Topsoil Screening and Easy to Operate Topsoil Rotary Screen for Fertilizer
Product Details:
| Place of Origin: | Henan, China |
| Brand Name: | Sinolion |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 unit |
|---|---|
| Price: | $4,100.00/sets >=1 sets |
|
Detail Information |
|||
| Applicable Industries: | Farms, Home Use, Energy & Mining | Showroom Location: | Canada, United States, Australia |
|---|---|---|---|
| Condition: | New | Type: | Gravity Separator |
| Production Capacity: | 98% | Voltage: | 220-420V, Customized |
| Dimension(L*W*H): | 5.4*2.1*2.7m | Weight: | 3210 KG |
| Warranty: | 1 Year | Marketing Type: | Ordinary Product |
| Machinery Test Report: | Provided | Video Outgoing-inspection: | Provided |
| Warranty Of Core Components: | 1 Year | Core Components: | Motor, Engine |
| Key Selling Points: | Competitive Price | Product Name: | Mobile Topsoil Trommel Screen |
| Usage: | Remove Dirty Soil,separate Different Sizes | Keywords: | High Quality, Easy To Operate |
| Capacity: | 60m3/h | Feature: | High Performance |
| After Sale Service: | Supply Technical Support At Any Time | Installation: | Send Video, CAD Drawing, And/or Dispatch Engineer |
| Trommel Diameter: | 1200mm | Trommel Length: | 3000mm |
Product Description
Factory Price High Quality Fertilizer Rotary Screen Topsoil Trommel Screen Topsoil Rotary Screen
1. Designed to fit your operation- Trommel screen can be customized to meet different capacity and working site . 2. Free from pollution- Fully enclosed structure,no dust pollution,improve working conditions for operators as well. 3.Variable application range-Compost,chemical,coal,plastic,recycling,metallurgy,mineral-selecting etc. 4. Superior design-Simple structure,easy maintenance,steady operation,low energy consumption.
Structure and Principle
The mobile trommel screen is mainly composed of hopper, screen drum, idler assembly, transmission part, discharge conveyor, brush, underframe, rear axle, traction, diesel generator, control cabinet, protective cover and other parts. The basic working principle of the trommel screen: the material is poured into the silo by the loader, and transported to the trommel screen by the conveyor on the silo, and then the motor reducer drives the idler to rotate the screen cylinder, and the material particles in the screen cylinder follow the screen. The drum rotates to a certain height, is thrown and dropped by gravity, and is filtered through the screen to form a screening. Finally, the screened materials are transported to different places by different conveyors.
Model | Trommeldiameter (mm) | Trommel length (mm) | Capacity (m3/h) | motor power （KW） | Weight (Kg) | Dimensions (L*W*H) |
MTS1230 | 1200 | 3000 | ≤60 | 10.6 | 3210 | 5.4*2.1*2.7 |
