Product Details:

Place of Origin: China
Brand Name: Sinolion
Certification: ISO CE

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: $4,100.00 - $28,750.00/sets
Get Best Price Contact Now

Detail Information

Applicable Industries: Building Material Shops, Manufacturing Plant, Other Showroom Location: None
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Marketing Type: Ordinary Product Warranty Of Core Components: 1 Year
Core Components: Engine, Bearing, Pump Condition: New
Type: Circular Application: Ore, Sieve Topsoil Compost
Voltage: 220V/380V Dimension(L*W*H): 5.4*2.1*2.7m
Weight: 3210 KG Warranty: 1 Year
Product Name: Mobile Trommel Screen Dimension: Depends On Model
Installation: Supply Manual To Guide User Feeding Size: Less Than 300mm
Color: Yellow, White, Red, Blue, Gray( Or As Client Request) Discharge Size: Less Than 6mm
MOQ: 1Set Advantage: High Separation Efficiency

Product Description

Electric Type Circular Screen Soil Compost Rotary Drum Sieve A Variety Of Models 0
Electric Type Circular Screen Soil Compost Rotary Drum Sieve A Variety Of Models 1
Electric Type Circular Screen Soil Compost Rotary Drum Sieve A Variety Of Models 2
Factory Price Straight Out A Variety Of Models Of Screen Soil Compost Rotary Drum Sieve Electric Type Equipment
Rotary drum sieve provide a simple,efficient and economical solution to upgrade a wide rang of material and optimize the subsequent process steps of recovery.This method of screening helps to reduce operating and investment cost and to increase product quality,while allowing rapid and large volume processing. (1) Select equipment model;
(2) Design and manufacture products according to clients' special requirement;
(3) Pre-check and accept products ahead of delivery;
(4)Help clients to draft solving plans;
(5)Guide clients how to install equipment successfully without problem.
Electric Type Circular Screen Soil Compost Rotary Drum Sieve A Variety Of Models 3
Electric Type Circular Screen Soil Compost Rotary Drum Sieve A Variety Of Models 4
Electric Type Circular Screen Soil Compost Rotary Drum Sieve A Variety Of Models 5
Electric Type Circular Screen Soil Compost Rotary Drum Sieve A Variety Of Models 6

Structure and Principle

The mobile trommel screen is cylindrical drum which is inclined and installed on the frame, the geared motor is connected to the drum device through a coupling, the driving drum will rotate around the axis direction. When the materials enters the drum device, due to the tilt and rotation of the drum device, the materials on the screen surface is overturned and rolled so that the fine material is discharged through the discharge port at the bottom of the back end of the drum of trommel screen, and the coarse material is discharged at the tail of the drum discharge. As the material in the drum devise flip, rolling, so the materials stuck in the sieve can be ejected to prevent the sieve blocking.
Electric Type Circular Screen Soil Compost Rotary Drum Sieve A Variety Of Models 7
Model
Trommeldiameter
(mm)
Trommel length
(mm)
Capacity
(m3/h)
motor power
(KW)
Weight
(Kg)
Dimensions
(L*W*H)
MTS0818
800
1800
≤15
2.4
650
3.15*1.1*1.65
MTS1022
1000
2200
≤30
8.2
2750
4.3*1.9*2.45
MTS1230
1200
3000
≤60
10.6
3210
5.4*2.1*2.7
MTS1550
1500
5000
≤90
20
7900
9.4*2.2*2.9
Electric Type Circular Screen Soil Compost Rotary Drum Sieve A Variety Of Models 8
Electric Type Circular Screen Soil Compost Rotary Drum Sieve A Variety Of Models 9
Electric Type Circular Screen Soil Compost Rotary Drum Sieve A Variety Of Models 10
Electric Type Circular Screen Soil Compost Rotary Drum Sieve A Variety Of Models 11
Electric Type Circular Screen Soil Compost Rotary Drum Sieve A Variety Of Models 12
Electric Type Circular Screen Soil Compost Rotary Drum Sieve A Variety Of Models 13
Electric Type Circular Screen Soil Compost Rotary Drum Sieve A Variety Of Models 14
Electric Type Circular Screen Soil Compost Rotary Drum Sieve A Variety Of Models 15
Electric Type Circular Screen Soil Compost Rotary Drum Sieve A Variety Of Models 16
Electric Type Circular Screen Soil Compost Rotary Drum Sieve A Variety Of Models 17
Electric Type Circular Screen Soil Compost Rotary Drum Sieve A Variety Of Models 18
Electric Type Circular Screen Soil Compost Rotary Drum Sieve A Variety Of Models 19
Electric Type Circular Screen Soil Compost Rotary Drum Sieve A Variety Of Models 20
Electric Type Circular Screen Soil Compost Rotary Drum Sieve A Variety Of Models 21
Electric Type Circular Screen Soil Compost Rotary Drum Sieve A Variety Of Models 22
Electric Type Circular Screen Soil Compost Rotary Drum Sieve A Variety Of Models 23
