Topsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch Hole

Topsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch Hole

Product Details:

Place of Origin: China
Brand Name: sinolion

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: $4,100.00 - $28,750.00/sets
Get Best Price Contact Now

Detail Information

Applicable Industries: Building Material Shops, Manufacturing Plant, Construction Works , Energy & Mining Showroom Location: Canada, United Kingdom, United States, Italy, Germany, Brazil, Mexico, Russia, Malaysia, Australia
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Marketing Type: New Product 2023 Warranty Of Core Components: 1 Year
Core Components: PLC, Engine, Bearing, Gearbox, Motor, Pressure Vessel, Gear, Pump Condition: New
Type: Gravity Separator Voltage: 380v/415v/440v
Dimension(L*W*H): Depends On Gold Washing Mining Weight: 2000 KG
Warranty: 1 Year Product Name: Mobile Without Shaft Trommel Screen For Compost, Topsoil
Application: Waste Sorting Machine Equipment Power: 3-45KW
Screen Material: Steel Bar, Steel Plate Punch Hole, Steel Wire Woven, Stainless Steel Dimension: According To Capacity
Installation: Supply Manual To Guide User Capacity: 50-500 Tons Per Hour
Feeding Size: Less Than 300mm Color: Yellow, White, Red, Blue, Gray( Or As Client Request)

Product Description

Drum scrubber washer / mobile compost plant for fertilizer

Product Description

Composting is an effective application method in the treatment of agricultural solid wastes, such as plant residues, composting of crop straws, agricultural processing wastes, and postage fertilizers for livestock and poultry manure. The Compost drum screen for organic fertilizer is designed to improve the screening rate of these fertilizers. The emergence of Compost drum screen for organic fertilizer has great economic benefits.



Working principle of the Compost drum screen
During the use of the Compost drum screen for organic fertilizer, it runs slowly and evenly, has small impact vibration, stable work, simple installation, and sometimes does not even need a special foundation. Can be placed directly on the flat floor or floor and under the silo. The roller screen can be provided with a comb-type cleaning mechanism. During the sieving process, the relative movement of the comb-type cleaning mechanism and the screening cylinder can be used to achieve the effect of uninterrupted cleaning of the screen body, so that the screening cylinder can be used in the entire working process Always keep clean, non-sticky, non-blocking, and not affect the screening effect.

Topsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch Hole 0Topsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch Hole 1



Application:munlcpal solid waste,construction waste,stone,compost,wood chips,sawdust,soil,coal,river sand,refractory materials,chemiacal,etc



Technical parameter of shaftless trommel screen



Model

Capacity

Power

 Screen

Discharge Size

Input Size

(m³/h)

(kw)

Diameter (mm)

Length (mm)

(mm)

(mm)

MTS0818

0-15

2.33

800

1800

0~100

≤300

MTS1022

0-30

8.8

1000

2200

0~100

≤300

MTS1230

0-60

11.4

1200

3000

0~100

≤300

MTS1550

0-90

18.4

1500

5000

0~100

≤300



Topsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch Hole 2

Topsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch Hole 3Topsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch Hole 4

Topsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch Hole 5Topsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch Hole 6Topsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch Hole 7Topsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch Hole 8Topsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch Hole 9Topsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch Hole 10

Topsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch Hole 11Topsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch Hole 12Topsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch Hole 13
