Topsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch Hole
Product Details:
Place of Origin: | China |
Brand Name: | sinolion |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 unit |
---|---|
Price: | $4,100.00 - $28,750.00/sets |
Detail Information |
|||
Applicable Industries: | Building Material Shops, Manufacturing Plant, Construction Works , Energy & Mining | Showroom Location: | Canada, United Kingdom, United States, Italy, Germany, Brazil, Mexico, Russia, Malaysia, Australia |
---|---|---|---|
Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
Marketing Type: | New Product 2023 | Warranty Of Core Components: | 1 Year |
Core Components: | PLC, Engine, Bearing, Gearbox, Motor, Pressure Vessel, Gear, Pump | Condition: | New |
Type: | Gravity Separator | Voltage: | 380v/415v/440v |
Dimension(L*W*H): | Depends On Gold Washing Mining | Weight: | 2000 KG |
Warranty: | 1 Year | Product Name: | Mobile Without Shaft Trommel Screen For Compost, Topsoil |
Application: | Waste Sorting Machine Equipment | Power: | 3-45KW |
Screen Material: | Steel Bar, Steel Plate Punch Hole, Steel Wire Woven, Stainless Steel | Dimension: | According To Capacity |
Installation: | Supply Manual To Guide User | Capacity: | 50-500 Tons Per Hour |
Feeding Size: | Less Than 300mm | Color: | Yellow, White, Red, Blue, Gray( Or As Client Request) |
Product Description
Drum scrubber washer / mobile compost plant for fertilizer
Composting is an effective application method in the treatment of agricultural solid wastes, such as plant residues, composting of crop straws, agricultural processing wastes, and postage fertilizers for livestock and poultry manure. The Compost drum screen for organic fertilizer is designed to improve the screening rate of these fertilizers. The emergence of Compost drum screen for organic fertilizer has great economic benefits.
Working principle of the Compost drum screen
During the use of the Compost drum screen for organic fertilizer, it runs slowly and evenly, has small impact vibration, stable work, simple installation, and sometimes does not even need a special foundation. Can be placed directly on the flat floor or floor and under the silo. The roller screen can be provided with a comb-type cleaning mechanism. During the sieving process, the relative movement of the comb-type cleaning mechanism and the screening cylinder can be used to achieve the effect of uninterrupted cleaning of the screen body, so that the screening cylinder can be used in the entire working process Always keep clean, non-sticky, non-blocking, and not affect the screening effect.
Application:munlcpal solid waste,construction waste,stone,compost,wood chips,sawdust,soil,coal,river sand,refractory materials,chemiacal,etc
Technical parameter of shaftless trommel screen
Model | Capacity | Power | Screen | Discharge Size | Input Size | |
(m³/h) | (kw) | Diameter (mm) | Length (mm) | (mm) | (mm) | |
MTS0818 | 0-15 | 2.33 | 800 | 1800 | 0~100 | ≤300 |
MTS1022 | 0-30 | 8.8 | 1000 | 2200 | 0~100 | ≤300 |
MTS1230 | 0-60 | 11.4 | 1200 | 3000 | 0~100 | ≤300 |
MTS1550 | 0-90 | 18.4 | 1500 | 5000 | 0~100 | ≤300 |
![]() | ![]() | ![]() |
Garbage Trommel Screen | Compost Trommel screen | Compost Drum Sieve |
