Wood Chipper Crushing Machine for Small Size in Energy Mining
Product Details:
Place of Origin: | China |
Brand Name: | sinolion |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 unit |
---|---|
Price: | $1,500.00/sets >=1 sets |
Detail Information |
|||
Applicable Industries: | Hotels, Manufacturing Plant, Home Use, Food Shop, Energy & Mining, Food & Beverage Shops | Showroom Location: | None |
---|---|---|---|
Condition: | New | Type: | Wood Chipper |
Power Type: | Diesel | Weight: | 400 KG |
Warranty: | 1 Year | Marketing Type: | New Product 2021 |
Machinery Test Report: | Provided | Video Outgoing-inspection: | Provided |
Warranty Of Core Components: | 1 Year | Core Components: | Motor, Gear, PLC |
After-sales Service Provided: | Engineers Available To Service Machinery Overseas | Application: | Peanut, Straw Stalk, Corn Cob, Straw, Couch Grass |
Spare Parts: | Hammer | Blades Quatity: | 24 Pieces |
Capacity: | 1000-1500kg/h | Feeding Size: | Less Than 300mm |
Rotation Speed: | 3500 R/min | Color: | Yellow, White, Red, Blue, Gray( Or As Client Request) |
Motor Speed: | 1440r/min |
Product Description
Wood crusher introduction:
1. Our wood crusher is the ideal equipment for advanced production of edible mushroom cultivition, biomass fuel pellet making. It can process the wood, branch into sawdust or powder at the same time.
2. The wood crusher machine also can be used for making raw materials for shaving broad, sawdust broad and MDF.
The wood crusher produced by our company is a king of newly-developed wood crushing equipment for raw wood, which is an innovation on the basis of traditional crusher-making theories both home and abroad. It is composed of machine body, knife chipping part, chips re-crushing part and sieving part, etc .It combines both chipping and crushing in one machine, can make sawdust in one passage, no need to use wood chipper for pre-processing of wood logs.
Wood crusher machine advantage:
1.1. Wood crusher can crush wood, corn cob, agri waste, etc.
1.2. It doesn't need drying wood and can directly crush them.
1.3. It adopts the blade cutting and high-speed airflow impact, collision double crushing function as an organic whole, and also can finish the small material processing operations at the same time . In the crushing process of the blade cutting, rotor produce high-speed airflow, along with the direct of the blade cutting to rotate , materials in the air flow speeds up, and make the material crush by double pieces again at the same time, and speed up the material crushing rate.
Main usage:
It is a whole body with blade and crusher, and can crush 1-20cm wood and branch. It also can adapt bamboo, grass, corn stalk, kaoliang stalk and other kinds of fiber materials.
Model | SLFS-400 | SLFS-500 | SLFS-600 | SLFS-700 | SLFS-800 | SLFS-1000 |
Feeding size(mm) | 160*200 | 180*200 | 200*200 | 200*250 | 250*300 | 300*400 |
Rotation speed(r/min) | 2800 | 2600 | 2600 | 2300 | 2000 | 2000 |
Power(kw) | 11 | 15 | 18.5-22 | 22-30 | 30-45 | 75 |
Blades | 4 | 4 | 4 | 4-6 | 4-6 | 4-6 |
Output (kg/h) | 1200 | 1500 | 2000 | 2500 | 3000 | 4000 |
Cutter diameter | 400mm | 500mm | 600mm | 700mm | 800mm | 1000mm |
