Product Details:

Place of Origin: Henan, China
Brand Name: sinolion

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: $6,000.00/sets >=1 sets
Packaging Details: All products will be processed to be rustproof and moisture proof before delivery. <br>20GP container or 40GP container <br>Equipment is packed with plastic wrap or steel case or free fumigation wooden cases, depends on machine weight. <br>Motor is packed
Supply Ability: 40 Set/Sets per Month
Get Best Price Contact Now

Detail Information

Applicable Industries: Building Material Shops, Machinery Repair Shops, Energy & Mining Showroom Location: Canada, United Kingdom, United States, France, Germany, Brazil, Mexico, Russia, Sri Lanka, Australia
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Marketing Type: New Product 2023 Warranty Of Core Components: 1 Year
Core Components: Gearbox, Motor Condition: New
Type: Circular Application: Food Processing
Voltage: 380v/415v/440v Dimension(L*W*H): Depends On Processing Trommel Screen
Weight: 2300 KG Warranty: 1 Year
Product Name: Factory Price Mobile Compost Tumbler Trommel Drum Screen Keyword: Compost Tumbler Trommel Drum Screen
Screen Material: Steel Bar, Steel Plate Punch Hole, Steel Wire Woven, Stainless Steel Power: 3-45KW
Dimension: According To Capacity Installation: Supply Manual To Guide User
Capacity: 50-500 Tons Per Hour Feeding Size: Less Than 300mm
Discharge Size: As Request Color: Yellow, White, Red, Blue, Gray( Or As Client Request)
Port: Qingdao, Dalian, Tianjin, Lianyungang, Dalian, Shanghai, Guangzhou( As Client Request)

Product Description

Factory price mobile compost tumbler trommel drum screen

Product Description

Municipal solid waste, construction waste, stone, compost, wood chips, sawdust, soil, coal, river sand, refractory materials, chemical, etc.



Mobile Compost Tumbler Trommel Drum Screen for Big Capacity of 50-500 tons per hour 0





Shaftless trommel screen working principle:
Due to the turning and rolling of the material in the screen drum, the material stuck in the screen hole can be ejected to prevent the screen hole from being clogged. GTS series shaftless trommel screen machine mainly consists of motor, gearbox, screen drum, frame, sealing cover, inlet and outlet. The screen drum is mounted obliquely on the frame. The motor is coupled to the drum unit via a coupling through a reducer to drive the screen drum unit to rotate about its axis. After the material enters the screen drum, due to the tilting and rotation of drum screen, the material on the screen surface is turned over and rolled, so that the qualified material (the product under the sieve) is discharged through the screen, and the unqualified material (the product on the sieve) ) is discharged through the end of the screen drum.





Mobile Compost Tumbler Trommel Drum Screen for Big Capacity of 50-500 tons per hour 1



Working Principle

1. lowering initial investment cost (comparative price)

2. saving operational cost (outstanding durability and simple mechanical structure)

3. reducing any additional cost in the future (high productivity & mobility)

4. GTS series can precisely select gold dust in highest yield rate of 98%.

5. High gold dust gathering capability by long-time and non-stop operation



technical parameters



Model

Trommeldiameter
(mm)

Trommel length
(mm)

Capacity
(m3/h)

motor power(KW)

Weight
(Kg)

Dimensions
(L*W*H)

MTS0818

800

1800

≤15

2.4

650

3.15*1.1*1.65

MTS1022

1000

2200

≤30

8.2

2750

4.3*1.9*2.45

MTS1230

1200

3000

≤60

10.6

3210

5.4*2.1*2.7

MTS1550

1500

5000

≤90

20

7900

9.4*2.2*2.9



Mobile Compost Tumbler Trommel Drum Screen for Big Capacity of 50-500 tons per hour 2





Packaging & Shipping

Mobile Compost Tumbler Trommel Drum Screen for Big Capacity of 50-500 tons per hour 3



Case

 Mobile Compost Tumbler Trommel Drum Screen for Big Capacity of 50-500 tons per hour 4Mobile Compost Tumbler Trommel Drum Screen for Big Capacity of 50-500 tons per hour 5Mobile Compost Tumbler Trommel Drum Screen for Big Capacity of 50-500 tons per hour 6

Customer

Mobile Compost Tumbler Trommel Drum Screen for Big Capacity of 50-500 tons per hour 7

Company Information

Mobile Compost Tumbler Trommel Drum Screen for Big Capacity of 50-500 tons per hour 8Mobile Compost Tumbler Trommel Drum Screen for Big Capacity of 50-500 tons per hour 9Mobile Compost Tumbler Trommel Drum Screen for Big Capacity of 50-500 tons per hour 10Mobile Compost Tumbler Trommel Drum Screen for Big Capacity of 50-500 tons per hour 11Mobile Compost Tumbler Trommel Drum Screen for Big Capacity of 50-500 tons per hour 12Mobile Compost Tumbler Trommel Drum Screen for Big Capacity of 50-500 tons per hour 13

FAQ

 Mobile Compost Tumbler Trommel Drum Screen for Big Capacity of 50-500 tons per hour 14
