Product Details:

Place of Origin: China
Brand Name: Sinolion

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: $3,000.00/sets >=1 sets
Get Best Price Contact Now

Detail Information

Applicable Industries: Energy & Mining Showroom Location: None
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Marketing Type: New Product 2020 Warranty Of Core Components: 1 Year
Core Components: Motor Condition: New
Type: Rotary Application: Compost, Soil, Sawdust, Wood Chips, Rock, Soil, River Stone, Gravel, Pebble
Voltage: 380V/415V/440V Dimension(L*W*H): As Per Different Model
Weight: 2200 KG, 2.2T-18T Warranty: 2 Years
Product Name: Drum Screen Machine/Compost Sieving Rotary Trommel Screen Keyword: Compost Sieving Rotary Trommel Screen
Power: 5.5KW, 7.5KW, 11KW Dimension: Depends On Model
Installation: Supply Manual To Guide User Capacity: 30-150 Tons Per Hour
Feeding Size: Less Than 300mm Discharge Size: Less Than 6mm

Product Description

Product Description

Soil screener provides a simple, efficient and economical solution to upgrade a wide rang of materials and optimize the subsequent process steps of recovery. This method of screening helps to reduce operating and investment cost and to enhance product quality with  rapid and large volume processing.



Screening Compost Sieving Rotary Trommel Screen Machine 30-150 Tons per Hour Capacity 0



Features of soil screener:

1. Trommel Screen Mesh Material

2. Bearing and Bearing box

3. The Spindle is made of oil drilling rod material

4. The hub is made of thicken flat steel.

5. Motor and Reducer

6. The machine frame using national standard channel steel or square steel.

7. Inlet and outlet Design

8. Can be installed belt conveyor for undersize material all-in-one machine, conveying height can be up to 4.5 meters to 6 meters, which convenient for loading and move, will save space and save your installation cost.

9. The trommel screen can be equipped with remote control device.

10. Can be equipped with pumps for cleaning materials.

11. Can be equipped with diesel engine for non-electric users.

12. Can be equipped with cleaning screen mesh device to prevent the block problem of below 3mm mesh.

13. Can be installed heavy hopper for different loader (16, 20, 30,50 model) feeding.

14. Can be installed tyre easy to move.

15. Can be equipped with adjustable-speed motor or variable frequency motor used to adjust the trommel rotate speed to meet requirements of customers for different materials screening. Trommel screen rotate speed is 16-18r/min, maximum must < 30r/min or it will form centrifugal force.

16. In a word, one customer one request and the trommel screen will be different.



Trommel sieve screen could also used for sandstone, topsoil, compost, municipal solid waste recycling plant, glass, mulch, organics, bark, wood chips, construction waste, etc.



Screening Compost Sieving Rotary Trommel Screen Machine 30-150 Tons per Hour Capacity 1

Product Details

Screening Compost Sieving Rotary Trommel Screen Machine 30-150 Tons per Hour Capacity 2

Working site

Screening Compost Sieving Rotary Trommel Screen Machine 30-150 Tons per Hour Capacity 3Screening Compost Sieving Rotary Trommel Screen Machine 30-150 Tons per Hour Capacity 4

Screening Compost Sieving Rotary Trommel Screen Machine 30-150 Tons per Hour Capacity 5

Screening Compost Sieving Rotary Trommel Screen Machine 30-150 Tons per Hour Capacity 6

Our Services

Screening Compost Sieving Rotary Trommel Screen Machine 30-150 Tons per Hour Capacity 7





Company Information

Screening Compost Sieving Rotary Trommel Screen Machine 30-150 Tons per Hour Capacity 8Screening Compost Sieving Rotary Trommel Screen Machine 30-150 Tons per Hour Capacity 9Screening Compost Sieving Rotary Trommel Screen Machine 30-150 Tons per Hour Capacity 10Screening Compost Sieving Rotary Trommel Screen Machine 30-150 Tons per Hour Capacity 11

FAQ

Question 1: What’s the delivery time after I pay the deposit ?

Answer: We will delivery the goods within 10-15 working days after receipt of the prepayment.



Question 2: Is mineral samples analysis available?

Answer: Sure, we supply samples analysis service for free. After the testing, we will give you the reasonable flow chart, suitable solution and equipment selection.



Question 3: Do you have client in my country?

Answer: Our products have exported to Malaysia, Indonesia, the Philippines, Vietnam, Myanmar, Korea, Singapore, Thailand, Mongolia, Ghana, Sudan, Serbia, Kazakhstan,  Canada, Nigeria, Australia, Chile, Brazil, Columbia, Ecuador, Peru, Bolivia, etc



Question 4: How long of your machine quality guarantee terms ?

Answer: Quality guarantee time is one year(wearing parts excluded).
