Type: Drying Oven Application: Briquettes Processing, Briquette Dryer
Condition: New Voltage: 220-440V
Power: 5.5kw Dimension(L*W*H): Refer To The Specific Model
Key Selling Points: Automatic Warranty: 12 Months
Weight (KG): 1800 Applicable Industries: Manufacturing Plant, Energy & Mining
Showroom Location: None Marketing Type: Ordinary Product
Machinery Test Report: Provided Video Outgoing-inspection: Provided
Warranty Of Core Components: 1 Year Core Components: Gear, Motor, Gearbox
After-sales Service Provided: Engineers Available To Service Machinery Overseas Product Name: Briquette Mesh Belt Dryer Machine
Heating Source: Steam,electricity, Gas Oil, Etc Material: Stainless /carbon Steel
Installation: Engineer's Guidance Usage: Briquette Dryer Machine
Name: Briquette Dryer Mesh Belt Width: 0.6-2m
Mesh Belt Layer: 1-8 Layer

Product Description

Product Introduction

Continuous Charcoal Coal Briquettes Mesh Belt Drying Equipment Dryer for different material briquettes

The riquette mesh belt dryer also named chain plate dryer, it is a kind of drying machine use steel net belt as transport carrier and dry material continuously. Because transmission belt is mesh, so this dryer can dry regular or irregular shape various briquette (for examples: coal, briquette of all kinds of mineral, food and vegetables). This briquette mesh belt dryer can be used with other supporting machine and also can be used alone. Especially it is the ideal dry equipment of various kinds of materials briquette production line.

Installation Guidance Provided Continuous Mesh Belt Drying Equipment for Briquettes 0

Features of briquette dryer mesh belt dryer machine

 1. Small space to take. 2. Low investment. 3. High efficiency.
4. Large output and high evaporation strength
5. Standardized production, the number of segments can be increased according to output and work shop
Product Parameters
Model
DW-1.2-8
DW-1.2-10
DW-1.6-8
DW-1.6-10
DW-2-8
DW-2-10
DW-2-20
Quantity of unit
4
5
4
5
4
5
10
Width of belt(m)
1.2
1.6
2
Length of dry section(m)
8
10
8
10
8
10
20
Operation temperature(oC)
50-140
Steam pressure(MPa)
0.2-0.8
Steam consumption (kg/h)
120-300
150-375
150-400
180-500
180-500
225-600
450-1200
Drying time (h)
0.2-1.2
1.25-1.5
0.2-1.2
0.25-1.5
0.2-1.2
0.25-1.5
0.5-3
Drying capacity(kg water/h)
60-160
80-200
85-220
100-260
100-260
120-300
240-600
Total power (kw)
11.4
13.6
14.6
18.7
19.7
24.5
51

Overall size
L(m)
9.56
11.56
9.56
11.56
9.56
11.56
21.56
W(m)
1.49
1.49
1.9
1.9
2.32
2.32
2.32
H(m)
2.3
2.3
2.4
2.4
2.5
2.5
2.5
Product Details Show
Installation Guidance Provided Continuous Mesh Belt Drying Equipment for Briquettes 1
Installation Guidance Provided Continuous Mesh Belt Drying Equipment for Briquettes 2
Installation Guidance Provided Continuous Mesh Belt Drying Equipment for Briquettes 3
Installation Guidance Provided Continuous Mesh Belt Drying Equipment for Briquettes 4
Installation Guidance Provided Continuous Mesh Belt Drying Equipment for Briquettes 5
Installation Guidance Provided Continuous Mesh Belt Drying Equipment for Briquettes 6
Installation Guidance Provided Continuous Mesh Belt Drying Equipment for Briquettes 7
Installation Guidance Provided Continuous Mesh Belt Drying Equipment for Briquettes 8
Installation Guidance Provided Continuous Mesh Belt Drying Equipment for Briquettes 9
Installation Guidance Provided Continuous Mesh Belt Drying Equipment for Briquettes 10
Installation Guidance Provided Continuous Mesh Belt Drying Equipment for Briquettes 11
Installation Guidance Provided Continuous Mesh Belt Drying Equipment for Briquettes 12
Why Choose Us
Installation Guidance Provided Continuous Mesh Belt Drying Equipment for Briquettes 13

About sinolion company

1,Our Company professional research and supply briquette mesh belt dryer machine many years, we have lots experiences to help our clients choose workable mesh belt dryer to meet client's demand.

Installation Guidance Provided Continuous Mesh Belt Drying Equipment for Briquettes 14

Mesh belt dryer technology

2, More than five engineers, professional research dryer technology, improving the dryer production process, to achieve customer satisfaction.

Installation Guidance Provided Continuous Mesh Belt Drying Equipment for Briquettes 15

Service

3, Professional sales team to provide pre-sale service, let customers fully understand briuqette mesh belt dryer, specialist is responsible for the after-sale service, solve practical problems when mesh belt dryer working.

Product Processing
Installation Guidance Provided Continuous Mesh Belt Drying Equipment for Briquettes 16

Steel belt making process

The belt material of briquette mesh belt dryer can be carbon stell or Stainless steel. the material depands on dry material. We will use carbon steel if dry material is coal briquette, charcoal briquette, carbon black briquette and other mineral briquette.
When the briquette mesh belt dryer dry fruits, vegetables, medicinal herbs, we must use stainless steel belt.

Middle section mading of briuqette mesh belt dryer

1.The shaft wall of briquette mesh belt dryer including outside, inside, channel steel. all 3 layers is 3mm high carbon steel.
2.Upper of the dryer, there are 2 layers 2mm high carbon steel.
3. Bottom of the dryer, there is 1 layer 3mm high carbon steel.
4. The frame of the middle section is 3mm high carbon steel.
5. U-channel steel is 3mm thickness high carbon steel.
The material also can use stainless steel when dry fruits, vegetables, medicinal herbs etc.

Installation Guidance Provided Continuous Mesh Belt Drying Equipment for Briquettes 17
Installation Guidance Provided Continuous Mesh Belt Drying Equipment for Briquettes 18

Mesh belt Detail

1,Shaft diameter 80mm

2, Sprocket diameter pitch=200mm

3,Mesh belt with chain use SUS 304

4, Bearing No. UCT316

Installation Guidance Provided Continuous Mesh Belt Drying Equipment for Briquettes 19

Mesh belt parameter

1,Spring length100mm;

inner holeΦ82mm; thicknessΦ16
2.Mesh wire’s thickness Φ3mm
3. Wire feed diameter Φ3mm

Installation Guidance Provided Continuous Mesh Belt Drying Equipment for Briquettes 20

Bearing of mesh belt dryer

Bearing No.according to belt layer.

1 layer mesh belt dryer, bearing 4 sets

Packing & Delivery
Installation Guidance Provided Continuous Mesh Belt Drying Equipment for Briquettes 21

Briquette Mesh belt dryer packing

The middle dry sevtion of briquette mesh belt dryer is 2 meters , so it is very easy to loading them into containers.  the briquette mesh belt dryer head and tail is 2.5m, so the complete briquette mesh belt dryer can be loaded in containers separately, the mesh belt will rolled and delivery together with briquette mesh belt dryer. other parts like dryer motore, fan, Electric control cabinet will packing in wood box or steel box.
