Compost Processing Trommel Screen for Organic Fertilizer Compost Machinery Repair Shops

Compost Processing Trommel Screen for Organic Fertilizer Compost Machinery Repair Shops

Product Details:

Place of Origin: Henan, China
Brand Name: sinolion

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: $4,100.00 - $28,750.00/sets
Get Best Price Contact Now

Detail Information

Applicable Industries: Building Material Shops, Machinery Repair Shops, Energy & Mining Showroom Location: Canada, United Kingdom, United States, Germany, Brazil, Mexico, Russia, Australia
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Marketing Type: New Product 2023 Warranty Of Core Components: 1 Year
Core Components: Gearbox, Motor Condition: New
Type: Circular Application: Food Processing
Voltage: 380v/415v/440v Dimension(L*W*H): Depends On Processing Trommel Screen
Weight: 2000 KG Warranty: 1 Year
Product Name: Compost Processing Trommel Screen For Organic Fertilizer Compost Keyword: Compost Drum Sieve
Screen Material: Steel Bar, Steel Plate Punch Hole, Steel Wire Woven, Stainless Steel Power: 3-45KW
Dimension: According To Capacity Installation: Supply Manual To Guide User
Capacity: 50-500 Tons Per Hour Feeding Size: Less Than 300mm
Discharge Size: As Request Color: Yellow, White, Red, Blue, Gray( Or As Client Request)

Product Description

Compost processing trommel screen for organic fertilizer compost for sale



Product Description



Up to now, our compost drum sieve equipment has adopted the latest technology to make the machine more environmental-friendly, energy-saving and economical. The compost drum sieve is made up of round or hexagonal roller, frame, hopper, reducer, drive motor and auxiliary structure. Most importantly, the drum sieve has the super powerful screening ability, simple operation, convenient maintenance and adjustment, long service life, flexible sieve ratios, and other remarkable effects. Last but not least, the screening granularity can be adjusted casually in order to achieve the ideal match ratio.

Sinolion compost drum screen is widely used for screening and classifying material, such as compost, mining, chemical, coal, building materials, abrasives, and other industries.





Working Principle

Fristly, put the materials into the drum, then they are lifted up by the rotation as they fall back down. This action is repeated with each revolution along the length of the drum. The material to be graded is fed into rotary sieve from organic fertilizer granulator, screw pushed inner sieve. The finer material passes through the screen openings while the larger material tumbles towards its eventual exit at the rear of the drum.





Application:

munlcpal solid waste,construction waste,stone,compost,wood chips,sawdust,soil,coal,river sand,refractory materials,chemiacal,etc

Compost Processing Trommel Screen for Organic Fertilizer Compost Machinery Repair Shops 0



Technical parameter





Model

Trommeldiameter
(mm)

Trommel length
(mm)

Capacity
(m3/h)

motor power(KW)

Weight
(Kg)

Dimensions
(L*W*H)

MTS0818

800

1800

≤15

2.4

650

3.15*1.1*1.65

MTS1022

1000

2200

≤30

8.2

2750

4.3*1.9*2.45

MTS1230

1200

3000

≤60

10.6

3210

5.4*2.1*2.7

MTS1550

1500

5000

≤90

20

7900

9.4*2.2*2.9

Compost Processing Trommel Screen for Organic Fertilizer Compost Machinery Repair Shops 1Compost Processing Trommel Screen for Organic Fertilizer Compost Machinery Repair Shops 2Compost Processing Trommel Screen for Organic Fertilizer Compost Machinery Repair Shops 3Compost Processing Trommel Screen for Organic Fertilizer Compost Machinery Repair Shops 4

Compost Processing Trommel Screen for Organic Fertilizer Compost Machinery Repair Shops 5

Compost Processing Trommel Screen for Organic Fertilizer Compost Machinery Repair Shops 6Compost Processing Trommel Screen for Organic Fertilizer Compost Machinery Repair Shops 7Compost Processing Trommel Screen for Organic Fertilizer Compost Machinery Repair Shops 8

Compost Processing Trommel Screen for Organic Fertilizer Compost Machinery Repair Shops 9Compost Processing Trommel Screen for Organic Fertilizer Compost Machinery Repair Shops 10

Compost Processing Trommel Screen for Organic Fertilizer Compost Machinery Repair Shops 11Compost Processing Trommel Screen for Organic Fertilizer Compost Machinery Repair Shops 12Compost Processing Trommel Screen for Organic Fertilizer Compost Machinery Repair Shops 13Compost Processing Trommel Screen for Organic Fertilizer Compost Machinery Repair Shops 14 Compost Processing Trommel Screen for Organic Fertilizer Compost Machinery Repair Shops 15
