Professional Moving Trommel Screen for Easy Maintenance Composting Screening

Professional Moving Trommel Screen for Easy Maintenance Composting Screening

Product Details:

Place of Origin: Henan, China
Brand Name: Sinolion
Certification: CE ISO

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: $4,100.00/sets 1-1 sets
Get Best Price Contact Now

Detail Information

Applicable Industries: Energy & Mining Showroom Location: Canada, United States, Germany, South Africa
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Marketing Type: Ordinary Product Warranty Of Core Components: 1 Year
Core Components: Bearing, Pump Condition: New
Type: Circular Application: Ore, Compost,topsoil,cattle And Sheep Dung
Voltage: 380V/415V/440V Dimension(L*W*H): 3150*1100*1650mm
Weight: 770 KG Warranty: 1 Year
Product Name: Mobile Trommel Screen Installation: Supply Manual To Guide User
Keywords: Automation Feeding Size: Less Than 300mm
Discharge Size: Less Than 6mm Or As Request Color: Yellow, White, Red, Blue, Gray( Or As Client Request)
MOQ: 1Set Feature: Easy Maintenance

Product Description

Professional Moving Trommel Screen for Easy Maintenance Composting Screening 0
Professional Moving Trommel Screen for Easy Maintenance Composting Screening 1
Professional Moving Trommel Screen for Easy Maintenance Composting Screening 2
High Quality Moving Trommel Screen Designed For Professional Screening Composting
The mobile trommel screening machine is a screening equipment developed by our company for small and medium-sized and light materials such as compost, wood chips, cow dung, sand and gravel. It has the following characteristics: 1. Smooth operation and low noise; 2. Simple structure, maintenance Convenient; 3. The screen holes are not easy to block; 4. The screening efficiency is high; 5. The screen has a long service life and is easy to replace.
Professional Moving Trommel Screen for Easy Maintenance Composting Screening 3
Professional Moving Trommel Screen for Easy Maintenance Composting Screening 4
Professional Moving Trommel Screen for Easy Maintenance Composting Screening 5
Professional Moving Trommel Screen for Easy Maintenance Composting Screening 6

Structure and Principle

The mobile trommel screen is mainly composed of silo, screen drum, idler assembly, transmission part, discharge conveyor, brush, underframe, rear axle, traction, diesel generator, control cabinet, protective cover and other parts. The basic working principle of the trommel screen: the material is poured into the silo by the loader, and transported to the trommel screen by the conveyor on the silo, and then the motor reducer drives the idler to rotate the screen cylinder, and the material particles in the screen cylinder follow the screen. The drum rotates to a certain height, is thrown and dropped by gravity, and is filtered through the screen to form a screening. Finally, the screened materials are transported to different places by different conveyors.
Professional Moving Trommel Screen for Easy Maintenance Composting Screening 7
Model
Trommel diameter
(mm)
Trommel length
(mm)
Capacity
(m3/h)
Weight
(Kg)
Dimensions
(L*W*H)
MTS0818
800
1800
≤15
650
3.15*1.1*1.65
Professional Moving Trommel Screen for Easy Maintenance Composting Screening 8
Professional Moving Trommel Screen for Easy Maintenance Composting Screening 9
Professional Moving Trommel Screen for Easy Maintenance Composting Screening 10
Professional Moving Trommel Screen for Easy Maintenance Composting Screening 11
Professional Moving Trommel Screen for Easy Maintenance Composting Screening 12
Professional Moving Trommel Screen for Easy Maintenance Composting Screening 13
Professional Moving Trommel Screen for Easy Maintenance Composting Screening 14
Professional Moving Trommel Screen for Easy Maintenance Composting Screening 15
Professional Moving Trommel Screen for Easy Maintenance Composting Screening 16
Professional Moving Trommel Screen for Easy Maintenance Composting Screening 17
