Long Life Wear Parts Cone Crusher for Minerals in Mobile Rock Ore Mini Plant
Product Details:
Place of Origin: | Henan, China |
Brand Name: | Sinolion |
Certification: | ISO9001:2008 |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 unit |
---|---|
Price: | $2,000.00/sets >=1 sets |
Packaging Details: | All products will be processed to be rustproof and moisture proof before delivery. 20GP container or 40GP container Equipment is packed with plastic wrap or steel case or free fumigation wooden cases, depends on machine weight. Motor is packed with steel c |
Supply Ability: | 50 Set/Sets per Month |
Detail Information |
|||
Applicable Industries: | Energy & Mining | Showroom Location: | None |
---|---|---|---|
Condition: | New | Type: | Cone Crusher, Motor Driving |
Application: | Stone, Ore, Glass, Coal | Motor Type: | AC Motor |
Capacity(t/h): | 20-100t/h | Dimension(L*W*H): | As Per Different Model |
Weight: | 1700 KG | Warranty: | 18 Month |
Marketing Type: | New Product 2020 | Machinery Test Report: | Provided |
Video Outgoing-inspection: | Provided | Warranty Of Core Components: | 1 Year |
Core Components: | Motor | Key Selling Points: | Automatic |
Model: | Cone Crusher | Installation: | Supply Manual And Send Engineer To Guide User |
Feeding Size: | 0-25mm | Discharge Size: | Adjustable From 0-40mm |
Concave Material: | Manganese Steel | Motor Quantity: | 1 Motor |
Wearing Parts: | Concave Bowl Liner | Price: | Negotiable |
Color: | Yellow, White, Red, Blue, Gray( Or As Client Request) | Local Service Location: | None |
Port: | Qingdao, Tianjin, Lianyungang, Shanghai Dalian Guangzhou( As Client Request) |
Product Description
Cone Crushers are commonly used for secondary, tertiary or quaternary crushing. It genius lies in it's durability and simplicity - there are only nine moving parts to these heavy duty machines. This cone crusher is able to pass uncrushable materials that have somehow entered the crushing chamber by opening the crushing cavity hydraulically instead of using springs. The importance of the cone crusher has significantly increased, because of its effectiveness and lower operating costs. It is able to crush hard, medium-hard, and many different types of materials, while providing a reliable and efficient crushing operation.
Cone crusher techinical parameters:
Model | Diameter of cone(mm) | Discharging Size (mm) | Max Feeding Size (mm) | Capacity (t/h) | Power | Weight | Dimensions |
PYB-600 | 600 | 12-25 | 65 | 15-25 | 30 | 5.5 | 1740*1225*1940 |
PYD-600 | 600 | 3-13 | 36 | 5-23 | 30 | 5.5 | 1740*1225*1940 |
PYB-900 | 900 | 15-50 | 115 | 50-90 | 55 | 10.18 | 1990*1640*2380 |
PYZ-900 | 900 | 5-20 | 60 | 20-65 | 55 | 10.19 | 1990*1640*2380 |
PYD-900 | 900 | 3-13 | 40 | 15-50 | 55 | 10.27 | 1990*1640*2380 |
PYB-1200 | 1200 | 20-50 | 145 | 110-200 | 110 | 24.7 | 2805*2300*2980 |
PYZ-1200 | 1200 | 8-26 | 100 | 50-150 | 110 | 25 | 2805*2300*2980 |
PYD-1200 | 1200 | 3-15 | 50 | 18-105 | 110 | 25.6 | 2805*2300*2980 |
PYB-1750 | 1750 | 25-60 | 215 | 280-480 | 155-160 | 50.6 | 3610*2950*4185 |
PYZ-1750 | 1750 | 10-30 | 185 | 115-320 | 155-160 | 51 | 3610*2950*4185 |
PYD-1750 | 1750 | 5-15 | 85 | 75-230 | 155-160 | 50.5 | 3610*2950*4185 |
PYB-2200 | 2200 | 30-60 | 300 | 590-1000 | 260-280 | 84 | 4790*3430*5080 |
PYZ-2200 | 2200 | 10-30 | 235 | 200-580 | 260-280 | 85 | 4790*3430*5080 |
PYD-2200 | 2200 | 5-16 | 110 | 120-370 | 260-280 | 85 | 4790*3430*5080 |
