Product Details:

Place of Origin: Henan, China
Brand Name: sionlion

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: $4,100.00/sets >=1 sets
Get Best Price Contact Now

Detail Information

Applicable Industries: Food & Beverage Factory, Farms, Home Use, Energy & Mining Showroom Location: Canada, United States, Australia
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Marketing Type: Ordinary Product Warranty Of Core Components: 1 Year
Core Components: Engine, Bearing, Pump Condition: New
Type: Circular Application: Ore, Mining Separation
Voltage: 110v-440v Dimension(L*W*H): Customized
Weight: 2000 KG Warranty: 1 Year
Product Name: Mobile Trommel Screen After-sales Service Provided: Video Technical Support
Color: Customized Making Raw Materials: Molybdenum Ore
Quality: High Reputation Screen Size: 3-10mm / Customized
Keywords: Alluvial Gold Mining Machine Usage: Mining Separatoion
Main Products: Mining Feeder

Product Description

2000 KG Topsoil Sand Gravel Trommel Screen for Mobile Home Compost Aggregate Screening 0
2000 KG Topsoil Sand Gravel Trommel Screen for Mobile Home Compost Aggregate Screening 1
2000 KG Topsoil Sand Gravel Trommel Screen for Mobile Home Compost Aggregate Screening 2
Mobile Trommel Screen Waste Rotary Drum Screen For Sand Washing Wast Trommel Screen
The mobile trommel screening machine is a screening equipment developed by our company for small and medium-sized and light materials such as compost, wood chips, cow dung, sand and gravel. It has the following characteristics: 1. Smooth operation and low noise; 2. Simple structure, maintenance Convenient; 3. The screen holes are not easy to block; 4. The screening efficiency is high; 5. The screen has a long service life and is easy to replace.
2000 KG Topsoil Sand Gravel Trommel Screen for Mobile Home Compost Aggregate Screening 3
2000 KG Topsoil Sand Gravel Trommel Screen for Mobile Home Compost Aggregate Screening 4
2000 KG Topsoil Sand Gravel Trommel Screen for Mobile Home Compost Aggregate Screening 5
2000 KG Topsoil Sand Gravel Trommel Screen for Mobile Home Compost Aggregate Screening 6

Structure and Principle

The mobile trommel screen is mainly composed of silo, screen drum, idler assembly, transmission part, discharge conveyor, brush, underframe, rear axle, traction, diesel generator, control cabinet, protective cover and other parts. The basic working principle of the trommel screen: the material is poured into the silo by the loader, and transported to the trommel screen by the conveyor on the silo, and then the motor reducer drives the idler to rotate the screen cylinder, and the material particles in the screen cylinder follow the screen. The drum rotates to a certain height, is thrown and dropped by gravity, and is filtered through the screen to form a screening. Finally, the screened materials are transported to different places by different conveyors.
2000 KG Topsoil Sand Gravel Trommel Screen for Mobile Home Compost Aggregate Screening 7
Model
Trommeldiameter
(mm)
Trommel length
(mm)
Capacity
(m3/h)
motor power
(KW)
Weight
(Kg)
Dimensions
(L*W*H)
MTS0818
800
1800
≤15
2.4
650
3.15*1.1*1.65
MTS1022
1000
2200
≤30
8.2
2750
4.3*1.9*2.45
MTS1230
1200
3000
≤60
10.6
3210
5.4*2.1*2.7
MTS1550
1500
5000
≤90
20
7900
9.4*2.2*2.9
2000 KG Topsoil Sand Gravel Trommel Screen for Mobile Home Compost Aggregate Screening 8
2000 KG Topsoil Sand Gravel Trommel Screen for Mobile Home Compost Aggregate Screening 9
2000 KG Topsoil Sand Gravel Trommel Screen for Mobile Home Compost Aggregate Screening 10
2000 KG Topsoil Sand Gravel Trommel Screen for Mobile Home Compost Aggregate Screening 11
2000 KG Topsoil Sand Gravel Trommel Screen for Mobile Home Compost Aggregate Screening 12
2000 KG Topsoil Sand Gravel Trommel Screen for Mobile Home Compost Aggregate Screening 13
2000 KG Topsoil Sand Gravel Trommel Screen for Mobile Home Compost Aggregate Screening 14
2000 KG Topsoil Sand Gravel Trommel Screen for Mobile Home Compost Aggregate Screening 15
We can customize different sizes of screens according to your needs,Discuss your project!
