Requested Discharge Size Mobile Rotary Mining Sand Gravel Stone Drum Compost Trommel Screen

Requested Discharge Size Mobile Rotary Mining Sand Gravel Stone Drum Compost Trommel Screen

Product Details:

Place of Origin: Henan, China
Brand Name: sinolion

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: $250,000.00/sets 1-1 sets
Get Best Price Contact Now

Detail Information

Applicable Industries: Building Material Shops, Manufacturing Plant, Construction Works , Energy & Mining Showroom Location: None
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Marketing Type: New Product Warranty Of Core Components: 1 Year
Core Components: PLC, Engine, Motor, Pressure Vessel, Gear, Pump Condition: New
Type: Gravity Separator Voltage: 380v/415v/440v
Dimension(L*W*H): Depends On Gold Washing Mining Weight: 2200 KG
Warranty: 1 Year Product Name: Mobile Rotary Mining Sand Gravel Stone Drum Compost Trommel Screen
Application: Compost, Panning, MSW Power: 3-45KW
Screen Material: Steel Bar, Steel Plate Punch Hole, Steel Wire Woven, Stainless Steel Dimension: According To Capacity
Installation: Supply Manual To Guide User Capacity: 50-500 Tons Per Hour
Feeding Size: Less Than 300mm Discharge Size: As Request
Color: Yellow, White, Red, Blue, Gray( Or As Client Request)

Product Description

Mobile stationary rotary trommel palm wood chip trommel

Product Description

Drum screen is a new screening equipment based on the advantages of similar products both at home and abroad. It has a simple structure and is easy to maintain. This equipment has no vibration and noise. With a high screen transmittance rate, it is particularly suitable for the screening of wet and sticky materials. The screen pores can never be blocked. block proof rotary drum screen is widely used for the screening and grading of coal, sand, gravel and other materials in electric power, mining, metallurgy, building materials, chemical and other industries.



Requested Discharge Size Mobile Rotary Mining Sand Gravel Stone Drum Compost Trommel Screen 0

Requested Discharge Size Mobile Rotary Mining Sand Gravel Stone Drum Compost Trommel Screen 1Requested Discharge Size Mobile Rotary Mining Sand Gravel Stone Drum Compost Trommel Screen 2

Requested Discharge Size Mobile Rotary Mining Sand Gravel Stone Drum Compost Trommel Screen 3



Working Principle

1. lowering initial investment cost (comparative price)

2. saving operational cost (outstanding durability and simple mechanical structure)

3. reducing any additional cost in the future (high productivity & mobility)

4. GTS series can precisely select gold dust in highest yield rate of 98%.

5. High gold dust gathering capability by long-time and non-stop operation



Requested Discharge Size Mobile Rotary Mining Sand Gravel Stone Drum Compost Trommel Screen 4

technical parameters



Model

Capacity

(t/h)

Power

(kw)

Diameter

(mm)

Length

(mm)

Discharge

(mm)

Input

(mm)

Dimension
((mm)

YGTS1020

10-30

4.0

1000

2000

0-100

≤300

3390×1400×2140

YGTS1225

30-50

5.5

1200

2500

0-100

≤300

4146×1600×2680

YGTS1545

50-120

11

1500

4500

0-100

≤400

8160×2300×2500

YGTS1548

80-150

11

1500

4800

0-100

≤400

8460×2300×2500

YGTS1848

100-200

15

1800

4800

0-100

≤400

8460×2300×2700

YGTS2060

200-350

30

2000

6000

0-100

≤400

9680×2300x3420


if you need more photos and video , please click here to contact me :

Packaging & Shipping



Requested Discharge Size Mobile Rotary Mining Sand Gravel Stone Drum Compost Trommel Screen 5Requested Discharge Size Mobile Rotary Mining Sand Gravel Stone Drum Compost Trommel Screen 6Requested Discharge Size Mobile Rotary Mining Sand Gravel Stone Drum Compost Trommel Screen 7

Customer

 Requested Discharge Size Mobile Rotary Mining Sand Gravel Stone Drum Compost Trommel Screen 8


if you need more photos and video , please click here to contact me :

Company Information

Requested Discharge Size Mobile Rotary Mining Sand Gravel Stone Drum Compost Trommel Screen 9Requested Discharge Size Mobile Rotary Mining Sand Gravel Stone Drum Compost Trommel Screen 10

Requested Discharge Size Mobile Rotary Mining Sand Gravel Stone Drum Compost Trommel Screen 11

Requested Discharge Size Mobile Rotary Mining Sand Gravel Stone Drum Compost Trommel Screen 12


if you need more photos and video , please click here to contact me :

FAQ

Question 1: Can you give me a solution and quotation?

Answer: Absolutely sure, we can provide accurate solution and quotation, please give us background information, including, raw material, the capacity, max. input size, the output size, the usage of final products, etc.



Question 2: Way of payment
Answer: Welcome clients place the order by alibaba online one-touch! Deya also offers various ways of payment, T/T, against copy of B/L, L/C, D/A, D/P, West union, etc. All can be negotiated.



Question 3: What’s the delivery time after I pay the deposit ?

Answer: Normal delivery time within 10 to 20 working days, complete production line or larger equipment may take longer. Exact delivery shall be confirmed when place the order.



Question 4: After order equipment how do we slove the equipment installing?

Answer: For a small single equipment, we offer you user manual, customer will install and commissioning as operating introduction; For a complete production line, we will send our engineer to your workplace to help you install and commissioning untill machines work normally. Sinolion has several experienced technicians with passports ready to go for installation, when installation service is needed, the client should pay for technicians’ round way air tickets, salary(shall be confirmed before leaving), food and lodging, most importantly to guarantee the technicians’ safety.



Question 5: How long of your machine quality guarantee terms?

Answer: Equipment from Zhengzhou Sinolion Machinery Co., Ltd. with 18 months warranty, can be extended to 24 months as request.
