Professional Aluminum Dross Sorting Compost Trommel Screener With 380V/415V/440V Voltage
Product Details:
| Place of Origin: | Henan, China |
| Brand Name: | Sinolion |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 unit |
|---|---|
| Price: | $4,000.00/sets >=1 sets |
| Packaging Details: | All products will be processed to be rustproof and moisture proof before delivery. <br>20GP container or 40GP container <br>Equipment is packed with plastic wrap or steel case or free fumigation wooden cases, depends on machine weight. <br>Motor is packed |
| Supply Ability: | 40 Set/Sets per Month wood chips sifter design |
|
Detail Information |
|||
| Applicable Industries: | Energy & Mining | Showroom Location: | United Kingdom, Mexico, Australia |
|---|---|---|---|
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 1 Year |
| Core Components: | Motor | Condition: | New |
| Type: | Compost Trommel Screener | Application: | Sawdust, Firewood, Topsoil, Compost, Solid, Municipal Soild Waste, Glass, Mulch, Organics, Bark, MSW, Municipal Solid Waste |
| Voltage: | 380V/415V/440V | Dimension(L*W*H): | As Per Different Model |
| Weight: | 2200 KG | Warranty: | 1 Year |
| Product Name: | Rotary Type Wood Chips Garbage Firewood Trommel Screen Factory Price | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
| Screen Material: | Steel Bar, Steel Plate, Manganese Steel Wire Woven, Stainless Steel | Dimension: | 5600x2015x2010mm |
| Installation: | Supply Manual To Guide User | Capacity: | 1-200 Tons Per Hour |
| Feeding Size: | Less Than 300mm | Discharge Size: | Less Than 6mm Or As Request |
| Color: | Yellow, White, Red, Blue, Gray( Or As Client Request) | Port: | Qingdao, Dalian, Tianjin, Lianyungang, Dalian, Shanghai, Guangzhou( As Client Request) |
Product Description
The wood often comes with bark, sawdust, mud, dirt and small pieces of wood. our firwood tumbler can clean this debris from the wood. It would be good to include a secondary screen to separate dirt from the smaller pieces of wood, the small pieces of wood can be sold as a separate product.
Rotary firewood screener functions: configured for classification, screening, grading, washing
Rotary firewood screener type: open type, closed type.
Rotary firewood screener construction: carbon steel, stainless steel.
Rotary firewood tumbler applications: widely used in compost, food waste, glass, wood mulch, organics, shredded plastic, topsoil, wood waste, ssphalt shingles, bark, municipal solid waste, chemical, coal, construction, gold mine, plastic, quarry, recycling, metallurgy, mineral-selecting industries, etc.
Application of firewood tumbler:
According to different sizing specification, the numbers of hierarchical level could be from one to four. Materials whose size is larger than the screen mesh of the last part will be discharged from the outlet.
During the process of operation, its movement is slowly and steady and installation is simple, sometime no need any special foundation and could be placed on smooth ground or floor.
It is the most commonly used classification device for refractory material, coal, river sand and mixture of sand and stone.
Rotary firewood tumbler specifications:
| Model | Capacity | Power | Screen Diameter | Screen Length | Discharge Size | Input Size | Dimension (L×W×H) | Weight |
| (t/h) | (kw) | (mm) | (mm) | (mm) | (mm) | (mm) | (Kg) | |
| GTS1015 | 50 | 3.0 | 1000 | 1500 | 0~100 | ≤300 | 2600×1400×1700 | 2200 |
| GTS1020 | 100 | 4.0 | 1000 | 2000 | 0~100 | ≤300 | 3390×1400×2140 | 2800 |
| GTS1225 | 160 | 5.5 | 1200 | 2500 | 0~100 | ≤300 | 4146×1600×2680 | 4200 |
| GTS1530 | 250 | 7.5 | 1500 | 3000 | 0~100 | ≤300 | 4460×1900×2820 | 5100 |
| GTS1545 | 350 | 11 | 1500 | 4500 | 0~100 | ≤400 | 5960×1900×3080 | 6000 |
| GTS1848 | 450 | 15 | 1800 | 4800 | 0~100 | ≤400 | 6500×2350×4000 | 7500 |
| GTS2055 | 600 | 22 | 2000 | 5500 | 0~100 | ≤400 | 7500×2550×4800 | 9600 |
| GTS2265 | 800 | 30 | 2000 | 6500 | 0~100 | ≤400 | 8500×2750×5000 | 12800 |
Question 1: What’s the delivery time after I pay the deposit ?
Answer: We will delivery the goods within 10-15 working days after receipt of the prepayment.
Question 2: Is mineral samples analysis available?
Answer: Sure, we supply samples analysis service for free. After the testing, we will give you the reasonable flow chart, suitable solution and equipment selection.
Question 3: Do you have client in my country?
Answer: Our products have exported to Malaysia, Indonesia, the Philippines, Vietnam, Myanmar, Korea, Singapore, Thailand, Mongolia, Ghana, Sudan, Serbia, Kazakhstan, Canada, Nigeria, Australia, Chile, Brazil, Columbia, Ecuador, Peru, Bolivia, etc
Question 4: How long of your machine quality guarantee terms ?
Answer: Quality guarantee time is one year(wearing parts excluded).
| | |
