Product Details:

Place of Origin: Henan, China
Brand Name: sinolion

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: $4,100.00 - $28,750.00/sets
Get Best Price Contact Now

Detail Information
Applicable Industries: Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Construction Works , Energy & Mining Showroom Location: None
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Marketing Type: New Product 2020 Warranty Of Core Components: 1 Year
Core Components: Motor Condition: New
Type: Circular Application: Ore, Industrial Waste, Mulch, Organics, Bark, MSW, Building Waste
Voltage: 380v/415v/440v Dimension(L*W*H): Depends On Models
Weight: 4000 KG Warranty: 1 Year
After-sales Service Provided: Engineers Available To Service Machinery Overseas Screen Material: Steel Bar, Steel Plate Punch Hole, Steel Wire Woven, Stainless Steel
Power: 3-45KW Dimension: According To Capacity
Installation: Supply Manual To Guide User Capacity: 50-500 Tons Per Hour
Feeding Size: Less Than 300mm Discharge Size: As Request
Color: Yellow, White, Red, Blue, Gray( Or As Client Request)

Product Description

Woodchips drum sieve compost rotary trommel screen with high efficiency

Product Description



4000 KG Capacity Woodchips Drum Sieve Compost Rotary Trommel Screen with and Capacity 0



This wheeled mobile trommel screen systems’ high flexibility and the comprehensive range of products, from the smallest screening machine with less than 1.8 tons to the largest with up to 20 tons, enable the company to serve customers from the gardening, landscaping, recycling, timber, civil engineering, glass and even gravel pits and quarries. This wheeled mobile machine are not only used in the processing of earth materials, but also in more specific fields of application, such as the extraction of recyclable fractions of plastics, foils and wood chips and in the processing of compost, milled material, building rubble, stones, gravel, as well as glass or even in the recycling of sandbags.

This wheeled mobile machine can neatly screen e.g. compost, soil, sand, slag, gravel, gravel, wood chips, refuse, stones as well as mineral waste from 2 – 80 mm. The material is filled into the belt feeder, which can hold up to 5.5 m³. The material is then fed into the double tromel. It consists of a steel, robust inner cage and an outer cage that can be equipped with wire screens of various mesh sizes. What the inner cage does not retain is captured by the outer cage, the fine fraction is discharged via a conveyor belt. Once a mountain of work has been eliminated, the can be towed to the next location.





4000 KG Capacity Woodchips Drum Sieve Compost Rotary Trommel Screen with and Capacity 1

4000 KG Capacity Woodchips Drum Sieve Compost Rotary Trommel Screen with and Capacity 2



technical parameters




Model Trommel diameter
(mm)		 Trommel length
(mm)		 Capacity
(m3/h)		 motor power(KW) Weight
(Kg)		 Dimensions
(L*W*H)
MTS0818 800 1800 ≤15 2.4 650 3.15*1.1*1.65
MTS1022 1000 2200 ≤30 8.2 2750 4.3*1.9*2.45
MTS1230 1200 3000 ≤60 10.6 3210 5.4*2.1*2.7
MTS1550 1500 5000 ≤90 20 7900 9.4*2.2*2.9
4000 KG Capacity Woodchips Drum Sieve Compost Rotary Trommel Screen with and Capacity 3

The trommel screen is a heavy-duty, mobile drum screen machine built for small to medium-sized topsoil and compost operations.





» Horizontal drum delivers consistent output.



» Material rides on screening surface for extremely effective separation.



 4000 KG Capacity Woodchips Drum Sieve Compost Rotary Trommel Screen with and Capacity 44000 KG Capacity Woodchips Drum Sieve Compost Rotary Trommel Screen with and Capacity 5



Case

 4000 KG Capacity Woodchips Drum Sieve Compost Rotary Trommel Screen with and Capacity 64000 KG Capacity Woodchips Drum Sieve Compost Rotary Trommel Screen with and Capacity 7

Customer

4000 KG Capacity Woodchips Drum Sieve Compost Rotary Trommel Screen with and Capacity 8
