Capacity 14
Industrial Machinery Movable Screening Compost Trommel Screen with 3210 KG Capacity 15
Industrial Machinery Movable Screening Compost Trommel Screen with 3210 KG Capacity 16
Industrial Machinery Movable Screening Compost Trommel Screen with 3210 KG Capacity 17
Industrial Machinery Movable Screening Compost Trommel Screen with 3210 KG Capacity 18
