Manure Sieve Organic Fertilizer Composting Machine Equipment Gray Mobile Trommel Screen
Product Details:
| Place of Origin: | China |
| Brand Name: | Sinolion |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 unit |
|---|---|
| Price: | $15,900.00/sets 1-1 sets |
|
Detail Information |
|||
| Applicable Industries: | Energy & Mining | Showroom Location: | Canada, United States, Germany, Russia, Colombia, Romania, South Africa, Nigeria |
|---|---|---|---|
| Condition: | New | Type: | Gravity Separator |
| Production Capacity: | 60m³/h | Voltage: | 220V/380V |
| Dimension(L*W*H): | 5.4*2.1*2.7m | Weight: | 2900 KG |
| Warranty: | 1 Year | Marketing Type: | New Product 2022 |
| Machinery Test Report: | Provided | Video Outgoing-inspection: | Provided |
| Warranty Of Core Components: | 1 Year | Core Components: | Motor, PLC, Engine, Gearbox |
| Key Selling Points: | High Rigidity | Product Name: | Mobile Trommel Screen |
| Screen Material: | Steel Bar, Steel Plate, Manganese Steel Wire Woven, Stainl | Discharge Size: | Less Than 6mm Or As Request |
| Application: | Topsoil,compost, Mulch, Organics, Bark, MSW | Feeding Size: | Less Than 300mm |
| Power: | 3-45KW | Installation: | Supply Manual To Guide User |
| Color: | Yellow, White, Red, Blue, Gray( Or As Client Request) | Certificate: | CE |
| MOQ: | 1Set | ||
Product Description
High Performance Manure Sieve Organic Fertilizer Composting Machine Equipment Mobile Trommel Screen
The mobile trommel screen provides a simple, efficient and economical screening solution for all kinds of materials, it also provides optimization treatment for the subsequent processing. This solution helps reduce operational processes and reduces investment costs and improves product quality, while allowing rapid and large volume processing.
Structure and Principle
The mobile trommel screen is mainly composed of silo, screen drum, idler assembly, transmission part, discharge conveyor, brush, underframe, rear axle, traction, diesel generator, control cabinet, protective cover and other parts. The basic working principle of the trommel screen: the material is poured into the silo by the loader, and transported to the trommel screen by the conveyor on the silo, and then the motor reducer drives the idler to rotate the screen cylinder, and the material particles in the screen cylinder follow the screen. The drum rotates to a certain height, is thrown and dropped by gravity, and is filtered through the screen to form a screening. Finally, the screened materials are transported to different places by different conveyors.
|
Product Type
|
Product Model
|
Trommel Diameter
|
Trommel Length
|
Trommel Power
|
|
Mobile trommel screen
|
MTS1230
|
1.2m
|
3m
|
4kw
|
