Product Details:

Place of Origin: China
Brand Name: SINOLION

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: $4,100.00 - $20,730.00/sets
Get Best Price Contact Now

Detail Information

Applicable Industries: Farms, Energy & Mining Showroom Location: Australia
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Marketing Type: New Product 2023 Warranty Of Core Components: 1 Year
Core Components: Motor, Gear, Pump Condition: New
Type: Gravity Separator Voltage: 110V-380V
Dimension(L*W*H): Customizable Weight: 5000 KG, 2200-12800
Warranty: 1 Year Product Name: Compost Trommel Screen
Power: 3-30KW Dimension: Depends On Model
Application: Organic Fertilizer, Construction & Demolition C&D, Glass, Mulch, MSW Installation: Supply Manual To Guide User
Capacity: 30-150 Tons Per Hour Feeding Size: Less Than 300mm
Discharge Size: Less Than 6mm Color: Yellow, White, Red, Blue, Gray( Or As Client Request)

Product Description

Depends on Model Compost Trommel Multi Screen for Mining Trommel Screening Plant Sale 0
Depends on Model Compost Trommel Multi Screen for Mining Trommel Screening Plant Sale 1
Depends on Model Compost Trommel Multi Screen for Mining Trommel Screening Plant Sale 2
Mobile Trommel Screen Waste Rotary Drum Screen For Sand Washing Wast Trommel Screen
The mobile trommel screening machine is a screening equipment developed by our company for small and medium-sized and light materials such as compost, wood chips, cow dung, sand and gravel. It has the following characteristics: 1. Smooth operation and low noise; 2. Simple structure, maintenance Convenient; 3. The screen holes are not easy to block; 4. The screening efficiency is high; 5. The screen has a long service life and is easy to replace.
Depends on Model Compost Trommel Multi Screen for Mining Trommel Screening Plant Sale 3
Depends on Model Compost Trommel Multi Screen for Mining Trommel Screening Plant Sale 4
Depends on Model Compost Trommel Multi Screen for Mining Trommel Screening Plant Sale 5
Depends on Model Compost Trommel Multi Screen for Mining Trommel Screening Plant Sale 6

Structure and Principle

The mobile trommel screen is mainly composed of silo, screen drum, idler assembly, transmission part, discharge conveyor, brush, underframe, rear axle, traction, diesel generator, control cabinet, protective cover and other parts. The basic working principle of the trommel screen: the material is poured into the silo by the loader, and transported to the trommel screen by the conveyor on the silo, and then the motor reducer drives the idler to rotate the screen cylinder, and the material particles in the screen cylinder follow the screen. The drum rotates to a certain height, is thrown and dropped by gravity, and is filtered through the screen to form a screening. Finally, the screened materials are transported to different places by different conveyors.
Depends on Model Compost Trommel Multi Screen for Mining Trommel Screening Plant Sale 7
Model
Trommeldiameter
(mm)
Trommel length
(mm)
Capacity
(m3/h)
motor power
(KW)
Weight
(Kg)
Dimensions
(L*W*H)
MTS0818
800
1800
≤15
2.4
650
3.15*1.1*1.65
MTS1022
1000
2200
≤30
8.2
2750
4.3*1.9*2.45
MTS1230
1200
3000
≤60
10.6
3210
5.4*2.1*2.7
MTS1550
1500
5000
≤90
20
7900
9.4*2.2*2.9
Depends on Model Compost Trommel Multi Screen for Mining Trommel Screening Plant Sale 8
Depends on Model Compost Trommel Multi Screen for Mining Trommel Screening Plant Sale 9
Depends on Model Compost Trommel Multi Screen for Mining Trommel Screening Plant Sale 10
Depends on Model Compost Trommel Multi Screen for Mining Trommel Screening Plant Sale 11
Depends on Model Compost Trommel Multi Screen for Mining Trommel Screening Plant Sale 12
Depends on Model Compost Trommel Multi Screen for Mining Trommel Screening Plant Sale 13
Depends on Model Compost Trommel Multi Screen for Mining Trommel Screening Plant Sale 14
Depends on Model Compost Trommel Multi Screen for Mining Trommel Screening Plant Sale 15
Depends on Model Compost Trommel Multi Screen for Mining Trommel Screening Plant Sale 16
Depends on Model Compost Trommel Multi Screen for Mining Trommel Screening Plant Sale 17
Depends on Model Compost Trommel Multi Screen for Mining Trommel Screening Plant Sale 18
Depends on Model Compost Trommel Multi Screen for Mining Trommel Screening Plant Sale 19
Depends on Model Compost Trommel Multi Screen for Mining Trommel Screening Plant Sale 20
Depends on Model Compost Trommel Multi Screen for Mining Trommel Screening Plant Sale 21
