Professional Mining Ore Ball Mill Machine for Gold Copper and Aluminum Powder Grinding

Professional Mining Ore Ball Mill Machine for Gold Copper and Aluminum Powder Grinding

Product Details:

Place of Origin: Henan, China
Brand Name: Sinolion

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: $2,686.00/sets >=1 sets
Get Best Price Contact Now

Detail Information

Applicable Industries: Building Material Shops, Manufacturing Plant, Construction Works , Energy & Mining Showroom Location: Canada, United Kingdom, United States, Brazil, Mexico, Russia, Australia
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Marketing Type: New Product 2021 Warranty Of Core Components: 1 Year
Core Components: PLC, Bearing, Motor Condition: New
Type: Ball Mill Motor Type: AC Motor
Capacity(t/h): 0.5-83t/h Dimension(L*W*H): Depend On Models
Weight: 1620 KG Warranty: 1 Year
Application: Gold Iron Copper, Quartz Limestone, Clinker, Cement, Chrom, Chromite Grinding Way: Wet, Dry Or Batch Type
Operation: Automatic Or Manual Driving Type: Diesel Engine Or Motor
Liner: High Manganese, Rubber, Ceramic(as Client Request) After-sales Service: Engineers Available Service Overseas
Brand: Sinolion Color: Customizable
Quality: Excellent Product Name: Lead Aluminum Powder Grinding Gold Copper Ball Mill Machine

Product Description

Mining Ore Iron Tin Manganese Lead Aluminum Powder Grinding Gold Copper Ball Mill Machine

Product Description

The ball mill is a key equipment to grind the crushed materials, which is widely used in the manufacture industries, such as cement, silicate, new building material, refractory material, fertilizer, ferrous metal, nonferrous metal and glass ceramics

Ball mill main parts : feeding part ,discharging part, ball mill cyclinder, transmission (reducer, gear, pinion, electric motor and electric control) and other major parts.





Professional Mining Ore Ball Mill Machine for Gold Copper and Aluminum Powder Grinding 0Professional Mining Ore Ball Mill Machine for Gold Copper and Aluminum Powder Grinding 1



Grinding is the last stage in the process of communication; in this stage the particles are reduced by a communication of impact and abrasion, either dry or in suspension in waterBall mills rotate around a horizontal axis, partially filled with the material to be ground plus the grinding medium. It is performed in rotating cylindrical steel vessels known as tumbling mills.



Wet dry gold ball mill for sale technicial parameters:



Model

Rotation speed

(r/min)

Weight of

grinding media

(ton)

Size of feed opening

(mm)

Discharge size

(mm)

Capacity

(t/h)

Power

(kw)

Weight

(T)

Φ 900x1800 38 1.5 ≤ 20 0.075-0.89 0.65-2 18.5 3.6
Φ 900x3000 38 2.51 ≤ 20 0.075-0.89 1.1-3.5 22 4.6
Φ 1200x2400 32 3.8 ≤ 25 0.075-0.6 1.5-4.8 30-45 12.5
Φ 1200x3000 32 5 ≤ 25 0.074-0.4 1.6-5 30-45 12.8
Φ 1200x4500 32 7 ≤ 25 0.074-0.4 1.6-5.5 55 13.8
Φ 1500x3000 27 8 ≤ 25 0.074-0.4 2-5.8 75-90 17
Φ 1500x4500 27 14 ≤ 25 0.074-0.4 3-6.5 110 21
Φ 1500x5700 27 15 ≤ 25 0.074-0.4 3.5-8 132 24.7
Φ 1830x3000 24 11 ≤ 25 0.074-0.4 4-10 180 28
Φ 1830x6400 24 23 ≤ 25 0.074-0.4 6.5-15 210 34
Φ 1830x7000 24 25 ≤ 25 0.074-0.4 7.5-17 245 36
Φ 2200x5500 21 30 ≤ 25 0.074-0.4 10-22 370 48.5
Φ 2200x6500 21 31 ≤ 25 0.074-0.4 14-26 280 52.8
Φ 2200x7500 21 33 ≤ 25 0.074-0.4 15-29 475 56





Professional Mining Ore Ball Mill Machine for Gold Copper and Aluminum Powder Grinding 2





Packaging & Shipping

Packing Details : All products will be processed to be rustproof and moisture proof before delivery.

20GP container or 40GP container


Equipment is packed with plastic wrap or steel case, depends on machine weight.
Motro is packed with steel case or wooden case. Control panel is packed with steel case.
Loading container in factory.



Delivery Details : 15-25 days after confirming order,detail delivery date should be decided according to production season and order quantity.

Professional Mining Ore Ball Mill Machine for Gold Copper and Aluminum Powder Grinding 3Professional Mining Ore Ball Mill Machine for Gold Copper and Aluminum Powder Grinding 4



Case

Professional Mining Ore Ball Mill Machine for Gold Copper and Aluminum Powder Grinding 5Professional Mining Ore Ball Mill Machine for Gold Copper and Aluminum Powder Grinding 6Professional Mining Ore Ball Mill Machine for Gold Copper and Aluminum Powder Grinding 7

Company Information

Professional Mining Ore Ball Mill Machine for Gold Copper and Aluminum Powder Grinding 8Professional Mining Ore Ball Mill Machine for Gold Copper and Aluminum Powder Grinding 9



Professional Mining Ore Ball Mill Machine for Gold Copper and Aluminum Powder Grinding 10

Professional Mining Ore Ball Mill Machine for Gold Copper and Aluminum Powder Grinding 11

FAQ

Question 1: What’s the delivery time after I pay the deposit ?

Answer: We will delivery the goods within 10-15 working days after receipt of the prepayment.



Question 2: Is mineral samples analysis available?

Answer: Sure, we supply samples analysis service for free. After the testing, we will give you the reasonable flow chart, suitable solution and equipment selection.



Question 3: Do you have client in my country?

Answer: Our products have exported to Malaysia, Indonesia, the Philippines, Vietnam, Myanmar, Korea, Singapore, Thailand, Mongolia, Ghana, Sudan, Serbia, Kazakhstan, Canada, Nigeria, Australia, Chile, Brazil, Columbia, Ecuador, Peru, Bolivia, etc



Question 4: How long of your machine quality guarantee terms ?

Answer: Quality guarantee time is one year(wearing parts excluded).
