50t/h Jaw Crusher for Pebble Gravel Hardcore Stone PC-400*300 PC-600*400 Hammer Mill List
Product Details:
| Place of Origin: | Henan, China |
| Brand Name: | Sinolion |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 unit |
|---|---|
| Price: | $2,200.00/sets >=1 sets |
|
Detail Information |
|||
| Applicable Industries: | Energy & Mining | Showroom Location: | Indonesia, Kenya, South Korea |
|---|---|---|---|
| Condition: | New | Type: | Hammer Crusher, Diesel Engine Or Electric Motor |
| Application: | Boulders, Brick , Cobble, Stone, Stone, Rock, Gold Ore, Clay, Pebble, Sand, Gravel, Glass | Motor Type: | AC Motor |
| Capacity(t/h): | 1-280t/h | Dimension(L*W*H): | As Per Different Model |
| Weight: | 1200 KG | Warranty: | 24 Months Excluding Spare Parts |
| Marketing Type: | New Product 2020 | Machinery Test Report: | Provided |
| Video Outgoing-inspection: | Provided | Warranty Of Core Components: | 1 Year |
| Core Components: | Motor | Key Selling Points: | High Productivity |
| Model: | PC Series Portable Hammer Crusher Mill Machine | Installation: | Supply Manual And Send Engineer To Guide User |
| Feeding Size: | 0-350mm | Discharge Size: | Adjustable |
| Screen Grade Size: | Adjustable | Hammer Heads Material: | 40Cr |
| Wearing Parts: | Hammer Head And Side Plates | Color: | Yellow, White, Red, Blue, Gray( Or As Client Request) |
Product Description
Hammer crusher specifications description:
A hammer mill is a crusher whose purpose is to shred or crush aggregate material into smaller pieces by the repeated blows of little hammers. The basic principle is straightforward. A hammer crusher is essentially a steel drum containing a vertical or horizontal rotating shaft or drum on which hammers are mounted. The hammers are free to swing on the ends of the cross, or fixed to the central rotor. The rotor is spun at a high speed inside the drum while material is fed into a feed hopper. The material is impacted by the hammer bars and is thereby shredded and expelled through screens in the drum of a selected size. The hammer crusher can be used as a primary, secondary, or tertiary crusher.
Hammer crusher drawing:
Hammer mill specifications:
| Model | Feed size (mm) | Discharge size (mm) | Capacity (t/h) | Power (kw) | Weight (T) |
| PC400×300 | ≤100 | ≤10 | 5-10 | 11 | 0.8 |
| PC600×400 | ≤120 | ≤15 | 10-25 | 18.5 | 1.5 |
| PC800×600 | ≤120 | ≤15 | 20-25 | 55 | 3.1 |
| PC1000×800 | ≤200 | ≤15 | 20-40 | 90 | 7.9 |
| PC1000×1000 | ≤200 | ≤15 | 30-70 | 132 | 8.66 |
| PC1250×1250 | ≤250 | ≤25 | 50-100 | 185 | 10.5 |
| PC1300×1200 | ≤250 | ≤29 | 60-150 | 240 | 13.6 |
| PC1400×1400 | ≤280 | ≤30 | 120-170 | 280 | 16.2 |
| PC1600×1600 | ≤350 | ≤30 | 200-280 | 450 | 19.6 |
Screen for choice or as request:
Hammer heads:
1. Waterproof packing with the international export standard by 20GP, 40GP, 40HQ container.
2. Equipment Fittings, Electric Motor and Power Cabinet will be packed in Wooden Case or Iron Box. Other Equipment will be packed by Color-Stripes Plastic Cloth.
3. Or as per customer's requirements.
Question 1: What’s the delivery time after I pay the deposit ?
Answer: We will delivery the goods within 10-15 working days after receipt of the prepayment.
Question 2: Is mineral samples analysis available?
Answer: Sure, we supply samples analysis service for free. After the testing, we will give you the reasonable flow chart, suitable solution and equipment selection.
Question 3: Do you have client in my country?
Answer: Our products have exported to Malaysia, Indonesia, the Philippines, Vietnam, Myanmar, Korea, Singapore, Thailand, Mongolia, Ghana, Sudan, Serbia, Kazakhstan, Canada, Nigeria, Australia, Chile, Brazil, Columbia, Ecuador, Peru, Bolivia, etc
Question 4: How long of your machine quality guarantee terms ?
Answer: Quality guarantee time is one year(wearing parts excluded).
